Dell™ Inspiron™ 300/400 Comprehensive Specifications

This document provides information that you may need when setting up, updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start

®Help and Support and select the option to view information about your computer.

Processor Memory

Card Reader

Drives and Devices System

Board

Connectors

Memory External

Connectors

Computer Information Battery

Expansion Bus AC Adapter

Video Physical

Audio Computer

Environment

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and Inspiron are trademarks of Dell Inc.; Intel is a registered trademark and Atom is a trademark of Intel

Corporation in the U.S. and other countries; AMD,ATI Mobility Radeon,and AMD Athlon are trademarks or registered trademarks of Advanced Micro

Devices, Inc.; Blu-ray Disc is a trademark of the Blu-ray Disc Association.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Regulatory Model D02U series Regulatory Type D02U001/D02U002 September 2009 Rev. A00

Processor

Computer Model Inspiron 300 Inspiron 400

Type Intel®Atom™ AMD Athlon™

AMD Athlon X2

L2 cache 512 KB 512 KB

1 MB

DRAM bus width —64 bits

External bus

frequency 133 MHz 200 MHz

Back

to Top

Drives and Devices

Computer Model Inspiron 300 Inspiron 400

Externally

accessible one 12.7-mm tray

load for SATA

DVD-ROM or

DVD+/-RW Super

Multi Drive

one 12.7-mm tray

load for SATA

DVD+/-RW Super

Multi Drive or Blu-

ray Disc™ combo

Communication — Mini PCIe WLAN

index.htm:

file:///T|/htdocs/systems/insp300/en/cs/index.htm[7/25/2012 8:50:34 AM]

(optional) card (802.11 b/g

or 802.11 a/b/g/n)

Internally

accessible one 3.5-inch bay

for SATA hard

drive

one 3.5-inch bay

for SATA hard

drive

Back

to Top

Memory

Computer Model Inspiron 300 Inspiron 400

Connectors one two

Minimum 1 GB 1 GB

Maximum 1 GB 8 GB

Memory type 533 MHz DDR2

UDIMM;

non-ECC memory

only

800 MHz DDR2

SODIMM;

non-ECC memory

only

Memory capacities 1 GB 1 GB, 2 GB, and 4

Memory

configurations

possible

1 GB 1 GB, 2 GB, 3 GB,

4 GB, 6 GB, and 8

Back

to Top

Computer Information

Computer Model Inspiron 300 Inspiron 400

System chipset Intel 945GC AMD®780G

Data bus width 64 bits 64 bits

DRAM bus width 64 bits —

Processor address

bus width 32 bits —

Flash EEPROM 8 MB 8 MB

Memory speed 667 MHz 800 MHz

Back

to Top

Expansion Bus

Computer Model Inspiron 300 Inspiron 400

SATA 2.0 1.5 Gbps and 3.0

Gbps 1.5 Gbps and 3.0

Gbps

USB 2.0 high speed

— 480 Mbps

full speed —

high speed —

480 Mbps

full speed —

index.htm:

file:///T|/htdocs/systems/insp300/en/cs/index.htm[7/25/2012 8:50:34 AM]

12 Mbps

low speed

— 1.2 Mbps

12 Mbps

low speed —

1.2 Mbps

Back

to Top

Video

Computer Model Inspiron 300 Inspiron 400

Video Intel UMA UMA:

ATI Mobility

Radeon™ HD 3200

Discrete:

ATI Mobility Radeon

HD 4330 (optional)

Video memory up to 128 MB up to 256 MB

(UMA)

512 MB DDR3

(Discrete)

Back

to Top

Audio

Computer Model Inspiron 300 Inspiron 400

Audio type integrated 2.1

channel, High

Definition Audio

integrated 2.1

channel, High

Definition Audio

Volume controls software program

controlled software program

controlled

Back

to Top

Memory Card Reader

Computer Model Inspiron 300 Inspiron 400

Cards supported Secure

Digital (SD)

Card

Mini Secure

Digital Card

Micro SD

Card

Secure

Digital High

Capacity

(SDHC)

Card

Secure

Digital (SD)

Card

Mini Secure

Digital Card

Micro SD

Card

Secure

Digital High

Capacity

(SDHC)

Card

Back

to Top

index.htm:

file:///T|/htdocs/systems/insp300/en/cs/index.htm[7/25/2012 8:50:34 AM]

System Board Connectors

Computer Model Inspiron 300 Inspiron 400

Memory one 240-pin

connector two 200-pin

connectors

Chassis fan one 4-pin

connector one 4-pin

connector

Graphic fan —one 4-pin

connector

SATA two 7-pin

connectors two 7-pin

connectors

Back

to Top

External Connectors

Computer

Model Inspiron 300 Inspiron 400

Front Panel Connectors

USB two USB 2.0-

compliant

connectors

two USB 2.0-compliant

connectors

Audio one headphone

connector one headphone

connector

Memory card

reader one 4-in-1

memory card

reader

one 4-in-1 memory

card reader

Back Panel Connectors

Network

adapter one RJ45

connector

(10/100)

one RJ45

connector(10/100/1000)

USB two USB 2.0-

compliant

connectors

two USB 2.0-compliant

connectors

Audio one microphone

connector

one line-out

connector

one microphone

connector

one line-out connector

Video one VGA

connector one VGA connector

one HDMI connector

Power one AC adapter

connector one AC adapter

connector

eSATA — two connectors

Back

to Top

Battery

Computer Model Inspiron 300 Inspiron 400

index.htm:

file:///T|/htdocs/systems/insp300/en/cs/index.htm[7/25/2012 8:50:34 AM]

Coin-cell battery 3-V CR2032

lithium coin cell

3-V CR2032 lithium

coin cell

Back

to Top

Physical

Computer Model Inspiron 300 Inspiron 400

Height 197.6 mm (7.77

inches) 197.6 mm (7.77

inches)

Width 197.6 mm (7.77

inches) 197.6 mm (7.77

inches)

Depth 89 mm (3.50

inches) 89 mm (3.50

inches)

Weight (without

AC adapter) 1.6 kg (3.53 lb) 2.0 kg (4.41 lb)

Back

to Top

AC Adapter

Computer Model Inspiron 300 Inspiron 400

AC Adapter (65 W)

Input voltage 100-240 VAC 100-240 VAC

Input current 1.7 A 1.7 A

Input frequency 50–60 Hz 50–60 Hz

Output power 65 W 65 W

Output current 3.42 A 3.42 A

Rated output

voltage 19 +/- 0.95 VDC 19 +/- 0.95 VDC

Dimensions:

Height 31.5 mm (1.24

inches) 31.5 mm (1.24

inches)

Width 45.5 mm (1.79

inches) 45.5 mm (1.79

inches)

Depth 108 mm (4.25

inches) 108 mm (4.25

inches)

Weight (without

AC adapter) 0.25 kg (0.55 lb) 0.25 kg (0.55 lb)

Weight (Auto-Air

adapter without

AC/DC cord)

0.26 kg (0.57 lb) 0.26 kg (0.57 lb)

AC Adapter (75 W)

NOTE: The 75 W AC adapter is shipped with the

discrete graphics card.

Input voltage —100-240 VAC

Input current —1.5 A

index.htm:

file:///T|/htdocs/systems/insp300/en/cs/index.htm[7/25/2012 8:50:34 AM]

Input frequency —50–60 Hz

Output power —75 W

Output current —3.95 A

Rated output

voltage —19 +/- 0.95 VDC

Dimensions:

Height — 30.3 mm (1.19

inches)

Width — 57.0 mm (2.24

inches)

Depth — 132.5 mm (5.21

inches)

Weight (without

AC adapter) —0.45 kg (0.99 lb)

Weight (Auto-Air

adapter without

AC/DC cord)

—0.46 kg (1.01 lb)

Back

to Top

Computer Environment

Temperature range:

Operating 10°C to 35°C

(50°F to 95°F)

Storage -40°C to 65°C

(-40°F to 149°F)

Relative humidity (maximum) 20% to 80% RH

(non-condensing)

Maximum vibration (using a random-vibration

spectrum that simulates user environment):

Operating 5 to 350 Hz at 0.0002 G2/Hz

Storage 5 to 500 Hz at 0.001 to 0.01

G2/Hz

Maximum shock (measured with hard drive in head-

parked position and a 2-ms half-sine pulse):

Operating 40 G +/- 5% with pulse

duration of 2 msec +/- 10%

(equivalent to 20 in/sec [51

cm/sec])

Storage 105 G +/- 5% with pulse

duration of 2 msec +/- 10%

(equivalent to 50 in/sec [127

cm/sec])

Altitude (maximum):

Operating -15.2 to 3048 m

(-50 to 10,000 ft)

Storage -15.2 to 10,668 m

(-50 to 35,000 ft)

index.htm:

file:///T|/htdocs/systems/insp300/en/cs/index.htm[7/25/2012 8:50:34 AM]

Airborne contaminant level G2 or lower as defined by

ISA-S71.04-1985
