ECP3630

This short guide is not

intended to explain

all the functions

of the appliance.

Please read all the

owner’s instruction

booklet before use.

WELCOME

Introducing the exclusive world of espresso through the global leaders,

De’Longhi. Based in Treviso, Italy, we grew up appreciating the taste and

aroma of a good cup of coffee.

Discover the barista brewing inside you: now you can make authentic espressos,

lattes and cappuccinos to suit your taste, in the comfort of your kitchen. Enjoy!

1. Use freshly ground espresso.

2. Store coffee beans in a cool, dark and dry container.

Vacuum sealed if possible.

3. Pre-heat your espresso and cappuccino cups using the cup warmer

storage on the top of the machine.

Tips for Perfect Espresso

ECP3630

ESPRESSO DRINKS

Espresso

A small 1 or 2 oz. shot of

pressure brewed espresso using

approximately 1 Tbsp. of ﬁnely

ground coffee.

Cappuccino

A single espresso shot topped

with equal parts steamed and

frothed milk (in a ratio of 1:1:1)

served in a 4 to 6 ounce cup.

Café Latte

A double espresso shot topped

with steamed milk to ﬁll; a ratio of

2:1 of milk to espresso is typical.

Italian Macchiato

A single or double espresso

topped with a dollop of heated

milk and served in a traditional

espresso cup.

Espresso Lungo

From 3 oz. up to 4 oz. of

brewed espresso using ﬁnely

ground coffee.

Americano

/3of espresso lungo and

/3of hot water.

... more recipes at: coffeemakers.delonghi.us/coffee-recipes-0

Cafee’ Mocha

This drink is made from layers of

chocolate, milk, espresso and

cream. Prepare hot, frothed milk.

Let it cool. Pour the chocolate

sauce in a different glass,

carefully pour in the hot milk.

Slowly add brewed espresso.

Top off with whipped cream and

garnish with chocolate ﬂakes.

Caramel Macchiato

A tasty variation of latte macchiato

with the addition of caramel syrup.

Pour the caramel syrup down the

inside of the glass. Pour ﬁrst the

cold milk and then the whisked hot

milk into the glass. Add the milk

foam. Prepare the espresso and

pour it into the glass. Add a bonnet

of milk foam.

Ingredients: 1 oz. of espresso coffee

4 oz. of hot milk

1 – 2 tablespoons of cold

chocolate sauce

Whipped cream

Chocolate ﬂakes

Ingredients: 1 oz. of espresso coffee

1 oz. of cold milk

5 oz. of hot milk

Caramel syrup

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed,

including the following:

• Read all instructions.

• Do not touch hot surfaces. Use handles and knobs.

• To protect against ﬁre, electrical shock and personal injury, do not immerse cord, plug or

appliance in water or other liquid.

• Never allow the appliance to be used by children.

• Unplug from the outlet when not in use and before cleaning. Allow to cool before ﬁtting or

taking off parts, and before cleaning the appliance.

• Do not operate with a damaged cord or plug, or after the appliance malfunctions, or has

been damaged in any manner. Return the appliance to the nearest authorized service facility

for examination, repair or adjustment.

• The use of accessory attachments or spare parts not recommended by the appliance

manufacturer may result in ﬁre, electrical shock or personal injury.

• Do not use outdoors.

• Do not let the cord hang over the edge of the table or counter, or touch hot surfaces.

• Do not place on or near a hot gas or electrical burner, or in a heated oven.

• Plug cord into the wall outlet. To disconnect, turn any control to “off”, then remove plug

from wall outlet.

• Do not use the appliance for other than the intended use. This appliance is to be utilized

for domestic use only.

Any other use is to be considered improper and therefore, dangerous.

WARNING: To reduce the risk of ﬁre or electric shock, do not remove the

cover. No user serviceable parts inside. Repair should be done by autho-

rized service personnel only!

SAVE THESE INSTRUCTIONS

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY

ECP3630

Get Started &

Owner’s Instructions

Booklets

IN THE BOX

A1. Water tank lip and

ﬁlter storage

A2. Cup warmer/storage tray

A3. Control panel dial

A4. Boiler outlet

A5. Steam dial

A6. Steam spout / frother

A7. High glass tray

A8. Drip tray

A9. Water tank

B1. Filter holder

with 3 ﬁlter cups

B2. Tamper/dispenser

measure scoop

MACHINE SET UP

5Machine is now ready to work!

Note: This operation can take a few minutes.

The machine may vibrate.

When light

is green, turn dial

position

, let

about half the tank

discharge from the

boiler outlet.

Remove tank, ﬁll with water

and replace.

Place containers under boiler outlet

and cappuccino maker.

Turn dial to

position, red light is on

and unit is heating up.

Then turn the steam dial to the

position and discharge all the water

remaining in the tank from the cappuccino

maker. Turn the steam dial back to and the

selector dial to position to stop the ﬂow.

ECP3630

BREWING ESPRESSO Using Pre-Ground Espresso

Use correct ﬁlter,

base on one or

two cup.

Brew 1 or 2 Espresso at one time.

5A 7A

7B5B

CUP

CUPS

23 4

Tamp the coffee. Attach ﬁlter holder in

place into boiler outlet. Turn right to lock into

position.

When light is

green,

turn dial to

position

to start coffee

delivery. And when the

desired amount is

reached, turn back to

position to stop.

CUPS

CUP

see filter icon:

BREWING ESPRESSO

Using E.S.E. POD Espresso

Attach ﬁlter holder in

place into boiler outlet.

Turn right to lock into

position.

Use one cup ﬁlter.

1 2 3 4

E.S.E. (which stands for Easy Serving Espresso) is the

technology being used to simplify the preparation of a

good espresso using just a few simple actions, thanks

to the adoption of the “serving” (individual pre-packed

doses containing 7 grams of ground coffee that has

been pressed and hermetically sealed between two

ﬁne layers of ﬁlter paper).

Tamp the POD

into the ﬁlter.

When light is green, turn dial

to position

to start coffee delivery. And when the desired amount

is reached, turn back to

position to stop.

E.S.E. POD

ECP3630

BREWING CAPPUCCINO or HOT MILK

Refer to previous section BREWING ESPRESSO

for the espresso related part.

Fill 1/3 of the pitcher,

3.5 oz. for Cappuccino,

6 oz. for Hot Milk.

Tip for the BEST

CAPPUCCINO:

Use Skim or 2% Milk at Refrigerator

Temperature (about 41°F/5°C)

Be sure frother is

immersed in milk,

but not beyond the

highlighted mark

on the spout

Pour the milk over the

espresso and enjoy!

1B1A

CappuccinoHot Milk

Wait for light to turn on.

Turn the steam dial to

to stop the steam.

Turn steam dial to

to release the steam.

Turn dial to position, red light is

on and unit is heating up.

DOUBLE TRAY ACCOMODATES TALLER GLASSES

Standard drip tray for use with

espresso glasses.

To accomodate a taller glass,

remove the standard drip tray.

Inner drip tray

Up to a 5” glass can be placed onto

the

inner drip tray
