Dell Wyse C10LE Guía de instalación

Small size. Big performance. Here:

Dell Wyse C class

Dell Wyse C class:

Your desktop just got bigger

Wyse

ContactStart Technical PrintModels

Small size.

Big performance.

Meet the Dell Wyse C class.

Combining small size and excellent

performance, it sets a new benchmark

in cloud client computing.

Seven models are available featuring:

Dell Wyse ThinOSTM, Microsoft Windows CE,

Dell Wyse enhanced SUSE Linux,

Windows Embedded Standard 2009 and

Windows Embedded Standard 7 operating

systems – and Dell Wyse WSM.

Features

Dell Wyse

C10LE

Featuring the

blisteringly

fast Dell Wyse

ThinOS designed

for high security

environments.

Dell Wyse

C30LE

Windows CE 6 –

Microsoft’s

componentized

real-time operating

system for small

footprint devices.

Dell Wyse

C50LE

Flexibility and

security in an

easy to manage

Linux platform.

Dell Wyse

C90LEW

Take advantage

of the power

of Microsoft

Windows

Embedded

Standard 2009.

Dell Wyse

C90LE7

Harnesses

the rich user

experience

of Microsoft

Windows

Embedded

Standard 7.

Introducing the Dell Wyse C class

dellwyse.com

Compact, clever, capable.

Creating highly productive, fully functional and compact cloud client computing

desktops has never been easier. C class features full support for the Dell Wyse TCX™

Suite of virtualization software – that includes multiple display support, multimedia &

Flash playback, rich audio and USB peripheral connectivity – and Dell Wyse WSM™

cloud PC provisioning software delivering a full PC experience.

Connectivity

Performance Mounting options

Microsoft Windows CE

Dell Wyse enhanced

SUSE LinuxDell Wyse ThinOS

Dell

Wyse

ThinOS

Cool performance. Cooler workspaces.

Designing these levels of high processing and graphics performance into such

a compact space hasn’t been at the expense of energy consumption and heat

emissions either. Each C class draws under 7 watts of power – creating cooler

working environments – in every respect.

Learn more. Simply click the datasheets below.

Green Management

User experience

acceleration

User experience

optimization

Cloud PC provisioning

Microsoft Windows

Embedded Standard 2009

Microsoft Windows

Embedded Standard 7

ContactStart Technical PrintModels Features

Features Dell Wyse C class

Take a tour of

the C class

dellwyse.com

ContactStart Technical PrintModels Features

Performance

Continue tour

High performance.

Inside out.

Inside every compact, Dell Wyse C class lies a

punchy VIA C7 1 GHz processor and an advanced

hardware media accelerator delivering rich multimedia

and video playback up to 1080p HD resolution.

Outside, you’ll ﬁnd advanced DVI-I display

connectivity for one or two displays, four free

USB 2.0 ports, PS/2 ports for keyboard and mouse,

gigabit Ethernet and optional WiFi (b/g/n) support.

C class supports the Dell Wyse TCX software suite

of user-experience enhancements and WSM

cloud PC provisioning software. VIA C7 1 GHz

processor

Plus advanced best

performance per

watt hardware

media accelerator

dellwyse.com

ContactStart Technical PrintModels Features

Connectivity Dell Wyse C class family

Continue tour

Well connected

Dell Wyse C10LE, C30LE, C50LE, C90LEW and C90LE7 thin clients

DVI-I Video output

Two PS/2 ports for keyboard and mouse

Wi-ﬁ antenna connector for optional 802.11 b/g/n*

Kensington lock slot

10/100/1000 Base-T ethernet port

Four available external USB 2.0 ports (2 front; 2 back)

Audio out: 1/8-inch mini jack, 16 bit stereo

Audio in: 1/8-inch mini jack, 8 bit stereo microphone

* C10LE factory option supports 802.11 a/b/g/n

internal wireless (dual-band, dual antenna) with

2 front USB ports and no rear USB ports.

C50LE does not support wireless connectivity.

dellwyse.com

ContactStart Technical PrintModels Features

Mounting options

Continue tour

Fits around you

On the desk or out of sight; Dell Wyse C class ﬁts around you.

Every C class thin client includes a monorail mount that lets you choose

how and where to ﬁt it: horizontally, vertically, directly to walls, under

desks... and even ﬁtted discretely to the rear of standard desktop displays. Back of monitor or

wall mounting

An optional VESA mount bracket

enables mounting to the rear of

a monitor (this requires the four

industry standard mounting points

to be free). The same bracket can

be used for wall mounting.

Desktop

Sturdy feet for

simple horizontal

desktop installation.

dellwyse.com

ContactStart Technical PrintModels Features

Desktop-computing Without compromise

Start the tour again

* Average power usage with device connected

to 1 keyboard, 1 PS/2 mouse, and 1 monitor.

That’s Dell Wyse

EarthSmart™computing

Every Dell Wyse C class model is EnergyStar certiﬁed, a recognized sign

of energy eciency. Through our EarthSmart computing initiative we

are committed to helping organizations implement a greener computing

strategy – one that delivers a more ecient and productive computing

experience for your users with a positive eect on energy wastage,

heat and carbon emissions.

Energy ecient

Each fanless C class cloud client draws just under 7 watts* of power

and creates very little heat as a result – contributing to cooler, quieter

user work environments, a greatly reduced carbon footprint and huge

savings in energy costs when compared to equivalent PC desktops.

Dell Wyse has introduced an ISO 14001 based environmental

management system and WEEE recycling processes, and all

products meet stringent RoHS Dell Wyse requirements.

dellwyse.com

More information

Download carbon calculators, fact sheets

and white papers from here:

www.dellwyse.com/green

ContactStart Technical PrintModels Features

Thin client management Dell Wyse Device Manager

Continue tour

Dell Wyse Device Manager (WDM) addresses key management

requirements for deploying powerful thin clients. With its centralized

management and administration WDM helps IT departments deliver

eective remote thin client support while minimizing end user downtime.

Security is assured with HTTPS based imaging, updates and downloads.

WDM delivers organization-wide beneﬁts:

Operations Centralized management.

Collect and organize asset information.

Administration Health status reports.

Automated client settings.

Update client ﬁrmware and add applications.

End User IT Costs Easy, eective remote support.

Create custom scripts and packages.

Minimize downtime Restart or reset thin clients in less than a minute.

Enforce policies. Minimize user errors.

At a glance features

• Security

HTTPS based imaging / updates

Fully encrypted network trac

Delegated admin access (MS AD) support

• No-Hassle deployment

Complete device imaging / patching / updates

Bandwidth throttling for eciency / reliability

Software updates and add-ons

• Device administration and monitoring

Device health status / reporting

Remote shadowing / control

Default device conﬁguration

• Reduce end user IT costs

Reduce energy consumption with scheduled up/down times

• Scalability

Distributed architecture

Microsoft SQL database support

Multiple remote repository support

• Complete asset visibility

Automated device discovery

Detailed hardware asset information

Installed software asset information

dellwyse.com

ContactStart Technical PrintModels Features

Cloud PC Provisioning Dell Wyse WSM

Continue tour

Enterprise computing from the cloud is here.

Whatever you want. Wherever you need it.

That’s the thinking behind Dell Wyse WSM. It’s a dynamic on-demand

streamed computing environment where everyone gets their preferred

operating systems, applications, user data and documents: Wherever they

are and whenever they need them.

And Dell Wyse WSM goes beyond the traditional VDI model too – with full

support for mobile workers and remote branch oces. Dell Wyse WSM

eectively changes the rules on what’s possible and opens up the beneﬁts

of high performance desktops to enterprise users: Wherever they are.

Better than a PC could ever be

With Dell Wyse WSM users – such as those in the ﬁnancial or retail

industries – are given a fresh computer with their chosen PC operating

system, applications and ﬁles all preloaded and ready-to-go, every time

they sit down and start-up their powerful desktop devices known as

Dell Wyse ‘cloud PCs’.

Dell Wyse cloud PCs feature powerful processors that enable them to run

full PC operating systems and applications locally, while keeping their

documents and data secure on central Dell Wyse WSM servers. Enabling

existing PC users to continue to use all their familiar operating systems

and applications seamlessly - but with greater reliability and better

overall performance than a full PC - with the result that many users

don’t even realize they’re using a cloud PC.

And - better still, Dell Wyse WSM features a highly secure, robust and

resilient network design that’s ideal for remote oces and mission

critical deployments such as the defense industry.

With everything managed, updated, conﬁgured remotely

and securely, Dell Wyse WSM is everything a PC promises.

Minus the headaches.

dellwyse.com

ContactStart Technical PrintModels Features

User experience optimization Dell Wyse TCX Suite

Continue tour

Dell Wyse TCX delivers an optimal

user experience in one software suite.

The TCX suite enriches the user experience by removing the limitations previously

associated with thin clients. It enhances, not replaces, key protocols like ICA/HDX and

RDP by adding key features to help make each more valuable.

with Dell Wyse Collaborative Processing Architecture

Multi-display

Ensures application

windows and dialog boxes

are multi-monitor aware

when using more than

one monitor.

USB Virtualization

Enables plug and play peripheral

support for virtual desktop

environments.

• Redirect and use local USB

devices in virtual desktops.

• Deploy virtual desktops to

knowledge workers with special

device access needs.

• Enable a broad set of USB

peripherals including webcams

and headsets.

Multimedia acceleration

Streamlines the delivery of video and

audio content to the local client for a rich

user experience within a thin client

computing architecture.

• Accelerates Mpeg1, Mpeg2, WMV,

Mpeg4 Part 2, AC3, AAC, MP3, WAV,

WMA media types.

• Collaborative Processing Architecture

enhances server scalability, and

network utilization by o-loading

multimedia rendering to the client.

Flash redirection

Flash redirection helps thin client

users to experience excellent Flash

video performance. Flash redirection

allows web-based Flash video

content to be fetched directly by the

Dell Wyse thin client from the source

where it is played locally. Users get

outstanding Flash video performance

while the VDI host system runs

more eciently.

Bi-directional sound

Enables bi-directional audio in

virtual desktop environments,

enabling solutions such as

VOIP, digital dictation or voice

recognition to be deployed.

dellwyse.com

Otros manuales para Wyse C10LE

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de De oficina de Dell

Dell

Dell Precision T7610 Manual de usuario

Dell

Dell OptiPlex 3090 Small Form Factor Manual de usuario

Dell

Dell GX520 - OptiPlex - 512 MB RAM Manual de usuario

Dell

Dell studio XPS Manual de usuario

Dell

Dell Vostro 230 Manual de usuario

Dell

Dell OptiPlex XE3 Manual de usuario

Dell

Dell Precision 0G475 Manual de usuario

Dell

Dell OptiPlex 7040 Manual de usuario

Dell

Dell XPS One 2710 Manual de usuario

Dell

Dell OptiPlex 7050 Tower Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Dell

Dell GX260 - Optiplex Pentium 4 2.0GHz 512MB 40GB... Manual de usuario

Dell

Dell Precision 3430 Manual de operación y mantenimiento

Dell

Dell OptiPlex 960 MT Manual del propietario

Dell

Dell Precision 7820 Tower Manual de usuario

Dell

Dell OptiPlex 330 Manual de usuario

Dell

Dell OptiPlex 3240 Manual de usuario

Dell

Dell OptiPlex 790 Manual del propietario

Dell

Dell Precision WorkStation 210 Manual de usuario

Dell

Dell YRC3G Manual de usuario

Dell

Dell Dimension 2400 Series Manual de usuario

Dell

Dell Optiplex 5070 Small Form Factor Manual de usuario

Dell

Dell Inspiron 23 Manual de usuario

Dell

Dell OptiPlex 3040 Manual de usuario

Manuales populares de De oficina de otras marcas

HP m9060n - Pavilion - Elite Hoja de especificaciones

Asus

Asus E210 Series Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

HP Presario SV7000 - Desktop PC Manual de usuario

HP ProDesk 400 G5 Manual

Logitech

Logitech MK320 Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

HP Z1 Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Compaq

Compaq iPAQ Internet Device Manual de usuario
