Dell Latitude 4310 Manual del propietario

Setup and Features Information

Front View

1ambient-light sensor

2camera (optional)

3camera-status light (optional)

4display

5microphone (optional)

6Dell Latitude ON™ button (optional)

7power button

8video connector (VGA)

9USB 2.0 connector

10 optical drive

11 volume-control buttons (3)

12 wireless switch

13 ExpressCard slot

14 fingerprint reader (optional)

15 contactless smart-card reader (optional)

16 memory-card slot

17 touchpad buttons (2)

18 touchpad

19 track-stick buttons (3)

20 track stick

21 keyboard

22 device-status lights

23 microphone

Regulatory Model: P05G Regulatory Type: P05G001

Dell™Latitude™4310

About Warnings

WARNING: A WARNING indicates a potential for

property damage, personal injury, or death.

March 2010

NOTE: Two microphones are available only if you purchase

a camera with the computer.

7JR5Tcc0.fm Page 1 Friday, January 22, 2010 10:42 AM

Back View

WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow

environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer

turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.

1network connector

2power and battery lights

3AC-adapter connector

4security-cable slot

5eSATA/USB 2.0 connector

6audio (line-out)/microphone (line-in) connector

7cooling vents

8smart-card slot

7JR5Tcc0.fm Page 2 Friday, January 22, 2010 10:42 AM

1Connect the AC adapter to the

AC-adapter connector on the

portable computer and to the

electrical outlet.

2Connect the network cable

(optional).

3Connect USB devices, such as a

mouse or keyboard (optional).

4Open the computer display and

press the power button to turn on

the computer.

NOTE: It is recommended that you turn on and shut down your computer at least

once before you install any cards or connect the computer to a docking device or

other external device, such as a printer.

Quick Setup

WARNING: Before you begin any of the

procedures in this section, read the safety

information that shipped with your

computer. For additional best practices

information, see

www.dell.com/regulatory_compliance.

WARNING: The AC adapter works with

electrical outlets worldwide. However,

power connectors and power strips vary

among countries. Using an incompatible

cable or improperly connecting the cable

to the power strip or electrical outlet may

cause fire or equipment damage.

CAUTION: When you disconnect the

AC adapter cable from the computer,

grasp the connector, not the cable itself,

and pull firmly but gently to avoid

damaging the cable. When you wrap the

AC adapter cable, ensure that you follow

the angle of the connector on the

AC adapter to avoid damaging the cable.

NOTE: Some devices may not be

included if you did not order them.

7JR5Tcc0.fm Page 3 Friday, January 22, 2010 10:42 AM

Specifications

NOTE: Offerings may vary by region. For more information regarding

the configuration of your computer, click Start→Help and Support

and select the option to view information about your computer.

System Information

Processor type Intel®Core™ i5

Intel Core i7

Chipset Intel 5-Series chipset

Memory

Memory module connector two SODIMM sockets

Memory module capacity 1 GB, 2 GB, or 4 GB

Memory type DDR3, 1066 MHz

Minimum memory 1 GB

Maximum memory 8 GB

NOTE: Memory greater than 4 GB

is supported by 64-bit operating

systems only.

Video

Video type integrated on system board

Video controller Intel HD graphics

Contactless Smart Card

Supported Smart

Cards/Technologies

ISO14443A — 106 kbps, 212 kbps,

424 kbps, and 848 kbps

ISO14443B — 106 kbps, 212 kbps,

424 kbps, and 848 kbps

ISO15693

HID iClass

FIPS201

NXP Desfire

Battery

Type 3-cell, 2.8 AHr, 30 WHr

6-cell, 2.8 AHr and above, 60 WHr

6-cell, 2.5 AHr long life, 54 WHr

battery slice, 48 WHr

Dimensions:

Depth 3-cell

— 28.80 mm (1.13 inches)

6-cell — 51.10 mm (2.01 inches)

Height

21.90 mm (0.86 inches)

Width

189.80 mm (7.47 inches)

Weight 3-cell — 0.19 kg (0.42 lb)

6-cell — 0.34 kg (0.75 lb)

battery slice — 0.63g (1.39 lb)

Voltage 11.1 VDC

Temperature range:

Operating

0 °C to 35 °C (32 °F to 95 °F)

Storage

–40 °C to 70 °C (–40 °F to 158 °F)

Coin-cell battery 3 V CR2032 lithium

7JR5Tcc0.fm Page 4 Friday, January 22, 2010 10:42 AM

AC Adapter

Input voltage 100–240 VAC

Input current (maximum) 1.5 A

Input frequency 50–60 Hz

Output power 65 W

Output current 4.34 A (maximum at 4-second pulse)

3.34 A (continuous)

Output voltage 19.5 +/– 1.0 VDC

Dimensions:

Width

66 mm (2.60 inches)

Height

16 mm (0.63 inches)

Depth

217 mm (8.54 inches)

Temperature range:

Operating

0 °C to 35 °C (32 °F to 95 °F)

Storage

–40 °C to 70 °C (–40 °F to 158 °F)

Physical

Front height 25.40 mm–26.50 mm (1.00–1.04 inches)

Back height 30.55 mm–31.65 mm (1.20–1.24 inches)

Width 323 mm (12.72 inches)

Depth 215 mm (8.47 inches)

Weight 1.56 kg–1.77 kg (3.44 lb–3.90 lb)

Environmental

Temperature range:

Operating

0 °C to 35 °C (32 °F to 95 °F)

Storage

–40 °C to 70 °C (–40 °F to 158 °F)

Relative humidity (maximum):

Operating

10 % – 90 % (noncondensing)

Storage

5 % – 95 % (noncondensing)

Altitude (maximum):

Operating

–15.2 m to 3048 m (–50 ft to 10,000 ft)

Storage

–15.2 m to 10,668 m (–50 ft to 35,000 ft)

7JR5Tcc0.fm Page 5 Friday, January 22, 2010 10:42 AM

Finding More Information and Resources

See the safety and regulatory documents that shipped with your computer

and the regulatory compliance website at

www.dell.com/regulatory_compliance for more information on:

• Safety best practices

• Warranty

•TermsandConditions

• Regulatory certification

• Ergonomics

• End User License Agreement

________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written

permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, Latitude, and Latitude ON are

trademarks of Dell Inc.; Intel is a registered trademark and Core is a trademark

of Intel Corporation in the U.S. and other countries.

Other trademarks and trade names may be used in this document to refer to either

the entities claiming the marks and names or their products. Dell Inc. disclaims

any proprietary interest in trademarks and trade names other than its own.
