DELTA 200

Installation guide

Outdoor-temperature-driven controller

for hot water heating

DELTA DORE

Bonnemain - 35270 COMBOURG - France

E-mail : deltadore@deltadore.com

Unit compliant with the requirements of directives

2004/108/CE (Electromagnetic Compatibility)

and 2006/95/CE (Low-Voltage Safety).

*2702087_Rev.1*

Because of changes in standards and equipment, the characteristics given in the text and the illustrations of

this document are not binding unless confirmed by Delta Dore.

- 3 -- 2 -

Installing the room unit

Choosing a location

Since the temperature measurement sensor is inside the unit, you must

install the thermostat flush-mounting box:

- in zone 1 (main room) only,

- on an accessible wall at a height of 1.50 m,

- away from heat sources (fireplaces, sunlight) and draughts (windows,

doors).

IMPORTANT: Do not install the thermostat on a wall in contact with the out-

doors or with an unheated room (e.g. garage, etc.).

The sleeve output in the flush-mounting box must be plugged (with mastic)

in order to avoid unwanted air movements that would cause the sensor rea-

ding to be inaccurate.

approx. 1.5 m

Min. 20 cm

Contents

Installing the room unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Room unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Technical unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installing the sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Water temperature sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Outdoor sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Determining the type of installation . . . . . . . . . . . . . . . . . . . . . . . . 6

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Technical characteristics

Technical unit

• 230V, 50 Hz power supply, ±10%

• Class I insulation

• Consumption: 4 VA

• 1 outdoor sensor input

• 2 feed (zone 1) and return (zone 2) sensor

inputs

• 2 circulator control outputs (zone 1 and

zone 2): 2A, 230V

• 1 boiler control output, 2A dry contact (do

not supply mains power)

• 1 mixer valve control output: 2 2A, 24V or

230V operating contacts that open and

close the valve (zone 1)

• Bus connection with the room unit: insulated

1.52 electric cable, max. length 50 m

• Automatic action: 1.C

• Storage temperature: -10°C to +70°C

• Operating temperature:

0°C to +40°C

• Dimensions: 80 x 230 x 65 mm

• Fire rating: 5V

• Circulator anti-seizing function: it switches

the circulator on for 3 seconds if the circula-

tor has not operated in the previous 24

hours (useful when the heating is off).

Room unit

• Power supply by bus, 12 to 22V voltage

• Class III insulation

• Clock backup during mains power failure: 2

hours (by capacitor)

• Storage temperature: -10°C to +70°C

• Operating temperature: 0°C to +40°C

• Dimensions: LxHxD = 82 x 94 x 53 mm

• Protection index: IP 30

• Fire rating:Vo

- 5 -- 4 -

Installing the sensors

Feed (zone 1) and return (zone 2) sensor

The water temperature sensors are wall-moun-

ted.

They are used to measure the surface tempera-

ture of pipes..

They can be used in a measurement range of -

30°C to +150°C, and are fitted as standard with

a 10 kΩNTC measuring element.

The sensors have a clamp so that they can be attached to pipes up to 1½"

in diameter.

The feed sensor (zone 1) must be installed after the mixer valve, between

the circulator (~50 cm) and the connected equipment (underfloor heating or

radiators).

The return sensor (zone 2) must be installed on the return of

the direct radiator network.

To ensure that the temperature is measured correctly, apply

the thermal paste from the syringe between the sensor and

the pipe.

Outdoor sensor

The outdoor sensor must be attached to a vertical wall with

screws and plugs.

The recommended position is on a

wall facing north or north-west,

away from unwanted heat sources (fireplace, air

vents, thermal bridges, etc.).

Mounting the room unit

Switch off the mains power supply (general

circuit breaker) before proceeding.

To attach the unit to the wall, you must separate it

from its base.

To do this, unscrew the lock screw as shown

opposite.

Once separated from the unit, the base can be

connected to the technical unit via the bus,

then attached to the flush-mounting box (dis-

tance between centres: 60 mm).

Screw the unit

closed.

Mounting the technical unit

The technical unit must be installed next to the boiler.

Remove the cover and attach the unit using screws and plugs.

Connect the unit before closing the cover.

Mounting

- 7 -- 6 -

Application 4: 1 radiator zone (without thermostatically controlled valves)

Application 3: 1 radiator zone (without thermostatically controlled valves),

1 radiator zone (with thermostatically controlled valves)

Zone 1

Zone 2

Circulator

zone 2

Circulator

zone 1

Room unit

in zone 1

SFeed

sensor

zone 1

Return sensor

zone 2

Mixer

valve

Outdoor

sensor

Boiler

thermostat

input control

Circulator

zone 1

SFeed

sensor

zone 1

Mixer

valve

Outdoor

sensor

Boiler

thermostat input

control

Zone 1 can be fitted with radiators that have thermostatically controlled

valves operating as limiters.

Connection

Determining the type of installation

Application 2: 1 underfloor hot water zone

Application 1: 1 underfloor hot water zone,

1 radiator zone (with thermostatically controlled valves)

Zone 1

Zone 2

Circulator

zone 2

Circulator

zone 1

Room unit

in zone 1

SFeed

sensor

zone 1

Return sensor

zone 2

Mixer

valve

Outdoor

sensor

Boiler

thermostat

input control

Circulator

zone 1

SFeed

sensor

zone 1

Mixer

valve

Outdoor

sensor

Boiler

thermostat

input control

IMPORTANT: If zone 2 is not used, switch it to Economy mode (with a set-

ting of 10°C).

- 9 -- 8 -

The wiring for the boiler thermostat input

control is optional.

It must be connected if you wish to authori-

se reductions when the DELTA 200 is not

being used for heating.

To connect it, remove the shunt (electric

wire) connecting the two thermostat input

terminals.

If the boiler has a clock input, do not mistake it for the thermostat input.

Testing the installation

Before closing the cover of the technical unit:

- Switch the installation on,

- Check that the green LED comes on (dialogue between the technical

unit and the room unit),

- Use a temperature setting that is high enough to activate the heating,

- The red LEDs indicate the status of the relay outputs:

- Restore the settings required for normal use,

- Close the cover of the technical unit.

Green LED

Dialogue Valve

opening Valve

closing Boiler

control Circulator 2 Circulator 1

Red LEDs

remove

the shunt

wires to be

connected

to the thermostat

do not mistake

for the clock input

(on some boiler models)

Connection

The diagrams provided are simplified for greater clarity.

Protections and other accessories required by standards are not illustrated.

- The connection must comply with UTE standard NF C15-100 and good practice.

- Nearby units or those that are connected must not generate excessive interference

(directive 2004/108/EEC).

• The contact sensor cable is 2.5 m long.

• The outdoor sensor can be connected using Ro2V cable (1.5 mm2).

• Sensor cables must never be longer than 50 m.

• Use an optional rate 3-way mixer valve, equipped with a 24 V or 230 V

servomotor. Duration of travel: 60 sec. to 240 sec.

Room unit

Zone 1

circulator

Zone 2

circulator

Mixer valve

Boiler

thermostat

input

IMPORTANT :

- Before connecting the return sensor for network 2, remove the resistor wired to terminals 3 and 4.

- To prevent any confusion when connecting the bus, it is advisable to use a cable of a completely

different colour from that used for the unit’s power supply (take care to align the poles properly).

- Any junctions or terminal block connections must be made outside the unit.

- The underfloor heating system must have a safety device that automatically cuts off the supply

of heat to the underfloor heating system when it reaches the limits set by DTU standard 65.8.

This underfloor heating security thermostat must be connected in series to the zone 1 circulator.

- In this wiring example, the mixer valve is supplied with 230 V power.

Some valves may be supplied with 24 V power. If this is the case, you must modify the wiring.

Zone 1

Valve

Network

Feed

Sensor

Zone 2

Direct

Network

Return

Sensor

Outdoor

sensor

NTC sensors

10,000 Ohms at 25°C To room unit

Pwr sup. Op. Cls.

24 V or 230 V

valve (2A)

Zone 1

Boiler

thermostat

input

control

Zone 2

230 V (2A)

radiator

circulator

Zone 1

230 V (2A)

circulator

network

230 V-50 Hz

Cons. 4 VA

power supply

- 11 -- 10 -

Menu C03: Setting the minimum water temperature

for network 1

This is the minimum temperature provided for a heating request from the

network.

Default setting: C03=0 and the temperature set to 20°C.

Menu C04 : Réglage de la température d’eau maximum

du réseau 1

Default setting: C04=0 and the temperature set to 50°C.

Changes not allowed

Changes allowed (from 20°C to 60°C)

Upon activation, the temperature is set to 20°C

Authorisation to modify the minimum

temperature for network 1

Changes not allowed

Changes allowed (from network 1 minimumT° + 1°C to 90°C)

Upon activation, the temperature is set to 50°C

(to match underfloor heating requirements).

Authorisation to modify the maximum

temperature of network 1

IMPORTANT: If you are using underfloor heating, the temperature

must not exceed 50°C.

When you increase the maximum temperature of network 1 from 50 to

51°C, network 1 acquires the status of a radiator network:

- zone 1 automatically goes into Comfort mode from 6am to 11pm for

each day of the week,

- the slope of zone 1 is initialised at 2.

When you decrease the maximum temperature of network 1 from 51 to

50°C, network 1 acquires the status of an underfloor heating network:

- zone 1 automatically goes into continuous Comfort mode for each day

of the week,

- the slope of zone 1 is initialised at 0.8.

Activation

Turn the knob to .

General principle: In each menu, press the

or button to modify,

and press to go to the next menu.

Menu C01: Access to program and setting changes

To modify settings, press the buttons in the following sequence: 5

times, 3 times, 5 times.

Default setting: C01=0

Menu C02: Outdoor temperature for no heating

Above this temperature, the circulators are off.The boiler thermostat input

control is off and the valve is forced to close.

Default setting: C02=0 and the temperature set to 20°C.

Modification of installer

settings

Allowed

Not allowed

Programming limitation

Access to the installer and

programming limitation settings

• Programs cannot be modified

• The frost protection setting

cannot be changed

• For each zone,

the temperature settings

are from 5°C to the Comfort

setting

Changes not allowed

Changes allowed (from 15°C to 25°C)

Upon activation, the temperature is set to 20°C

Authorisation to modify the outdoor

temperature for no heating

- 13 -- 12 -

Menu C07: Setting the slope of zone 1 (see pg. 14)

Default setting: C07=0 and the slope is set to 0.8.

Example 1: Setting network 1 for underfloor heating

To determine the correct slope for your installation, on the corresponding

axes, note down the maximum feed temperature for network 1 (set in menu

C04, e.g. 45°C) and the minimum outdoor base temperature (e.g.-6°C). In

this example, the correct slope is 0.9.

Example 2: Setting network 1 for radiators

On the corresponding axes, note down the maximum feed temperature for

network 1 (set in menu C04, e.g. 75°C) and the minimum outdoor base

temperature (e.g. -6°C).

In this example, the correct slope is 2.

IMPORTANT: In a few days (if the programming authorises enough com-

fort periods), DELTA 200 will automatically adapt the slope to the installa-

tion settings: this is self-adaptation.

Changes not allowed

Changes allowed (from 0 to 4 in increments of 0.1)

Upon activation, the slope is set to 0.8.

Authorisation to change the slope

of network 1 (zone 1)

Changes not allowed

Changes allowed (from 0 to 4 in increments of 0.1)

Upon activation, the slope is set to 0.8.

Authorisation to change the slope

of network 1 (zone 1)

Activation

Menu C05: Setting the minimum water temperature

for network 2

Zone 2 does not have a room sensor. Adjustments are made using the

thermostatically controlled valves.The setting displayed on DELTA 200 is

merely theoretical.

Default setting: C05=0 and the temperature set to 20°C.

Menu C06: Setting the maximum water temperature

for network 2

Default setting: C06=0 and the temperature set to 80°C.

Changes not allowed

Changes allowed (from network 2 minimumT° + 1°C to 90°C)

Upon activation, the temperature is set to 80°C.

Authorisation to modify the maximum

temperature of network 2

Changes not allowed

Changes allowed (from 20°C to 60°C)

Upon activation, the temperature is set to 20°C

Authorisation to modify the minimum

temperature for network 2

- 15 -- 14 -

Menu C08: Setting the slope of zone 2

Default setting: C08=0 and the slope set is 1.0.

Example: Minimum outdoor base temperature: -6°C

Direct radiator network feed temperature: 70°C

Determine the temperature drop (Δt) between the network feed and return

in accordance with the installation characteristics: e.g. 20°C

In this example, the return temperature is estimated to be 50°C.

On the corresponding axes, note down the maximum return temperature for

network 2 and the minimum outdoor base temperature (e.g. -6°C).

In this example, the correct slope is 1.

Manual setting:

Set the temperature to 20°C on the DELTA 200 and set

the thermostatically controlled valves to maximum.For outdoor temperatu-

res of around 10°C, you must obtain 20°C in the room measured.

Use a higher slope if the temperature is lower.

Use a lower slope if the temperature is higher.

Return the thermostatically controlled valves to the desired setting.

Changes not allowed

Changes allowed (from 0 to 4 in increments of 0.1)

Upon activation, the slope is set to 1.

Authorisation to change the slope

of network 2 (zone 2)

20 18 16 14 12 10 8 6 4 2 0 -2 -4

-6

-8 -10 -12 -14 -16 -18 -20

Network T

Slope 0,2

Slope 2

Slope 3

Slope 3,5 Slope 2,5

Slope 4

Slope 0,6

Slope 1,2

Slope 1

Slope 1,8 Slope 1,6

Slope 1,4

Slope 0,8

Slope 0,4

Activation

Example 1: Setting network 1 for underfloor heating

Example 2: Setting network 1 for radiators

20 18 16 14 12 10 8 6 4 2 0 -2 -4

-6

-8 -10 -12 -14 -16 -18 -20

Text

Feed T

Slope 0,2

Slope 2

Slope 3

Slope 3,5 Slope 2,5

Slope 4

Slope 0,6

Slope 1,2

Slope 1

Slope 1,8

Slope 1,6

Slope 1,4

Slope 0,8

Slope 0,4

20 18 16 14 12 10 8 6 4 2 0 -2 -4

-6

-8 -10 -12 -14 -16 -18 -20

Text

Feed T

Slope 0,2

Slope 2

Slope 3

Slope 3,5 Slope 2,5

Slope 4

Slope 0,6

Slope 1,2

Slope 1

Slope 1,8 Slope 1,6

Slope 1,4

Slope 0,8

Slope 0,4

- 17 -- 16 -

Menu C11: Setting the temperature increase time for

zone 2

This is the period during which overpower is used in zone 2 to increase the

temperature.

The following formula is used when switching from Economy to Comfort

mode: Toverpower = setting C11 x (zone 2 setting - outdoor T°)

The following formula is used when switching from Shutdown or Frost

Protection to Economy or Comfort mode:

Tsoverpower = 2 x setting C11 x (zone 2 setting - outdoorT°)

Upon activation, the time is set to 5 min./°C.

Menu C12: Control differential for zone 2

Default setting: C12=0 and the differential is set to 3°C.

Changes not allowed

Changes allowed (from 0 to 20 minutes/°C)

Upon activation, the time is set to 5 min./°C.

Setting the overpower time for zone 2

Changes not allowed

Changes allowed (from 0.5°C to 10°C)

Upon activation, the temperature is set to 3°C.

Setting the control differential for zone 2

Tip: Initially, use the default setting (30 min/°C).

- If the desired temperature is reached too quickly, set a higher value

(e.g. 45 min./°C).

- If the desired temperature is not reached quickly enough, set a lower

value (e.g. 20 min./°C).

IMPORTANT : If you do not require anticipation, set C10 to 0.

Activation

Menu C9: Valve operating time

Corresponds to the maximum time for the valve to open or close.

Default setting: C09=0 and the time set is 120 seconds.

Menu C10: Anticipation value of zone 1

Anticipation is the time it takes to reach the desired temperature at the time

specified in the program, namely:

Tanticipation = (Zone 1 setting - Zone 1 T° as measured) x Setting C10.

It keeps the temperature from rising too quickly, which would consume too

much energy.

Example:You are in economy mode and the room temperature is 17°C.

The Comfort temperature setting is 20°C.

C10 is set to 30 min/°C.

For room temperature to have reached 20°C by the time Comfort mode is

programmed to come on, heating will need to begin 1.5 hours in advance:

Ta = (20°C - 17°C) x 30 min./°C = 1:30.

Default setting: C10=0 and anticipation time is set to 30 minutes/°C.

Changes not allowed

Changes allowed (from 0 to 120 minutes/°C in increments of 5)

Upon activation, the time is set to 30 min./°C.

Setting the anticipation time

for zone 1

Changes not allowed

Changes allowed (from 1 to 240 seconds)

Upon activation, the time is set to 120 seconds.

Setting the valve operating time (zone 1)

IMPORTANT: To determine the valve operating time, refer to the valve

documentation.

- 19 -- 18 -

Nothing is displayed

on the room unit screen. There is no power supply:

Check your circuit breaker or the link

with the technical unit

The screen flashes

The unit displays:

There has been a lengthy mains power failure.

Reset the unit's clock.

Diagnosis

/Solutions

• Communication fault between the room

unit and the technical unit

• Zone 1 feed sensor fault

• Zone 2 return sensor fault

• Outdoor sensor fault

Contact your installer.

Default setting: C15=0.

Menu C16: Combining heating with the alarm

This menu is displayed if a TYXAL alarm control unit is used with the DELTA 200.

Default setting: C16=1.

Fully activating the control unit switches the installation into Economy

override mode in both zones.

Shutting the control unit down switches the installation into Comfort

override in both zones (up to the next change of program).

Maintenance

Not allowed

Allowed

Combining heating with alarm operation

Activation

Menu C13: Authorising and modifying the access code

Only if DELTA 200 is associated with a TYPHONE 500.

Default setting: C13=0.

For each access code digit, press the or buttons to modify it and

press to go to the next digit.

Menu C14: Language selection

Only if DELTA 200 is associated with a TYPHONE 500.

Default setting: C14=0.

Menu C15: Correcting the room temperature measure-

ment (zone 1)

If there is a difference between the actual temperature (taken with a

thermometer) and the temperature measured and displayed by the unit,

menu C15 can be used to compensate for the difference (from -4°C to

+3.9°C in increments of 0.1°C) by changing the way the sensor measures.

No access to correction

Correction possible

Correction of the temperature measured

in zone 1

French

English

Language selection

No access code (upon activation)

Code authorised (the code can be modified)

Access code authorisation

Otros manuales para DELTA 200

Tabla de contenidos

Otros manuales de Termostato de DELTA DORE

DELTA DORE

DELTA DORE Connected Tybox 5100 Pack Manual de usuario

DELTA DORE

DELTA DORE TYBOX Manual de usuario

DELTA DORE

DELTA DORE TYBOX 5200 Manual de usuario

DELTA DORE

DELTA DORE Tybox 5701 FP Manual de usuario

DELTA DORE

DELTA DORE DELTA 8000 TAP BUS Manual de usuario

DELTA DORE

DELTA DORE TYBOX 21 Manual de usuario

DELTA DORE

DELTA DORE Tybox 5701FP Manual de usuario

DELTA DORE

DELTA DORE TYBOX 147 Manual de usuario

DELTA DORE

DELTA DORE RADIO TYBOX Manual de usuario

DELTA DORE

DELTA DORE Radio Tybox Manual de usuario

DELTA DORE

DELTA DORE TYBOX 147 Manual de usuario

DELTA DORE

DELTA DORE Tybox 1117 Manual de usuario

DELTA DORE

DELTA DORE TYBOX 127 Manual de usuario

DELTA DORE

DELTA DORE TYBOX 817 W RF Manual de usuario

DELTA DORE

DELTA DORE Tybox 5300 Manual de usuario

DELTA DORE

DELTA DORE TYBOX 21 Manual de usuario

DELTA DORE

DELTA DORE TYBOX 610 RF Manual de usuario

DELTA DORE

DELTA DORE TYBOX B+ Manual de usuario

DELTA DORE

DELTA DORE PACK TYBOX 5000 Manual de usuario

DELTA DORE

DELTA DORE TYBOX 817- 827 W RF Manual de usuario

DELTA DORE

DELTA DORE PACK TYBOX 5000 Manual de usuario

DELTA DORE

DELTA DORE 6050675 Manual de usuario

DELTA DORE

DELTA DORE Diana D20 Manual de usuario

DELTA DORE

DELTA DORE DELTA 8000 TA BUS Manual de usuario

Manuales populares de Termostato de otras marcas

EWELLY

EWELLY EW-181 Manual de usuario

Prolon

Prolon T1100 Instrucciones de instalación

Computherm

Computherm Q20 Manual de usuario

Heatmiser

Heatmiser neoStat Manual de usuario

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Manual de usuario

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Manual de usuario

Saswell

Saswell SAS920XWHB-7-S-RF Guía

Aircalo

Aircalo TFP1-ET85P2 Manual de usuario

Honeywell

Honeywell CM721 Manual de usuario

Carrier

Carrier DEBONAIR 33CS Manual de usuario

Lennox

Lennox iHarmony Zone Thermostat Instrucciones de montaje

Gemtech

Gemtech GT7000 Manual de instrucciones

Rollei

Rollei Smartes 45000 Manual de usuario

Sinope

Sinope TH1300RF Manual de usuario

Honeywell

Honeywell RLV4305 Manual de usuario

Honeywell

Honeywell Prestige 2.0 THX9421 Manual de usuario

NuTone

NuTone NTBZ48 Instrucciones de funcionamiento originales

Stelpro

Stelpro MAESTRO ASMT402AD Manual de usuario
