Digitus DA-10060 Manual de usuario

USB-C Mini Charging

Adapter 20W

Quick Installation Guide

DA-10060

DEAR CUSTOMER

Thank you for purchasing this product. For optimum

performance and safety, please read these instructions

carefully befor e connecting, operating, or using this

product. Please keep this manual for future reference.

1.INTRODUCTION

The DIGITUS® MINI Charging Adapter is suitable for USB-C

devices such as smartphones, tablets or notebooks and

provides an output of up to 20W. Thanks to the super

compact dimensions, the USB-C charger fits into any bag,

making this charging adapter an ideal companion for

everyday use. The integrated short circuit, surge and excess

current protection provides added security. Fur thermore,

the integrated excess heat protection prevents potential

overloads and damages to the charger or connected

devices.

2.FEATURES

1. Compact charger for USB-C dev ices such as smartphones

or tablets

2. Supports charging power of up to 20W - compatible

with Power Delivery (PD 3.0)

3. Integrated surge protection / excess current protection /

short circuit protection

4. Integr ated overheating protection with auto-recovery

for the highest degr ee of security

5. Ideal for use on the go thanks to compact dimensions

6. Housing made of f ire-resistant material

3.SPECIFICATIONS

Input/output

Input

100-240VAC 50/60Hz

Input Plug

EU plug

Output

5V/3A 9V/2.22A

12V/1.67A (20W Max)

Protection

Over Current Protection

Yes

Over Voltage Protection

Yes

Over Load Protection

Yes

Short Circuit Protection

Yes

Over Temperature

Protection

Yes

Performance

Ripple And Noise

≤200mV

Efficiency

≥85%

Line Regulation

±5%

Mechanical

Color

White

Size

30*29*68mm

weight

37g

Environmental

Operating Temperature

0~25°C

Storage Temperatur e

-20 ~ 85°C

Operating Humidity

20% ~ 90% RH

Storage Humidity

5% ~ 95%

Certification

CE, RoHS ,

Limited Warranty

1 Year

User Manual

English Version

4.PACKAGE CONTENT

Befor e attempting to use this unit, please check the

packaging and make sure the following items are contained

in the shipping carton

1x US B-C Mini Charging Adapter

1x QIG (Quick Installation Guide)

5.OPEARTION

5.1 Operation Procedures

Plug the DC connector of power adapter into a sock et.

Plug one US B connector of the cable into the interface of

the charger and plug the other connector of the cable into

the electronic device (Apple iPad, Google Chrome book,

Apple iPhone, Samsung Smartphone, MP3, PC, etc.)

Please pull the USB connector out after the electronic

equipment's fully charged.

5.2 Operation Notes

For optimum performance, please use the power adapter

according to the user manual.

Please plug the power adapter into socket whose

voltage range should be 100~240VAC.

Please unplug the power adapter after using.

Note: Our products have protection functions and the

two tips above are suggestions just for safety.

Do not use the power adapter with an electronic product

which is not in conformity with the specifications, to avoid

any problems caused by specification mismatching.

It’s normal that power adapter will be a little overheated

in the use process.

When the power adapter stops working und er over-

current, over- temperature or short-circuit protection,

please unplug the device after it automatically r eturns

to work, then you need to check whether the device is

compatible w ith this charger.

Do not let the power adapter close to f ire, such as stove,

candles etc.

Do not let the power adapter soak into liquid, such as

swimming pool, bathtub, etc.

Do not wash the power adapter with corrosive cleaner.

If the power station cannot work properly, please

contact the store or distributor in your area

6.CONNECTION DIAGRAM

1) Smartphone

2) Tablet

Hereby Assmann Electronic GmbH declares that the

Declaration of Conformity is part of the shipping content. If

the Declaration of Conformity is missing, you can request it

by post under the below mentioned manufacturer address.

www.assmann.com

ASSMANN Electronic GmbH

Auf dem Schüffel 3

58513 Lüde

nscheid

Germany
