Dell 5000 Series Manual de usuario

Dell Edge Gateway

5000 Series

Installation and Operation Manual

Regulatory Model: N01G\N02G

Regulatory Type: N01G001\N02G001

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss

of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

the United States and/or other jurisdictions. All other marks and names mentioned herein may

be trademarks of their respective companies.

2016 - 01

Rev. A001

Contents

1 Overview............................................................................................ 5

2 System Features............................................................................... 6

System LEDs......................................................................................8

DIP switches......................................................................................9

3 Setting up your Dell Edge Gateway............................................10

Professional installation instructions..........................................11

Instructions d'installation professionnelles...............................12

Federal Communication Commission Interference

Statement.........................................................................................12

Industry Canada Statement..........................................................13

Powering on the Dell Edge Gateway ........................................16

Mounting the Dell Edge Gateway on the wall................... 16

Mounting the Dell Edge Gateway on a DIN rail.................19

Inserting a micro-SIM card and activating your

mobile broadband................................................................... 22

Removing the micro-SIM card....................................................24

4 Setting up your operating system.............................................. 25

Windows 10 LTSB...........................................................................25

Ubuntu Snappy...............................................................................25

Wind River Linux.............................................................................25

5 Specifications - Gateway..............................................................27

6 I/O Module Overview....................................................................30

Features............................................................................................ 31

Setting up the I/O Module........................................................... 32

Specifications - I/O Module.........................................................37

5000 Series 3

7 Power Module Overview.............................................................. 41

Features............................................................................................42

Setting up the Power Module..................................................... 43

Power module — Connecting a battery..............................47

Specifications - Power Module.................................................. 49

8 Enclosure Overview...................................................................... 52

Features............................................................................................53

Setting up the Enclosure..............................................................54

Specifications - Enclosure............................................................61

9 Setting up the ZigBee Dongle .................................................... 63

10 Contacting Dell............................................................................65

5000 Series 4

Overview

The Dell Edge Gateway 5000/5100 series allows you to connect (wired or wireless)

to network enabled devices and manage them remotely in your existing network

ecosystem. The system can be either mounted on the wall using the Dell approved

wall mount kit or mounted into your existing rack infrastructure using the DIN-rail

mounting bracket. The system is running on Windows 10 Enterprise, Ubuntu

Snappy, and Wind River Linux operating systems. As part of a complete

interoperable building automation system, Edge Gateway provides precise

monitoring and control of connected points. I/O expansion module provide the

Edge Gateway with additional inputs and output module. The power expansion

module provide the Edge Gateway with power redundancy options by allowing you

to connect a 24V AC/DC, a 19.5V DC, and a battery backup simultaneously.

If the Edge Gateway is setup as a web server, it offers the capability for

configuration from a web browser. Configure I/Os, set-up objects, and monitor

present values via a browser.

Overview 5

System Features

Feature

1. USB 2.0 port For USB 2.0 devices

2. USB 2.0 port For USB 2.0 devices

3. HDMI port Connect a Monitor or another HDMI‑in

enabled device. Provides video and audio

output.

4. Wi-Fi antenna port (port four) Connect an antenna to increase the range

and strength of the Wi-Fi signals.

5. Intrusion detection connector Connect a TPB based security device to

detect any intrusion into the system.

6. Wireless antenna port (port

three)

Connect an antenna to increase the range

and strength of the Wi-Fi signals.

System Features 6

Feature

7. Mobile broadband antenna port

(port two)

Connect an antenna to increase the range

and strength of the mobile broadband

signals.

8. Micro-SIM card slot Insert a micro-SIM card to connect to a

mobile broadband network.

9. Mobile broadband antenna port

(port one)

Connect an antenna to increase the range

and strength of the mobile broadband

signals.

10. Power module expansion port Connect an external power module for

increased power options.

11. +24V AC/DC power Phoenix

connector

Connect a +24V AC/DC power connector

to provide power to your system

12. +19.5 VDC power adapter port Connect a +19.5 VDC power adapter

connector to provide power to your

system

13. Power button Press and hold for 2 seconds to turn on

the system if it is turned off.

14. Earth ground Connect the grounding cable to the

system

15. Serial port Connect to a serial port enabled device

like printers and so on.

16. CANbus port Connect to a CANbus port enabled device

or dongles.

17. RS422/485 port Connect a RS422/485 device.

18. RS485 port Connect a RS422 device.

19. RS485 port Connect a RS485 device.

20. USB 3.0 port For USB 3.0 devices

21. Network port Connect an Ethernet (RJ45) cable from a

router or a broadband modem for network

or internet access.

22. Network port Connect an Ethernet (RJ45) cable from a

router or a broadband modem for network

or internet access.

System Features 7

Feature

23. I/O expansion port Connect an external expansion module for

additional I/O ports.

Topics:

• System LEDs

• DIP switches

System LEDs

Feature

1. Serial port status LED Provide the status of the serial port

connection.

2. CANbus port status LED Provide the status of the CANbus port

connection.

3. RS422/485 port status LED Provide the status of the RS422/485 port

connections.

4. RS485 port status LED Provide the status of the RS485 port

connections.

5. RS485 port status LED Provide the status of the RS485 port

connections.

6. Network status LED Indicates the connectivity status and

network activity.

7. Network status LED Indicates the connectivity status and

network activity.

8. Power status LED Indicates the power‑state of the system.

9. Mobile broadband status LED Indicates the mobile broadband status and

network activity.

System Features 8

Feature

10. Wireless status LED Indicates the wireless connectivity status

and network activity.

11. Bluetooth status LED Indicates the bluetooth status and activity.

12. Cloud connection status LED Indicates the cloud connection status.

DIP switches

Feature

1. RS422/RS485 port toggle switch Toggle between RS422 or RS485 standard

2. RS422/RS485 port resistor

switch

Enable/disable the differential termination

resistor

3. RS422/RS485 port bias resistor

switch

Enable/disable the bias resistor for the

RS422/RS485 port

4. RS422/RS485 port diagnostic

switch

Enable or disable the RS422/RS485 port

5. RS485 port resistor switch Enable/disable the differential termination

resistor for RS485

6. RS485 port bias resistor switch Enable/disable the bias resistor for the

RS485 port

7. RS485 port resistor switch Enable/disable the differential termination

resistor for RS485

8. RS485 port bias resistor switch Enable/disable the bias resistor for the

RS485 port

System Features 9

Setting up your Dell Edge

Gateway

WARNING: Before you begin any of the procedures in this section, read the

safety information that shipped with your system. For additional best

practices information, go to www.dell.com/regulatory_compliance.

WARNING: When installing the Gateway, the responsible party or integrator

shall use the AC Adapter provided with the Dell Edge Gateway, or connect to a

24Vac or 24Vdc power source already present as part of the clients

installation.

WARNING: The Dell AC Adapter (full-wave rectified and have no built-in

isolation transformer) is acceptable for use up to ambient temperature of

40°C and is a limited power source, SELV/Limited Energy Circuit, Class 2

power source. If ambient temperature of the installation exceeds 40 °C then

use the 24Vac or 24Vdc power available as part of the installation.

WARNING: Always make sure that the available power source matches the

required input power of the Dell Edge Gateway, check the input power

markings next to power connector(s) before making connections. The 24 V

power source must be compliant with local Electrical Codes and Regulations.

WARNING: To ensure the protection provided by Dell Edge Gateway is not

impaired, do not use or install the system in any manner other than that which

is specified in this manual.

WARNING: When installing the Gateway use acable appropriate for the load

currents: 3-core cable rated 5 A at 90 °C (194 °F) minimum, which conform to

either IEC 60227 or IEC 60245. The system accepts cables from 0.8 to 2.5 mm

(18 to 14 AWG).

WARNING: The symbol indicates hot surface or adjacent hot surface that

can obtain temperature during normal use that can cause a burn. Allow

equipment to cool off or use protective gloves when handling to reduce risk

of a burn.

WARNING: If a battery is included as part of System/Network, battery must be

must be installed with appropriate enclosure in accordance with local Fire and

Electrical Codes and Laws.

Setting up your Dell Edge Gateway 10

Otros manuales para 5000 Series

Tabla de contenidos

Otros manuales de Puerta de Dell

Dell

Dell Dell Edge Gateway 3002 Manual de usuario

Dell

Dell Edge Gateway 3000 Series Manual de usuario

Dell

Dell PowerConnect J-Series Manual de usuario

Dell

Dell Edge Gateway 5000 Series Manual de usuario

Dell

Dell Edge Gateway 5000 Series Manual de usuario

Dell

Dell Edge 3000 Series Manual de usuario

Dell

Dell PowerConnect J-SRX100 Instrucciones de instalación

Dell

Dell J-SRX210B Manual de usuario

Dell

Dell Edge 3001 Manual de usuario

Dell

Dell Edge 5100 Series Manual de usuario

Dell

Dell Dell Edge Gateway 3002 Manual de usuario

Dell

Dell EMC Edge Gateway 5200 Manual de usuario

Dell

Dell SonicWall SRA 4200 Manual de servicio

Dell

Dell iDRAC 8 Manual de usuario

Dell

Dell Latitude 3000 Series Manual de usuario

Dell

Dell PowerConnect J-SRX210 Instrucciones de instalación

Dell

Dell PowerConnect J-SRX100SU Manual de usuario

Dell

Dell Edge Gateway 5000 Series Manual de usuario

Dell

Dell 5000 Series Manual de usuario

Dell

Dell EMC SD-WAN Edge 600 Series Manual de usuario

Dell

Dell EMC Edge 3200 Manual de usuario

Dell

Dell EMC Edge Gateway 3200 Manual de usuario

Dell

Dell Edge 3000 Series Manual de usuario

Dell

Dell EMC Edge Gateway 5200 Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
