Dell XPS L701X Manual de usuario

Dell™ XPS™ L701X Service

Manual

Regulatory model: P09E series Regulatory type: P09E001

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

____________________

Information in this document is subject to change without notice.

Trademarks used in this text: Dell™, the Dell logo, and XPS™ are trademarks of Dell Inc.; Microsoft®,

Windows® and the Windows start button logo

are either trademarks or registered trademarks of

Microsoft corporation in the United States and/or other countries; Bluetooth®is a registered trademark

owned by Bluetooth SIG, Inc. and is used by Dell Inc. under license.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Regulatory model: P09E series Regulatory type: P09E001

October 2010 Rev. A00

Contents 3

Contents

1 Before You Begin. . . . . . . . . . . . . . . . . . . . 9

Recommended Tools. . . . . . . . . . . . . . . . . . . . 9

Turning Off Your Computer. . . . . . . . . . . . . . . . . 9

Before Working Inside Your Computer . . . . . . . . . 10

2Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Removing the Battery . . . . . . . . . . . . . . . . . . 13

Replacing the Battery . . . . . . . . . . . . . . . . . . 14

3 Module Cover . . . . . . . . . . . . . . . . . . . . . 15

Removing the Module Cover. . . . . . . . . . . . . . . 15

Replacing the Module Cover . . . . . . . . . . . . . . 16

4 Memory Module(s) . . . . . . . . . . . . . . . . . 17

Removing the Memory Module(s) . . . . . . . . . . . . 17

Replacing the Memory Module(s). . . . . . . . . . . . 18

5 Wireless Mini-Card(s) . . . . . . . . . . . . . . . 21

Removing the Mini-Card(s) . . . . . . . . . . . . . . . 21

4Contents

Replacing the Mini-Card(s) . . . . . . . . . . . . . . . 23

6 Hard Drive(s) . . . . . . . . . . . . . . . . . . . . . 27

Removing the Hard Drive(s) . . . . . . . . . . . . . . . 27

Replacing the Hard Drive(s) . . . . . . . . . . . . . . . 30

7 Optical Drive . . . . . . . . . . . . . . . . . . . . . 33

Removing the Optical Drive . . . . . . . . . . . . . . . 33

Replacing the Optical Drive . . . . . . . . . . . . . . . 34

8 Palm-Rest Assembly . . . . . . . . . . . . . . . 37

Removing the Palm-Rest Assembly . . . . . . . . . . . 37

Replacing the Palm-Rest Assembly . . . . . . . . . . . 40

9 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . 43

Removing the Keyboard . . . . . . . . . . . . . . . . . 43

Replacing the Keyboard . . . . . . . . . . . . . . . . . 45

10 Power-Button Board . . . . . . . . . . . . . . . 47

Removing the Power-Button Board . . . . . . . . . . . 47

Replacing the Power-Button Board . . . . . . . . . . . 48

Contents 5

11 Coin-Cell Battery . . . . . . . . . . . . . . . . . . . 51

Removing the Coin-Cell Battery . . . . . . . . . . . . . 51

Replacing the Coin-Cell Battery. . . . . . . . . . . . . 52

12 Internal Card With Bluetooth®Wireless

Technology . . . . . . . . . . . . . . . . . . . . . . . 55

Removing the Bluetooth Card . . . . . . . . . . . . . . 55

Replacing the Bluetooth Card . . . . . . . . . . . . . . 56

13 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Display Assembly . . . . . . . . . . . . . . . . . . . . 59

Removing the Display Assembly . . . . . . . . . . 59

Replacing the Display Assembly . . . . . . . . . . 62

Display Bezel . . . . . . . . . . . . . . . . . . . . . . 63

Removing the Display Bezel . . . . . . . . . . . . 63

Replacing the Display Bezel . . . . . . . . . . . . 64

Display Panel . . . . . . . . . . . . . . . . . . . . . . 64

Removing the Display Panel . . . . . . . . . . . . 64

Replacing the Display Panel . . . . . . . . . . . . 66

Display Cable . . . . . . . . . . . . . . . . . . . . . . 67

Removing the Display Cable . . . . . . . . . . . . 67

Replacing the Display Cable . . . . . . . . . . . . 68

Display-Panel Brackets . . . . . . . . . . . . . . . . . 69

Removing the Display-Panel Brackets . . . . . . . 69

Replacing the Display-Panel Brackets . . . . . . . 70

6Contents

14 Camera Module . . . . . . . . . . . . . . . . . . . 73

Removing the Camera Module. . . . . . . . . . . . . . 73

Replacing the Camera Module . . . . . . . . . . . . . 76

15 Top Cover . . . . . . . . . . . . . . . . . . . . . . . . 79

Removing the Top Cover . . . . . . . . . . . . . . . . . 79

Replacing the Top Cover . . . . . . . . . . . . . . . . . 84

16 Subwoofer . . . . . . . . . . . . . . . . . . . . . . . 87

Removing the Subwoofer . . . . . . . . . . . . . . . . 87

Replacing the Subwoofer . . . . . . . . . . . . . . . . 88

17 AC-Adapter Connector . . . . . . . . . . . . . 91

Removing the AC-Adapter Connector . . . . . . . . . . 91

Replacing the AC-Adapter Connector . . . . . . . . . . 93

18 Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Removing the Fan . . . . . . . . . . . . . . . . . . . . 95

Replacing the Fan . . . . . . . . . . . . . . . . . . . . 97

19 Heat Sink . . . . . . . . . . . . . . . . . . . . . . . . 101

Removing the Heat Sink . . . . . . . . . . . . . . . . 101

Contents 7

Replacing the Heat Sink . . . . . . . . . . . . . . . . . 103

20 Processor Module . . . . . . . . . . . . . . . . . 107

Removing the Processor Module . . . . . . . . . . . . 107

Replacing the Processor Module . . . . . . . . . . . . 109

21 I/O Board . . . . . . . . . . . . . . . . . . . . . . . . 111

Removing the I/O Board . . . . . . . . . . . . . . . . . 111

Replacing the I/O Board . . . . . . . . . . . . . . . . . 113

22 TV Antenna Connector . . . . . . . . . . . . . 115

Removing the TV Antenna Connector . . . . . . . . . . 115

Replacing the TV Antenna Connector . . . . . . . . . . 117

23 USB Board . . . . . . . . . . . . . . . . . . . . . . . 119

Removing the USB Board . . . . . . . . . . . . . . . . 119

Replacing the USB Board . . . . . . . . . . . . . . . . 120

24 System Board . . . . . . . . . . . . . . . . . . . . 123

Removing the System Board . . . . . . . . . . . . . . . 123

Replacing the System Board. . . . . . . . . . . . . . . 125

Entering the Service Tag in the BIOS . . . . . . . . . . 127

8Contents

25 Speakers . . . . . . . . . . . . . . . . . . . . . . . . 129

Removing the Speakers . . . . . . . . . . . . . . . . 129

Replacing the Speaker. . . . . . . . . . . . . . . . . 131

26 Flashing the BIOS . . . . . . . . . . . . . . . . . 133

Before You Begin 9

Before You Begin

This manual provides procedures for removing and installing the components

in your computer. Unless otherwise noted, each procedure assumes that the

following conditions exist:

• You have performed the steps in "Turning Off Your Computer" on page 9

and "Before Working Inside Your Computer" on page 10.

• You have read the safety information that shipped with your computer

• A component can be replaced or—if purchased separately—installed by

performing the removal procedure in reverse order.

Recommended Tools

The procedures in this document may require the following tools:

• Small flat-blade screwdriver

•Phillipsscrewdriver

•Plasticscribe

• BIOS executable update program available at

support.dell.com

Turning Off Your Computer

CAUTION: To avoid losing data, save and close all open files and exit all open

programs before you turn off your computer.

Save and close all open files and exit all open programs.

To shut down the operating system, click

Start

and then click

Shut

Down

Ensure that the computer is turned off. If your computer did not

automatically turn off when you shut down the operating system, press

and hold the power button until the computer turns off.

10 Before You Begin

Before Working Inside Your Computer

Use the following safety guidelines to help protect your computer from

potential damage and to help to ensure your own personal safety.

WARNING: Before working inside your computer, read the safety information

that shipped with your computer. For additional safety best practices information,

see the Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance.

CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist

grounding strap or by periodically touching an unpainted metal surface (such as a

connector on your computer).

CAUTION: Handle components and cards with care. Do not touch the components

or contacts on a card. Hold a card by its edges or by its metal mounting bracket.

Hold a component such as a processor by its edges, not by its pins.

CAUTION: Only a certified service technician should perform repairs on your

computer. Damage due to servicing that is not authorized by Dell™ is not covered

by your warranty.

CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,

not on the cable itself. Some cables have connectors with locking tabs; if you are

disconnecting this type of cable, press in on the locking tabs before you

disconnect the cable. As you pull connectors apart, keep them evenly aligned to

avoid bending any connector pins. Also, before you connect a cable, ensure that

both connectors are correctly oriented and aligned.

CAUTION: To avoid damaging the computer, perform the following steps before

you begin working inside the computer.

Ensure that the work surface is flat and clean to prevent the computer

cover from being scratched.

Turn off your computer (see "Turning Off Your Computer" on page 9) and

all attached devices.

CAUTION: To disconnect a network cable, first unplug the cable from your

computer and then unplug the cable from the network device.

Disconnect all telephone or network cables from the computer.

Press and eject any installed cards from the Media Card Reader.

Disconnect your computer and all attached devices from their electrical

outlets.
