Digisol DG-GS4110 Manual de usuario

V1.0

2020-01-22

DG-GS4110

PORTS

8 PORT L2 GIGABIT ETHERNET WEB MANAGED

SWITCH WITH 2 GIGABIT SFP PORTS

Trademarks:

Company has an on-going policy of upgrading its products and it may be

possible that information in this document is not up-to-date.

Please check with your local distributors for the latest information.

No part of this document can be copied or reproduced in any form without

written consent from the company.

DIGISOL is a trademark of DIGISOL SYSTEMS LTD. All other trademarks

are the property of the respective manufacturers.

About guide:

This guide provides instructions to install the Switch.

Note: The model you have purchased may appear slightly different from the illustrations shown

in the document. Refer to the Product Instruction and Technical Specification sections for

detailed information about your switch, its components, network connections, and technical

specifications.

Terminology / Usage:

In this guide, the term "Switch" (first letter capitalized) refers to the Switch, and "switch" (first

letter lower case) refers to other Ethernet switches. Some technologies refer to terms

"switch", "bridge" and "switching hubs" interchangeably, and both are commonly accepted for

Ethernet switches.

Note: indicates important information that helps a better use of the device.

Warning: indicates potential property damage or personal injury.

Products introduction

Thanks for purchasing the Web Managed Ethernet Switch products.

The is a Web Managed Gigabit Ethernet Switch, It provides 8 10/100/1000Mbps Auto-

Negotiation RJ45 ports and 2 Gigabit SFP Ports . It supports the port's full line speed forwarding to

ensure the stable transmission of data. This switch can be used as a small and medium-sized LAN

network.

Excellent performance can help you widely use in wireless, monitoring and other fields.

8 Port 10/100/1000Base-TX with 2 Gigabit SFP Web Managed Switch

Hardware installation

Front Panel

PWR LED：The Power LED lights up when the Switch is connected to a power source.

Link/Act LED: The Link/Act LED flashes which indicate a network link through the corresponding

port. Blinking indicates that the Switch is either sending or receiving data to the port.

RST: Pressing the Reset button for 5 seconds the switch will change back to the default

Configuration and all changes will be lost.

Rear Panel

Grounding: use specialized ground lead connect.

Connect the power adapter output terminal to this port. Supports input voltages +44 ~ +57 VDC

This chapter provides unpacking and installation information for the Web Managed Ethernet

switch.

First step: open a seal

Open the shipping carton and carefully unpack its contents. Please consult the packing list

located in the User Manual to make sure all items are present and not damaged.

Switch 1pcs

AC power cord 1pcs

Rubber feet 4pcs

Screws 6pcs

Mounting brackets 2pcs

CD 1pcs

If any item is found missing or damaged, please contact the local reseller for replacement.

Second step: switch installation

For safe switch installation and operation, it is recommended that you:

Visually inspect the power cord to see that it is secured fully to the AC power connector.

Make sure that there is proper heat dissipation and adequate ventilation around the switch.

Do not place heavy objects on the switch.

Desktop or Shelf Installation

When installing the switch on a desktop or shelf, the rubber feet included with the device must be

attached on the bottom at each corner of the device's base. Allow enough ventilation space

between the device and the objects around it.

Rack Installation

Attach the mounting brackets to the switch's side panels (one on each side) and secure them with

the screws provided (please note that these brackets are not designed for palm size switches).

Third step: Plugging in the AC Power Cord

Using the AC power cord to connect to the power adapter, and then plug the output terminal of

the adapter into the DC IN socket on the back of the switch. (The AC power outlet should be

grounded)

Warning: Do not turn on the power switch before power cables are connected. Power surge may

cause damage to the Switch.

Power failure

As a precaution, the switch should be unplugged in case of power failure. When power is resumed,

plug the switch back in.

Getting Started

This chapter introduces the management interface of Web Managed Ethernet switch.

Management Option

The Web Managed Ethernet switch can be managed through any port on the device by using the

Web-based management.

Each switch must be assigned its own IP address, which is used for communication with Web-

Based Management or a SNMP network manager. The PC should have an IP address in the same

range as the switch.

Please refer to the following installation instructions for the Web-based Management.

Using Web-based Management

After a successful physical installation, you can configure the Switch, monitor the network status,

and display statistics using a web browser.

Supported Web Browsers

The embedded Web-based Management currently supports the following web browsers:

Internet Explorer 6 or higher version

Netscape 8 or higher version

Mozilla

Firefox 1.5/2.0 or higher version

Connecting to the Switch

You will need the following equipment to begin the web configuration of your device:

1. A PC with a RJ-45 Ethernet connection

2. A standard Ethernet cable

Connect the Ethernet cable to any of the ports on the front panel of the switch and to the

Ethernet port on the PC.

In order to login and configure the switch via an Ethernet connection, the PC must have an IP

address in the same subnet as the switch. For example, if the switch has an IP address of

192.168.0.1, the PC should have an IP address of 192.168.0.x (where x is a number between 2 ~

254), and a subnet mask of 255.255.255.0

Open the web browser and enter 192.168.0.1 (the factory-default IP address) in the address bar.

Then press <Enter>.

Enter the IP address in the web browser

NOTE: The switch's factory default IP address is 192.168.0.1 with a subnet mask of

When the following logon dialog box appears, enter the password then click OK.

By default, the username is admin and the password is admin.

To log in to the switch, the IP address of your PC should be set in the same subnet as that of the

switch. The IP address is 192.168.0.x (”x” is any number from 2 to 254). Subnet Mask is

255.255.255.0. 255.255.255.0

1. WEB page elements

Shown in Figure 2, WEB page is mainly composed of three parts: title page, navigation tree page

and main page

Title page is used to display the logo

Main page Is used to display the user from the navigation tree, select the page

Logon Dialog Box
