DigitaLinx DL-HDM88-FS Instrucciones de funcionamiento

11675 Ridgeline Dr
Colorado Springs, CO 80921
Rev 160518 Phone: 719-260-0061
Toll-Free: 800-530-8998
Fax: 719-260-0075
DL-HDM88-FS Installaon and
Operaon Guide

DL-HDM88-FS Installaon Guide
2

DL-HDM88-FS Installaon Guide
3
Important Safety Instrucons
»Please completely read and verify you understand all instrucons in this manual before operang this equipment.
»Keep these instrucons in a safe, accessible place for future reference.
»Heed all warnings.
»Follow all instrucons.
»Do not use this apparatus near water.
»Clean only with a dry cloth.
»Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)
that produce heat.
»Use only accessories specied or recommended by Intelix.
»Explanaon of graphical symbols:
◊ Lightning bolt/ash symbol: the lightning bolt/ash and arrowhead within an equilateral triangle
symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the
product enclosure which may be of sucient magnitude to constute a risk of shock to a person or
persons.
◊ Exclamaon point symbol: the exclamaon point within an equilateral triangle symbol is intended
to alert the user to the presence of important operang and maintenance (servicing) instrucons
in the literature accompanying the product.
»WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
»Use the mains plug to disconnect the apparatus from the mains.
»THE MAINS PLUG OF THE POWER CORD MUST REMAIN READILY ACCESSIBLE.
»Do not defeat the safety purpose polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of
your obsolete outlet. Cauon! To reduce the risk of electrical shock, grounding of the center pin of this plug must be
maintained.
»Protect the power cord from being walked on or pinched parcularly at the plugs, convenience receptacles, and the
point where they exit from the apparatus.
»Do not block the air venlaon openings. Only mount the equipment per Intelix’s instrucons.
»Use only with the cart, stand, table, or rack specied by Intelix or sold with the equipment. When/if a
cart is used, use cauon when moving the cart/equipment combinaon to avoid injury from p-over.
»Unplug this apparatus during lightning storms or when unused for long periods of me.
»Cauon! Shock Hazard. Do not open the unit.
»Refer to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.

DL-HDM88-FS Installaon Guide
4
Table of Contents
Product Overview��������������������������������������������������������������������������������������������������������������������������������������� 6
Package Contents ��������������������������������������������������������������������������������������������������������������������������������������� 6
Front and Rear Panels��������������������������������������������������������������������������������������������������������������������������������� 7
Front Panel���������������������������������������������������������������������������������������������������������������������������������������������������� 7
Rear Panel ����������������������������������������������������������������������������������������������������������������������������������������������������� 7
IR Remote��������������������������������������������������������������������������������������������������������������������������������������������������� 8
Installaon Instrucons������������������������������������������������������������������������������������������������������������������������������ 8
Mount the Matrix ����������������������������������������������������������������������������������������������������������������������������������������� 8
Shelf Mounng Instrucons ...................................................................................................................8
Rack Mounng Instrucons....................................................................................................................8
Connect Sources�������������������������������������������������������������������������������������������������������������������������������������������� 9
Connect Displays������������������������������������������������������������������������������������������������������������������������������������������� 9
Connect External IR Control �������������������������������������������������������������������������������������������������������������������������� 9
Connect RS232 Control��������������������������������������������������������������������������������������������������������������������������������10
Connect TCP/IP (Ethernet) Control ��������������������������������������������������������������������������������������������������������������10
Router Connecon ...............................................................................................................................11
Crossover Cable Connecon .................................................................................................................11
Web Browser Control�������������������������������������������������������������������������������������������������������������������������������� 12
Matrix Control���������������������������������������������������������������������������������������������������������������������������������������������12
Advance Sengs�����������������������������������������������������������������������������������������������������������������������������������������13
Network Sengs�����������������������������������������������������������������������������������������������������������������������������������������15
EDID Management ����������������������������������������������������������������������������������������������������������������������������������� 16
RS232 Commands������������������������������������������������������������������������������������������������������������������������������������� 17
Roung Commands�������������������������������������������������������������������������������������������������������������������������������������17
CEC Control Commands�������������������������������������������������������������������������������������������������������������������������������18
Volume Control Commands ������������������������������������������������������������������������������������������������������������������������19
Video Output Resoluon Commands ���������������������������������������������������������������������������������������������������������19
HDCP Commands ����������������������������������������������������������������������������������������������������������������������������������������20
EDID Commands �����������������������������������������������������������������������������������������������������������������������������������������20
System Commands��������������������������������������������������������������������������������������������������������������������������������������21
Preset Scene Commands�����������������������������������������������������������������������������������������������������������������������������22

DL-HDM88-FS Installaon Guide
5
Troubleshoong ��������������������������������������������������������������������������������������������������������������������������������������� 23
Matrix does not power on���������������������������������������������������������������������������������������������������������������������������23
Cannot view 4K content ������������������������������������������������������������������������������������������������������������������������������23
Cannot hear surround sound audio ������������������������������������������������������������������������������������������������������������23
Technical Specicaons ���������������������������������������������������������������������������������������������������������������������������� 24

DL-HDM88-FS Installaon Guide
6
The DigitaLinx DL-HDM88-FS is an eight input by eight output seamless 4K scaling HDMI matrix switcher
with input support up to 4k@30Hz and HDCP2.2. With a high-performance 4K@30Hz video scaler built into
each output channel, it easily scales various resoluons to match the best video and picture quality across all
displays. The DL-HDM88-FS provides each HDMI output with a de-embedded 3-pin unbalanced stereo audio
out to feed an audio amplier system.
The matrix features advanced independent DIP switch for EDID management. The DL-HDM88-FS oers HDCP
handling, including the ability to turn input HDCP compliance ON and OFF to ensure maximum funconality
with a wide range of sources.
The DL-HDM88-FS can be controlled via front panel buons, front panel IR, external IR, remote IR, RS232, and
Ethernet. The matrix includes a simple IR remote control to allow IR switching. The matrix also features a full
command set for RS232 and Ethernet control with third party control systems, plus control via a web browser.
Product Overview
Package Contents
Please verify the following items are in the shipping box prior to installaon of the DL-HDM88-FS.
1 ea. DL-HDM88-FS
1 ea. IR Remote Controller
1 ea. AC Power Cord
1 ea. USB to UART Cable
8 ea. 3.5mm 3pin Phoenix
1 ea. Matrix Mounng Brackets (pair)
1 ea. IR Receiver
1 ea. DL-HDM88-FS Installaon and Operaon Guide

DL-HDM88-FS Installaon Guide
7
Front and Rear Panels
Front Panel
Rear Panel
134 5
2
AB C
FG
D E H
1. Output Channel Indicator
2. Output Buons
3. Input Buons
4. Front Panel Menu Selecon
5. Power Switch
A. AC 100~240V 50/60Hz power supply input
B. HDMI Outputs
C. Audio Outputs
D. HDMI Inputs
E. IR Extension
F. EDID DIP Switch
G. TCP/IP (Ethernet) control input for control via web browser
H. RS232 control input

DL-HDM88-FS Installaon Guide
8
IR Remote
The DL-HDM88-FS includes a IR remote which performs roung funcons available on the front panel of the
matrix. When using the remote control locally, i.e., pointed directly at the matrix, the previous/next buons
are used to scroll between the input sources connected to the matrix for each individual output display.
Installaon Instrucons
Mount the Matrix
Rack Mounng Instrucons
At least 2 inches of free air space is required on both sides of the DL-HDM88-FS for proper side venlaon.
Avoid mounng the DL-HDM88-FS near a power amplier or any other source of signicant heat.
Remove the rubber feet from the boom of the matrix. Remove the larger two screws on both sides of the
DL-HDM88-FS.
Aach the supplied rack ears to the sides of the DL-HDM88-FS matrix. The matrix requires one rack unit
(1 RU) of space. It is recommended that you leave an empty rack space above and below the DL-HDM88-FS for
addional cooling.

DL-HDM88-FS Installaon Guide
9
Connect Sources
Connect Displays
Connect the source devices to HDMI inputs using HDMI cables that are less than or equal to 5 meters in length
for 4k30 signals. For source devices that are further away, it is highly recommended to install a Digitalinx
DL-HD70 or DL-HDE100.
Connect the display devices to HDMI outputs using HDMI cables that are less than or equal to 5 meters in
length for 4k30 signals.. For display devices that are further away, it is highly recommended to install a Digitalinx
DL-HD70 or DL-HDE100.
Connect External IR Control
If IR extension is required, connect the TRS 3.5 mm plug IR RX to the matrix IR EXT port, ensuring the IR receiver
eye is placed in clear view of the handset used to control.
Insert the matrix power supply included and switch on power located on the front panel. Check that the front
panel LED screen is on to indicate the matrix is ready for use.
Applying Power
Switching Capabilies
Switch between sources and displays using the matrix front panel buons, IR remote control, serial RS232,
or LAN. To set a route using the front panel of the DL-HDM88-FS, press the desired Input buon (Source) and
desired Output buon ( Display), then press Take.

DL-HDM88-FS Installaon Guide
10
Connect RS232 Control
The RS232 connecon on the matrix is One (1) 3-pin Removable Terminal Block Connector. User can use a USB
to UART cable or a direct serial cable for matrix control. See below for control system conguraon.
• 57600 baud
• 8 Data Bits
• 1 Stop Bit
• Parity = none
Connect Ethernet (Web Browser) Control
The DL-HDM88-FS may be controlled via Ethernet through a web browser interface.
The TCP/IP port requires a standard straight-through Category
5 or greater cable with the TIA/EIA-568B crimp paern for
opmal operaon.
The default sengs for the TCP/IP port are:
IP address: 192.168.0.178
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Connect the Ethernet cable between to the matrix and a router
with a straight-through cable or between the matrix and a
computer with a crossover cable.
