Delta Children Little Folks OLYMPIA Manual de usuario

Customer Service Tel. (646) 435-8726 www.deltachildren.com www.deltachildren.com

INSTRUCTION MANUAL

Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE

LF11459

OLYMPIA

STROLLER

WARNING:

Adult assembly required because of

small parts. Keep assembly parts out

of reach of children

under 3 years.

CHOKING HAZARD

Customer Service: (646) 435-8726 DCP-01232020-F4

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Before returning this product to the store!

Let’s see if we can assist you!

• Not sure how to assemble our product?

Visit our site for easy to follow instructions along with some Tricks and Tips assembly

video’s https://www.deltachildren.com/pages/instructions

• If you are missing a piece or have a damaged part

Please contact our Consumer Experience Center for assistance at 646-435-8726 or email

[email protected]. To better assist you please have your Style# or Model# and

Lot# available. This can be found on a white rectangular sticker on your product, on the

regisatrion card, and on the product’s box.

• In the event we do not have a replacement part available

You may need to return your product to the retailer for an exchange or refund.

• Warranty

In order to protect your investment, don’t forget to register your product.

You may also wish to consider purchasing our extended warranty.

Visit https://www.deltachildren.com/pages/extended-warranty for more details.

• Please note:

“All Final”, “As Is” or Third Party/Liquidator sales are not covered under our Limited

Limited Manufacturer Warranty..

Customer Service Tel. (646) 435-8726 www.deltachildren.com

EXTENDED WARRANTY

DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFE’S MISHAPS!

With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if

your item stops working due to normal wear and tear, plus all those unexpected surprises.

2 YEARS OF PROTECTION

For Additional Information:

Simply visit our Website, register your product, and add the Extended Warranty

https://www.deltachildren.com/pages/product-registration

Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,

Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,

New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia

LIMITED MANUFACTURER WARRANTY

This Delta product is warranted to be free from defects for a period of 90 days from the date of

purchase under normal use. This warranty extends only to the original retail purchaser and is valid

only when supplied with proof of purchase, or if received as a gift, when the registration is on file

with Delta. This limited manufacturer warranty does not cover the following:

• Products purchased as floor models or samples.

• Items purchased on an “as-is” basis, as a second hand product, or as a resale product.

• Items purchased at a Final sale, a “Going out of Business” sale, or a Liquidation sale.

TO REGISTER YOUR PRODUCT for important safety alerts and updates to your product

please visit www.deltachildren.com

TO REPORT A PROBLEM, please log on to www.deltachildren.com and click the

Consumer Care Tab, or contact us by phone at (646) 435-8726 or email [email protected]

Date of Purchase: _____________ (you should also keep your receipt)

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Prevent serious injury from falls

or sliding out:

• ALWAYS use the restraint system.

• Only children who have developed enough

upper body control to sit without leaning

forward can use the front seat in the

upright position.

• NEVER leave child unattended.

• DO NOT use the storage bag to carry children.

To prevent product from tipping over:

• DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the storage bag.

• DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the cup holder.

• DO NOT place additional items on this

product, except as recommended in

the instructions.

To prevent injury:

• Make sure all body parts are clear of the

stroller when folding and unfolding.

• DO NOT place hot liquids in the cup holder.

Hot liquids can burn your child.

WARNING

•Please read these instructions before assembly and use of this product.

•Adult assembly is required.

•Use only for a child who weighs less than 45 lbs (20.41 kg).

•Maximum weight limit for the storage bag is 3 lbs (1.36 kg).

•Maximum weight limit for the cup holder is 3 lbs (1.36 kg).

•Product features and decorations may vary from the photo.

Consumer Information

Care

•The plastic parts may be wiped clean using a mild cleaning solution and

damp cloth. Hand wash fabric with damp cloth and air dry.

Do not use bleach.

•To keep your stroller wheels from squeaking, use a silicone or graphite

based lubricant.

English Instructions

Delta Children's Products Corp.

114 West 26th Street

New York, NY 10001

(646) 435-8726

www.DeltaChildren.com

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Front Swivel

Wheels X 2

Parts

IMPORTANT! Please remove all parts from the package and identify

them before assembly.

Rear Non-Swivel

Wheel x 2

Assembly

Inside View of

Rear Wheels

Fully Locked

Position

IMPORTANT! Before assembly or each use, inspect this product for

damaged hardware, loose joints, missing parts or sharp edges.

DO NOT use if any parts are missing or broken. Contact manufacturer for

replacement parts and instructions if needed. Never substitute parts.

Attaching Rear Non-Swivel Wheels

• Locate the legs on the rear of the stroller as illustrated.

• Use the Rear Non-Swivel Wheel and align with the stroller frame leg.

• Attach Rear Non-Swivel Wheel into the rear of the stroller frame leg,

make sure the pin is aligned with the housing, until it “CLICKS” into a

fully locked position. Make sure the wheel is in a fully locked position by

pulling outward on the wheel.

• Repeat on opposite side.

Front Wheel Assembly

•Slide the front wheel caster onto a front leg. Make sure you hear a

“click”.

•Pull on the front wheel assembly to make sure it is securely attached to the

front leg.

• Repeat this procedure to attach the other front wheel assemblies.

Front Wheel Caster

Front Leg

Cup Holder

Stroller

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Setup and Use

To Unfold

•Locate the latch clip on the side of the stroller.

•Pull to release the latch clip on the side of the stroller.

•Position the stroller upright on its rear wheels.

•Grasp a handle with one hand. With your other hand, push down on the

front of the stroller to open.

Latch Clip

Side Frame

Opening Stroller

• With your foot, push down on the Primary Locking Mechanism

until it “clicks” into place.

Primary Locking

Mechanism

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Setup and Use

Prevent serious injury from falls

or sliding out:

• ALWAYS use the restraint system.

• Only children who have developed enough

upper body control to sit without leaning

forward can use the front seat in the

upright position.

• NEVER leave child unattended.

• DO NOT use the storage bag to carry children.

To prevent product from tipping over:

• DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the storage bag.

• DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the cup holder.

• DO NOT place additional items on this

product, except as recommended in

the instructions.

To prevent injury:

• Make sure all body parts are clear of the

stroller when folding and unfolding.

• DO NOT place hot liquids in the cup holder.

Hot liquids can burn your child.

WARNING

Attaching Cup Holder

•Locate the knob on the side of the stroller.

•Fit the notch in the cup holder over the knob on the side rail and push

down until you hear a “click”. Pull up on the cup holder to be sure it

is secure.

Canopy and Sun Visor Adjustment

• The canopy and sun visor can be adjusted to an open or closed position.

Seat Recline Adjustment

•To recline seat: Push gray release buttons on BOTH sides of stroller at

the same time and allow the seat to fully RECLINE.

•To return upright: Push seat upwards until it automatically “CLICKS”

into place.

WARNING: Do not attempt to recline seat with child in stroller.

Release

Button

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Setup and Use

TO LOCK

TO UNLOCK

Rear Wheel Brakes

To lock the rear wheel brakes:

•Press both brake pedals down until they “click” into the locked position.

Make sure the brake pedals are pressed down completely.

•Always set both brake pedals whenever you park the stroller.

To unlock the rear wheel brakes:

•Lift both brake pedals until they “click” into the unlocked position.

Customer Service Tel. (646) 435-8726 www.deltachildren.com

SECURING CHILD

Securing Child

•Place your child in the stroller. Position the crotch belt between your

child’s legs.

•Pull shoulder straps over child’s arm and shoulder and fasten both strap

ends to the restraint system.

•Fasten both waist belts to the buckle on each side of the crotch belt.

Make sure you hear a “click” on both sides.

•Check to be sure the restraint system is securely attached by pulling it

away from your child. The restraint system should remain attached.

To tighten the waist belts and shoulder straps:

•Feed the anchored end of a waist belt up through the buckle to form a

loop A. Pull the free end of the waist belt B.

•Repeat this procedure to tighten the other waist belt.

•Feed the top end of the shoulder strap through the plastic stay to form

a loop . Pull the bottom end down to tighten the strap .

•Repeat this procedure to tighten the other shoulder strap.

To loosen the waist belts and shoulder straps:

•Feed the free end of the waist belt up through the buckle to form a

loop A. Enlarge the loop by pulling on the end of the loop toward the

buckle. Pull the anchored end of the waist belt to shorten the free end of

the waist belt B.

•Repeat this procedure to loosen the other waist belt.

•Feed the bottom end of the shoulder strap through the plastic stay to form

a loop . Pull the top end up to loosen the strap .

•Repeat this procedure to loosen the other shoulder strap.

Please note: After adjusting the restraint system to ﬁt your child, make sure

you pull on it to be sure it is securely fastened.

TIGHTEN

LOOSEN

5 Point Safety

Harness

•Tighten each waist belt and shoulder strap so that the restraint system is

snug against your child.

Please refer to the next section for instructions to tighten the waist belts.

Before Placing your Child in Stroller:

Close Canopy. Press both brake pedals down until they “click” into the locked position.

Make sure the brake pedals are pressed down completely.

Always set both brake pedals when parking the stroller.

Waist Belt

Crotch Belt

Restraint System

Customer Service Tel. (646) 435-8726 www.deltachildren.com

Storage

•Lift the front wheels toward the closed canopy.

•Slide the latch clip onto the side frame to secure in the folded

storage position.

•Storage position.

Latch Clip

Side Frame

Hint: Make sure canopy is in the closed position before folding the stroller.

1. With your foot, step on the Secondary Locking Mechanism.

2. Then with your foot, lift up on the Primary Locking Mechanism.

Primary Locking

Mechanism

Secondary Locking

Mechanism

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Paseante de Delta Children

Delta Children

Delta Children Jeep POWERGLYDE PLUS 11808 Manual de usuario

Delta Children

Delta Children Disney baby 61100-2344 Manual de usuario

Delta Children

Delta Children LX SIDE X SIDE Manual de usuario

Delta Children

Delta Children POWERGLYDE Jeep 11460 Manual de usuario

Delta Children

Delta Children PATRIOT OPEN TRAILS DELUXE JOGGER Manual de usuario

Delta Children

Delta Children CLASSIC TOUR Manual de usuario

Delta Children

Delta Children Jeep PowerGlide plus Manual de usuario

Delta Children

Delta Children Jeep Breeze Manual de usuario

Delta Children

Delta Children J is for Jeep Side x Side Destination Manual de usuario

Delta Children

Delta Children Jeep Scout Double Stroller Manual de usuario

Delta Children

Delta Children J is for Jeep Atlas AL Sport Manual de usuario

Delta Children

Delta Children OLYMPIA Little Folks LF11602 Manual de usuario

Delta Children

Delta Children The Clutch Manual de usuario

Delta Children

Delta Children Jeep Classic Jogger Manual de usuario

Delta Children

Delta Children Jeep 60008A Manual de usuario

Delta Children

Delta Children Jeep CLUTCH PLUS Manual de usuario

Delta Children

Delta Children Jeep SPORT UTILITY Manual de usuario

Delta Children

Delta Children Jeep 12597A Manual de usuario

Delta Children

Delta Children jeep EVEREST Manual de usuario

Delta Children

Delta Children Jeep WRANGLER DELUXE Manual de usuario

Delta Children

Delta Children CRUZER 11511 Manual de usuario

Delta Children

Delta Children Revolve 11898 Manual de usuario

Delta Children

Delta Children Jeep Arrow Manual de usuario

Delta Children

Delta Children The Clutch Manual de usuario

Manuales populares de Paseante de otras marcas

Hauck

Hauck Priya Trioset Manual de usuario

CHILDHOME

CHILDHOME CWQDN Manual de usuario

Dreamer Design

Dreamer Design Rebound GST Manual de usuario

Britax

Britax STEELCRAFT AGILE Manual de usuario

Graco

Graco 7427 Manual de usuario

Comfort

Comfort COMPASS Manual de usuario

OBaby

OBaby Aura Manual de usuario

Tutek

Tutek Tirso Manual de usuario

Babify

Babify Dual Plus Manual de usuario

Graco

Graco Stroller Manual de usuario

Special Tomato

Special Tomato Jogger Manual de usuario

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manual de usuario

Otto Bock

Otto Bock Kimba neo Manual de usuario

Milly Mally

Milly Mally ROYAL Guía de inicio rápido

Hauck

Hauck DUETT 3 PRAM Manual de usuario

BOB

BOB DUALLIE Manual de usuario

Nuna

Nuna Pepp Manual de usuario

Britax

Britax B2 Manual de usuario
