Dell 2000 Manual del propietario

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

Template Last Updated - 01/02/2008

About Warnings

WARNING: A WARNING indicates a potential for property damage, personal injury or

death.

Dell™ Latitude™ 2000

Setup and Features Information

1 camera status light 2 web camera

3 display 4 keyboard status lights (3)

March 2009

0XXXXXAXX

Model P02T series

Signoff.fm Page 1 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

5 power button 6 security cable slot

7 AC adapter connector 8 network connector

9 USB connectors (2) 10 cooling vents

11 3-in-1 memory card reader 12 touch pad

13 microphone 14 device status lights (4)

15 media controls (volume down,

volumn up and mute) (3)

1 usage mode indication 2 audio connectors (2)

3 USB connector 4 cooling vents

5 video connector 6 security cable slot

Signoff.fm Page 2 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do

not store your Dell™ computer in a low-airflow environment, such as a closed briefcase, while it

is running. Restricting the airflow can damage the computer or cause a fire. The computer turns

on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with

the fan or the computer.

Quick Setup

WARNING: Before you begin any of the procedures in this section, read the safety information

that shipped with your computer. For additional best practices information see

www.dell.com/regulatory_compliance.

WARNING: The AC adapter works with electrical outlets worldwide. However, power

connectors and power strips vary among countries. Using an incompatible cable or improperly

connecting the cable to the power strip or electrical outlet may cause fire or equipment damage.

CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector,

not the cable itself, and pull firmly but gently to avoid damaging the cable. When you wrap the AC

adapter cable, ensure that you follow the angle of the connector on the AC adapter to avoid

damaging the cable.

NOTE: Some devices may not be included if you did not order them.

Connect the AC adapter to the AC

adapter connector on the computer and to

the electrical outlet.

Connect the network cable.

Signoff.fm Page 3 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

NOTE: It is recommended that you turn on and shut down your computer at least once before you

install any cards or connect the computer to a docking device or other external device, such as a

printer.

Specifications

NOTE: Offerings may vary by region. For more information regarding the configuration of your

computer, click Start→Help and Support and select the option to view information about your

computer.

Connect USB devices, such as a mouse or

keyboard.

Open the computer display and press

the power button to turn on the

computer.

System Information

Processor type Intel®Atom™ Processor

Chipset Intel 945GSE Chipset

Video

Video type integrated UMA graphics on the system board

Data bus

integrated video

Video controller

Intel®Gen 3.5 Integrated Graphics Engine

Battery

Type 6-cell "smart" lithium ion

3-cell "smart" lithium ion

Dimensions:

6-cell lithium-ion batteries:

Depth

48.13 mm (1.9 inches)

Signoff.fm Page 4 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

Height

42.46 mm(1.67 inches)

Width

204 mm (8.03 inches)

3-cell lithium-ion batteries:

Depth

40.50 mm (1.59 inches)

Height

23.24 mm (0.92 inches)

Width

204 mm (8.03 inches)

Weight

6-cell lithium-ion batteries

Minimum Weight — 0.34 kg (0.749 lbs)

Maximum Weight — 0.35 kg (0.771 lbs)

3-cell lithium-ion batteries

Minimum Weight — 0.185 kg (0.407 lbs)

Maximum Weight — 0.190 kg (0.418 lbs)

Voltage 11.1 VDC (6-cell and 3-cell)

Temperature range:

Operating

0° to 35° C (32° to 95° F)

Storage

–40° to 60° C (–40° to 149° F)

Coin-cell battery CR 2032

AC Adapter

Input voltage 100–240 VAC

Input current (maximum) 1.5 A

Input frequency 50–60 Hz

Output current

65W

4.34 A (maximum at 4-second pulse);

3.34 A (continuous)

90W

5.62A (maximum at 4-seconds pulse)

4.62A (continuous)

Output power 65 W or 90 W

Rated output voltage 19.5 +/–1.0 VDC

Dimensions:

65W

Height

28.3 mm (1.11 inches)

Battery (continued)

Signoff.fm Page 5 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

Width

137.2 mm (5.40 inches)

Depth

57.8 mm (2.27 inches)

90W

Height

34.2 mm (1.35 inches)

Width

60.87 mm (2.4 inches)

Depth

153.45 mm (6.04 inches)

Temperature range:

Operating

0° to 35° C (32° to 95° F)

Storage

–40° to 65° C (–40° to 149° F)

Physical

Height 22.5 mm to 39.9 mm (0.89 inches to 1.57 inches)

without touch screen

24.1 mm to 41.5 mm (0.95 inches to 1.63 inches)

with touch screen

Width 265 mm (10.43 inches) with/without touch screen

Depth 187 mm (7.36 inches) with/without touch screen

Weight (3-cell battery without touch

screen)

1.36 Kg (3.0 lb)

Environmental

Temperature range:

Operating

0° to 35° C (32° to 95° F)

Storage

–40° to 65° C (–40° to 149° F)

Relative humidity (maximum):

Operating

10% to 90% (noncondensing)

Storage

5% to 95% (noncondensing)

Altitude (maximum):

Operating

–15.2 to 3048 m (–50 to 10,000 ft)

Storage

–15.2 to 10,668 m (–50 to 35,000 ft)

AC Adapter (continued)

Signoff.fm Page 6 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

Finding More Information and Resources

________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is

strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and Latitude are trademarks of Dell Inc.; Intel is a

registered trademark and Atom is a trademark of Intel Corporation in the U.S. and other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade

names other than its own.

If you need to: See:

Find safety best practices information for your

computer, review Warranty information, Terms and

Conditions(U.S only), Safety instructions,

Regulatory information, Ergonomics information,

and End User License Agreement.

The safety and regulatory documents that

shipped with your computer and see the

Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance.

Signoff.fm Page 7 Wednesday, February 11, 2009 10:38 PM

FILE LOCATION: C:\Documents and Settings\marcelle_britto\Desktop\ME\Business

Client\SFITS\Welch\SFITS\A00\EN\Source\Signoff.fm

DELL CONFIDENTIAL – PRELIMINARY 2/11/09 – FOR PROOF ONLY

Signoff.fm Page 8 Wednesday, February 11, 2009 10:38 PM

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions

(1)This device may not cause harmful interference and

(2)This device must accept any interference received, including interference that may cause undesired operation

Any changes or modifications (including the antennas ) made to this device that are not expressly approved by the

manufacturer may void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of

the FCC rules. These limits are designed to provide to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the installation. , May cause harmful interference to radio communication. However, there is

no guarantee that interference

Will not occur in a particular installation. if this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

-Reorient or relocate the receiving antenna

-Increase the separation between the equipment and receiver

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

-Consult the dealer or an experienced radio / TV technician for help

FCC RF radiation exposure statement:

this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter .
