DFI P5BTX/L Manual de usuario

P5BTX/L

Rev. A+

System Board

User’s Manual

34371013

Thispublicationcontainstheinformationthatisprotectedbycopyright.

Nopartofitmaybereproducedinanyformorbyanymeansorused

to make any transformation/adaptation without the prior written

permissionfromthecopyrightholders.

Thispublication is providedfor informational purposesonly. The

manufacturermakesnorepresentationsorwarrantieswithrespectto

thecontentsoruseofthismanualandspecificallydisclaimsanyexpress

orimpliedwarrantiesofmerchantabilityorfitnessforanyparticularpurpose.

Theuserwillassumetheentireriskoftheuseortheresultsoftheuseof

thisdocument.Further,themanufacturerreservestherighttorevisethis

publicationandmakechangestoitscontentsatanytime,withoutobligation

tonotifyanypersonorentityofsuchrevisionsorchanges.

AllRightsReserved.

Trademarks

Microsoft®MS-DOS®,WindowsTM andWindows®95areregistered

trademarksofMicrosoftCorporation.IntelandPentiumareregistered

trademarksofIntelCorporation.Cyrix,6x86,6x86Land6x86MXare

registeredtrademarksof Cyrix Corporation.AMD,K5and K6 are

registeredtrademarksofAdvancedMicroDevices,Inc. IBMisaregistered

trademarkofInternationalBusinessMachineCorporation.Awardisa

registeredtrademarkofAwardSoftware,Inc.Othertrademarksand

registeredtrademarksofproductsappearinginthismanualarethe

propertiesoftheirrespectiveholders.

Caution:

Danger of explosion if battery incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

Dispose of used batteries according to the battery manufacturer’s

instructions.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•Consult the dealer or an experienced radio TV technician for

help.

Notice:

1.The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2.Shielded interface cables must be used in order to comply with

the emission limits.

TableofContents

Chapter 1 - Introduction

1.1Features and Specifications...................................................................

1.2Package Checklist.......................................................................................7

Chapter 3 - Award BIOS Setup Utility

3.1The Basic Input/Output System........................................................

3.1.1Standard CMOS Setup.......................................................

3.1.2BIOS Features Setup.............................................................

3.1.3Chipset Features Setup.......................................................

3.1.4Power Management Setup................................................

3.1.5PNP/PCI Configuration.......................................................

3.1.6Load Fail-Safe Settings..........................................................

3.1.7Load Optimal Settings..........................................................

3.1.8Integrated Peripherals...........................................................

3.1.9Supervisor Password............................................................

3.1.10User Password.........................................................................

3.1.11IDE HDDAuto Detection................................................

3.1.12Save & Exit Setup...................................................................

3.1.13Exit Without Saving................................................................

Chapter 2 - Hardware Installation

2.1System Board Layout .............................................................................

2.2Installation Steps..........................................................................................

2.2.1Installing System Memory........................................................

2.2.2Installing a Processor..................................................................

2.2.3Setting the Jumpers on the System Board..................

2.2.4Installing Expansion Cards......................................................

2.2.5Connecting the Ribbon Cables and Wires of the

Ports and Connectors..............................................................

2.2.6Installing the System Board....................................................

Appendix A - Identifying Processors

A.1Intel Processors...........................................................................................

A.2Cyrix Processors........................................................................................

A.3AMD Processors........................................................................................

Appendix B - System Error Report

B.1POST Beep...................................................................................................

B.2Error Messages............................................................................................65

Appendix C - Troubleshooting

C.1 Troubleshooting Checklist.....................................................................68

Chapter 4 - Supported Softwares

4.1Desktop Management Interface........................................................

4.2IDE Drivers...................................................................................................57

P5BTX/L System Board User’s Manual

Introduction

CHAPTER

Introduction

1.1 Features and Specifications

1.1.1 Features

Chipset

•Intel82430TX PCIset chipset

Processor

The system board is equipped with a 321-pin ZIF socket (Intel

Socket 7). This socket is designed for easy removal of an old

processor and easy insertion of an upgrade processor. The system

board is also equipped with a switching voltage regulator that

supports 2.8V to 3.5V core voltage for various processors.

•Intel Pentiumprocessor with MMXTM technology-166/200/

233MHz

•Intel Pentium90/100/120/133/150/166/200MHz

•Cyrix6x86L PR150+/PR166+ and 6x86MX-PR166/PR200

•AMDK5 PR90/PR100/PR120/PR133/PR166

•AMDK6-166, K6-200, K6-233 and future K6 processors

System Memory

The system board supports 8MB to 256MB of memory. It is

equipped with two DIMM and four SIMM sockets. The 168-pin

DIMM sockets use x64 EDO (60/70ns), fast page mode (60/70ns),

or SDRAM (10/12/13ns), 3.3V. The 72-pin SIMM sockets use EDO

or fast page mode, 60/70ns, x32 DRAM, 5V.

Level 2 Cache Memory

•512KB pipeline burst, direct map write-back cache installed on

the system board.

Expansion Slots

The system board is equipped with 4 dedicated PCI slots and 3

dedicated 16-bit ISA slots. All PCI and ISA slots are bus masters.

P5BTX/L System Board User’s Manual

Desktop Management Interface (DMI)

The system board comes with DMI 2.0 built into the BIOS. The

DMI utility in the BIOS automatically records various information

about your system configuration and stores these information in

the DMI pool, which is a part of the system board's Plug and Play

BIOS. DMI, along with the appropriately networked software, is

designed to make inventory, maintenance and troubleshooting of

computer systems easier.

Onboard I/O

•Two NS16C550A-compatible serial ports

•One SPP/ECP/EPP parallel port

•One floppy drive interface supports up to 2.88MB floppy

drives.

•One PS/2 mouse port

•One PS/2 or AT keyboard port

•One 12-pin standard AT power supply connector

PCI Bus Master IDE Controller

•Two PCI IDE interfaces support up to four IDE devices

•Ultra DMA/33 supported (Synchronous DMA mode - data

transfer rate up to 33MB/sec.)

•PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up

to 16.6MB/sec.)

•Bus mastering reduces CPU utilization during disk transfer

•ATAPI CD-ROM supported

•LS-120 and ZIP supported

IrDA Interface

The system board is equipped with an IrDA connector for

wireless connectivity between your computer and peripheral

devices.

USB Ports

The system board is equipped with a header for external USB

ports. USB allows data exchange between your computer and a

wide range of simultaneously accessible external Plug and Play

peripherals.

Introduction

BIOS

•Award BIOS, Windows95 Plug and Play compatible

•Flash EPROM for easy BIOS upgrades

Power Supply Connector

The system board is equipped with an AT power supply connector

for connecting an AT power supply.

1.1.2 Technology

SDRAM

Synchronous Dynamic Random Access Memory (SDRAM) is a

DRAM technology that uses the clock on the chip to synchronize

with the CPU clock so that the timing of the memory chips and

the timing of the CPU are synchronized. This saves time during

transmission of data, subsequently increasing system performance.

Ultra DMA/33 Bus Master IDE

The system board supports Synchronous Ultra DMA mode that

provides data transfer rate at 33MB/sec, which is double the data

transfer rate of Enhanced IDE or ATA-2. This enables the CPU to

operate more efficiently when handling simultaneous events.

1.1.3 Intelligence

RTC Timer to Power On the System

The RTC installed on the system board allows your system to

automatically wake up on the set day and time. Set the day and

time you would like your system to power on in the “Resume By

Alarm” field (Power Management Setup) of the Award BIOS.

P5BTX/L System Board User’s Manual

Virus Protection

Most viruses today destroy data stored in hard drives. The system

board is designed to protect the boot sector and partition table

of your hard disk drive. If an attempt is made to write to the

boot sector or partition table of the hard disk drive, the BIOS will

halt the system and an error message will appear. Refer to the

“Virus Warning” field in the BIOS Features Setup section of this

manual (Chapter 3).

1.2 Package Checklist

The system board package contains the following items:

þThesystemboard

þA user’s manual

þSerial, mouse and printer port cables

Option 1:

-One card-edge bracket with a 9-pin and 25-pin serial port

cables

-One card-edge bracket with a 25-pin printer port cable

and a PS/2 mouse port cable

Option 2:

-One card-edge bracket with two 9-pin serial port cables

and a PS/2 mouse port cable

-One 25-pin printer port cable for chassis mounting

þOne 40-pin IDE hard disk cable

þOne 34-pin floppy disk drive cable

þOne utility diskette

þFive spare jumpers

¨Onecard-edge bracketwithtwoUSBports(optional)

If any of these items are missing or damaged, please contact your

dealer or sales representative for assistance.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de DFI

DFI

DFI C586HX Manual de usuario

DFI

DFI Blood-Iron P43-T34 Manual de usuario

DFI

DFI LanParty DK 790GX-M2RS Manual de usuario

DFI

DFI SD170 Manual de usuario

DFI

DFI WL051-BCC-4305UE Manual de usuario

DFI

DFI SB102-D Manual de usuario

DFI

DFI PS35-BC Manual de usuario

DFI

DFI GIC68-D Manual de usuario

DFI

DFI CA63-SN Manual de usuario

DFI

DFI ADS630 Manual de usuario

DFI

DFI G5C630-DR Manual de usuario

DFI

DFI P4X400-A Manual de usuario

DFI

DFI 915P-TAL Manual de usuario

DFI

DFI HU171 Manual de usuario

DFI

DFI SD101 Manual de usuario

DFI

DFI 486-OCV Plus Manual de usuario

DFI

DFI 855GME-MGF Manual de usuario

DFI

DFI AD72-SC Manual de usuario

DFI

DFI CD102 Series Manual de usuario

DFI

DFI SD630-H110-000G Manual de usuario

DFI

DFI LanParty UT X38 Series Manual de usuario

DFI

DFI CMS630-Q470E Manual de usuario

DFI

DFI AD76 RAID Manual de usuario

DFI

DFI Blood-Iron G41-T33 Manual de usuario

Manuales populares de Placa madre de otras marcas

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
