Digital Watchdog X39 Manual de usuario

Wall(Ceiling) Mount Camera

Analog PTZ Outdoor

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

User’s Manual

x39

Safety Information

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

This symbol indicates that dangerous voltage

consisting a risk of electric shock is present within

this unit.

This exclamation point symbol is intended to alert the

user to the presence of important operating and

maintenance (servicing) instructions in the literature

accompanying the appliance

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO

USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION:

To prevent damage which may result in ﬁre or electric shock hazard, do not expose this appliance to

rain or moisture.

1. Be sure to use only the standard adapter that is speciﬁed in the speciﬁcation sheet. Using any

other adapter could cause ﬁre, electrical shock, or damage to the product.

2. Incorrectly connecting the power supply or replacing battery may cause explosion, ﬁre, electric

shock, or damage to the product.

3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal

heat generation or ﬁre.

4. Securely plug the power cord into the power receptacle. Insecure connection may cause ﬁre.

5. When installing the camera, fasten it securely and ﬁrmly. A falling camera may cause personal injury.

6. Do not place conductive objects (e.g. screw drivers, coins, metal things, etc.) or containers ﬁlled

with water on top of the camera. Doing so may cause personal injury due to ﬁre, electric shock,

or falling objects.

7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause ﬁre or electric shock.

8. If any unusual smells or smoke come from the unit, stop using the product. In such case,

immediately disconnect the power source and contact the service center. Continued use in such

a condition may cause ﬁre or electric shock.

9. If this product fails to operate normally, contact the nearest service center. Never disassemble or

modify this product in any way.

10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause ﬁre or

electric shock.

11. When ambient temperature is below the freezing point, the dome cover will frost and the power.

will fail. In this case, install or reboot the system, and the frost will disappear 3 hours after turning

on the power.

[Note that the lowest guaranteed operating temperature is -45°C (-49°F) without wind.]

WARNING

Safety Information

1. Do not drop objects on the product or apply strong shock to it. Keep away from a location subject

to excessive vibration or magnetic interference.

2. Do not install in a location subject to high temperature (over 50°C), low temperature (below -10°C),

or high humidity. Doing so may cause ﬁre or electric shock.

3. If you want to relocate the already installed product, be sure to turn o the power and then move

or reinstall it.

4. Remove the power plug from the outlet when there is a lightning. Neglecting to do so may cause

ﬁre or damage to the product.

5. Keep out of direct sunlight and heat radiation sources. It may cause ﬁre.

6. Install it in a place with good ventilation.

7. Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage

the CCD image sensor.

8. Apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids, such as

vases, shall be placed on the apparatus.

9. The Main plug used to disconnect the device shall stay readily operable at any time.

CAUTION

WARNING

1. Read these instructions.

2. Keep these instructions.

3. Regard all warnings.

4. Follow all instructions.

5. Do not use this camera near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including

ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the other. A grounding type plug has two blades and a third

grounding prong. The wide blade or the third prong is provided for your safety. If the provided

plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with cart, stand, tripod, bracket, or table specied by the

manufacturer, or sold with the camera.

13. Unplug this camera when a cart is used. Use caution when moving the

cart that contains the camera to avoid injuries that can result from the

camera falling over.

14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power supply cord or plug is damaged, liquid has spilled on

the camera, objects have fallen into the camera, the camera has been exposed to rain or

moisture, the camera does not operate normally, or the camera has dropped.

Safety Instructions

Contents

Features

Product & Accessories

Parts Name & Function

Safety Information

Important Safety Instructions

INTRODUCTION

DIP Switch Setup

Cabling

Installation

INSTALLATION

Check Points before Operation

Reserved Presets

Moving Around the OSD Menu

Functions

OSD Display of Main Screen

General Rules of Key Operation for Menu

OSD - ROOT MENU & SYSTEM INFORMATION

OSD - DISPLAY SETUP > CAMERA ID

OSD - DISPLAY SETUP > PRIVACY ZONE

OSD - MOTION SETUP

OSD - FUNCTION SETUP > PRESET SETUP

OSD - FUNCTION SETUP > SCAN SETUP

OSD - FUNCTION SETUP > PATTERN SETUP

OSD - FUNCTION SETUP > GROUP SETUP

OSD - FUNCTION SETUP > SCHEDULE SETUP

OSD - CAMERA SETUP > WB SETUP

OSD - CAMERA SETUP > AE SETUP

OSD - CAMERA SETUP > SPECIAL

OSD - SYSTEM SETUP

OSD - SYSTEM INITIALIZE

OSD MENU

Dimension

Specification

Troubleshooting

Warranty Information & Limits and Exclusions

Appendix I Camera IDs

SPECIFICATIONS

x39

Features

CAMERA SPECIFICATIONS

• CCD Sensor: EX-View HADTM CCD

•

Zoom Magniﬁcation: ×39 Optical, ×12 Digital Zoom

• Wide Dynamic Range

• Day & Night Function: ICR (IR Cut ﬁlter Removal)

• Various Focus Mode: Auto Focus/Manual Focus/

Semi-Auto Focus

• Independent or Global Camera Settings for Each

Preset Location

POWERFUL PAN/TILT FUNCTIONS

• Maximum 360°/SEC High Speed Pan/Tilt Motion

• Vector Drive Technology: Pan/Tilt Motions are

accomplished in the shortest path. As a result,

time to target view is reduced dramatically and

the video on the monitor is very natural to watch.

• Ultra low speed (0.05°/SEC) enables operator to

locate camera to desired target view with accuracy

and ease.

• Zoom-Proportional Pan/Tilt speed helps operator

to move the camera easily.

PRESET, PATTERN, SCAN, GROUP, PRIVACY

ZONE, SCHEDULE, AND MORE...

• Maximum 127 presets are assignable. Each of

them have independent characteristics, such as

white balance, auto exposure, label, alarm

input/output, etc.

• Maximum 8 set of scans can be stored. This

enables user to move camera repetitively between

two preset positions with designated speed.

• Maximum 4 patterns can be recorded and played

back. This enables the camera to follow any

trajectory operated by the joystick as closely as

possible.

• Maximum 8 set of group actions can be stored.

This enables the camera to move repetitively

between dierent combination of preset, pattern,

or scan. A group is composed of maximum 20

entities of preset, pattern, or scan.

•

Maximum 8 privacy zones can be set up to protect

privacy of other people.

• 7 rules of schedule can be assigned by day and

time. Appropriate actions (such as home, preset,

scan, pattern, and group) can be deﬁned for each

rule. Also, it is possible to use weekday and all days

to simplify the rule.

PTZ (PAN/TILT/ZOOM) CONTROL

• With RS485 communication, a maximum of 255

cameras can be controlled at the same time.

• Auto, Pelco-D, Pelco-P, Samsung, Panasonic, Kalatel,

AD(American Dynamics) protocol can be selected

as a control protocol in the current version of

ﬁrmware.

OSD(ON-SCREEN DISPLAY) MENU

• OSD Menu is provided to display the status of

camera and to conﬁgure the functions interactively.

•

Camera ID, Pan/Tilt/Zoom/Direction

, Alarm Input/

Output, Date/Time, Current Temperature, and

Preset are displayed on screen.

• Each display item can be turned on or oﬀ

independently.

ALARM I/O FUNCTIONS

• 8 Alarm sensor inputs and 4 relay output are

available.

• To reject external electric noise and shock perfectly,

alarm sensor input is decoupled with photo coupler.

• The signal range of sensor input is from DC 5.0 to

12.0 Volts to adopt various applications.

• If an external sensor is activated, camera can be set

to move to the corresponding preset position.

•

Relay outputs can be assigned to work with a certain

Preset.

RESERVED PRESETS FOR SPECIAL PURPOSE

• Most of camera settings are directly changed by

calling reserved presets, not entering into OSD

Menu. For more information, refer to “Reserved

Presets”(page 18) of this manual.

Product & Accessories

Housing Safety

Cable Hanger

Waterproof Tape

Hole Template

Hexagonal Wrench

User’s Manual

Anchor Bolt (4pcs)

Safety Wire

Product Accessories

Additional Tools for Installation:

1. AC Power Adapter + Cable

2. Dual Cable for RS485 (PTZ Remote Control)

3. At Least Two (2) Terminal Boxes

(Matching the camera’s RS-485 Terminal

and your Joystick Controller DVR,

Alarm Sensor, and Audio In and Out)

4. Drill

5. Screw Driver

1. PTZ Mechanism

2. Sunshield & Upper Housing

3. Mounting Box

4. Inner Box Switches

5. Dome Cover

Part Name & Function

Wall/Pendant Mount Bracket

The Wall/Pendant Mount Bracket is used to secure

the camera onto a wall or ceiling. It includes a

built-in junction box. Depending on the camera’s model,

the Junction box may include the inner box.

The junction box accommodates the inner box.

Sunshield & Upper Housing

PTZ Mechanism

Dome Cover

Inner Box

Wall Mount Bracket

Inner Box

The inner box includes the dip switches and terminal locks. See page 9-10

for further information on what are dip switches and how to set them up.

The inner box also includes the camera’s power supply outlet, and

video, communication, and alarm input/output.

Sunshield & Upper Housing

The Sunshield protects the PTZ mechanism from

the sun rays and rain fall. The upper housing, which

is attached to the sunshield, accommodates the PTZ

mechanism. The Upper housing is also connected

to both the mounting brackets and the dome cover.

The upper housing has a built-in fan and heater to

remove moisture on the bubble dome.

Dome Cover

Do not detach protection vinyl from dome cover

until the installation process is completed. The vinyl

will protect the dome cover from scratches and dust.

DIP Switch Setup

The DIP Switch is a control panel that

is setup to a specific protocol so the camera

can communicate with other devices,

such as: Joystick Controller, DVR, PTZ

Remote Controlling, Alarm Sensor, etc.

Before installing the camera, you

should set the DIP Switch to

configure the Camera ID and

Communication Protocol.

Inner Box

1. Communication Protocol Setup

Congure the appropriate protocol using the

DIP switch combination.

- If you set the protocol as AUTO protocol (factory default),

camera

will automatically recognize the type of protocol

being used; however, this will not recognize the AD

protocol.

If you want to control the camera using the DVR or

system

keyboard, the protocol set in the camera’s inner box

must be identical to the camera protocol setup in the DVR.

Otherwise, you will not be able to control the camera.

See page ____ for further information.

- If you change the camera protocol by adjusting the

DIP switch, the change will be eective after you

reboot the camera.

Protocol Setup Baud Rate Setup RS-485

Termination Resistor

21 3 4 5 6 7 8

8J 21 3 4 5678

AUTO- Factory Default

8J 21 3 4 5678

PELCO-D

8J 21 3 4 5678

PELCO-P

8J 21 3 4 5678

SAMSUNG

8J 21 3 4 5678

PANASONIC

8J 21 3 4 5678

GE(Kalatel)

8J 21 3 4 5678

AD (American Dynamics)

DIP Switch Setup

2. Communication Baud Rate Setup

Select the appropriate Baud Rate with DIP switch

combination. As factory Default, the camera’s

Baud Rate is set to 2400 BPS.

See page ____ for further information.

4. Camera ID Setup

ID number of camera is set using binary number.

The example is shown below.

Inner Box

3. RS-485 Termination Resistor

- The last Pin on the top line on the right,

is used to turn ON/OFF RS-485 termination.

Normally, if you are connecting only one

PTZ camera connected, keep the Switch

on the OFF state. This will allow the camera

to communicate with the controller.

By default, the RS-485 Termination Resistor is OFF.

- When you have a long daisy chain style

connection, turn ON this termination

switch for the camera furthest from the controller.

8J 21 3 4 5678

2400 BPS

8J 21 3 4 5678

4800 BPS

8J 21 3 4 5678

9600 BPS - Factory Default

8J 21 3 4 5678

19200 BPS

38400 BPS

8J 21 3 4 5678

Pin 1 2 3 4 5 6 7 8

1 2 4 8 16 32 64 128ID Value

ex) ID=5

ex) ID=10

OFF

If you want to control a certain camera, you must

match the Camera ID with CAM ID, setting of DVR

or controller.

- The range of ID is 0~255. Factory default of Camera

ID is 1.

- For a full list of all the ID numbers and their

corresponding Pin Switches, please see Appendix I

8J 21 345678

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Digital Watchdog

Digital Watchdog

Digital Watchdog DWC-D4365T Manual de usuario

Digital Watchdog

Digital Watchdog Star-light Plus DWC-B6883WTIR Manual de usuario

Digital Watchdog

Digital Watchdog STAR-LIGHT DWC-D4283WD Manual de usuario

Digital Watchdog

Digital Watchdog Starlight B1363D Manual de usuario

Digital Watchdog

Digital Watchdog MEGAPIX DWC-MT94WiAT Manual de usuario

Digital Watchdog

Digital Watchdog MEGApix DWC-MB72Wi4T Manual de usuario

Digital Watchdog

Digital Watchdog DWC-V1312XW Manual de usuario

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-V6563WTIR Manual de usuario

Digital Watchdog

Digital Watchdog MEGAPIX DWC-MT94WI36T Manual de usuario

Digital Watchdog

Digital Watchdog V1362DIR Manual de usuario

Digital Watchdog

Digital Watchdog DWC-TT4Wi36 Manual de usuario

Digital Watchdog

Digital Watchdog MEGApix DWC-MPVA5WiAT Manual de usuario

Digital Watchdog

Digital Watchdog MEGApix DWC-MD72Di28T Manual de usuario

Digital Watchdog

Digital Watchdog DWC-B562DIR Manual de usuario

Digital Watchdog

Digital Watchdog STAR-LIGHT PLUS DWC-D3853WTIRW Manual de usuario

Digital Watchdog

Digital Watchdog MEGApix DWC-MPTZ30X Manual de usuario

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-MC553WTIR Manual de usuario

Digital Watchdog

Digital Watchdog MegaPix Pano DWC-PZ21M69T Manual de usuario

Digital Watchdog

Digital Watchdog Infinity OMNI-Plus V1382TIR Manual de usuario

Digital Watchdog

Digital Watchdog DWC-MB75Wi4TW Manual de usuario

Digital Watchdog

Digital Watchdog Infinity B1367WTIR650 Manual de usuario

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-VA583WTIR Manual de usuario

Digital Watchdog

Digital Watchdog MEGApix DWC-MVC8WiATW Manual de usuario

Digital Watchdog

Digital Watchdog MEGApix CaaS DWCA-VF25W28-64 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario

Digital Watchdog x39 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas
