Datalogic PowerScan PD8530 Manual de usuario

PowerScan

™

PD8530 Family

Industrial Corded Handheld

Area Imager Bar Code Reader

Quick Reference Guide

Datalogic Scanning, Inc.

959 Terry Street

Eugene, Oregon 97402

Telephone: (541) 683-5700

Fax: (541) 345-7140

documentation or the procedures described therein may be reproduced or

transmitted in any form or by any means without prior written permission of

Datalogic Scanning, Inc. or its subsidiaries or affiliates ("Datalogic" or “Datalogic

Scanning”). Owners of Datalogic products are hereby granted a non-exclusive,

revocable license to reproduce and transmit this documentation for the purchaser's

own internal business purposes. Purchaser shall not remove or alter any proprietary

notices, including copyright notices, contained in this documentation and shall

ensure that all notices appear on any reproductions of the documentation.

Should future revisions of this manual be published, you can acquire printed versions

by contacting your Datalogic representative. Electronic versions may either be

downloadable from the Datalogic website (www.scanning.datalogic.com) or

provided on appropriate media. If you visit our website and would like to make

comments or suggestions about this or other Datalogic publications, please let us

know via the "Contact Datalogic" page.

DISCLAIMER

Datalogic has taken reasonable measures to provide information in this manual that

is complete and accurate, however, Datalogic reserves the right to change any

specification at any time without prior notice. Datalogic is a registered trademark of

Datalogic S.p.A. in many countries and the Datalogic logo is a trademark of Datalogic

S.p.A. all licensed to Datalogic Scanning, Inc. All other trademarks and trade names

referred to herein are property of their respective owners.

PATENTS

This product is covered by one or more of the following patents:

Design Pat. AU 310201; AU 310202; CN 693980; CN735959; HK 0602013.5M001; HK

0602013.5M002; JP 1305693; KR 30-0460940; US D570,843 S; USD588,596 S.

US Pat. 5,992,740; 6,305,606 B1; 6,517,003; 6,808,114 B1; 6,997,385 B2; 7,387,246 B2;

5,367,151; 5,449,893; 5,545,889; 6,098,877; 6,220,514 B1; 6,412,698 B2; 6,607,132 B1;

6,817,529 B2; 6,834,805 B2; 7,948,214 B2.

European Pat. 789,315 B1; 895,175 B1; 1,128,314 B1; 1,128,315 B1; 1,396,811 B1;

1,413,971 B1; 1,816,585 B1; 1,942,442 B1.

Additional patents pending.

Quick Reference Guide 1

Table of Contents

Description .....................................................................................................3

Using the PowerScan™ PD8530 Family ...............................................4

Indicators ........................................................................................................5

LED Indicators .......................................................................................5

Beeper......................................................................................................5

Good Read Spot ...................................................................................6

Setup ................................................................................................................6

Connections ..................................................................................................7

Connecting the Cable ........................................................................7

Start-Up ...................................................................................................9

Interface Selection ....................................................................................10

Wedge Keyboard Nationality ................................................................11

USB Keyboard Nationality ......................................................................12

Reading Parameters .................................................................................13

Good Read Spot Duration...............................................................13

Default Configuration ..............................................................................14

Operating Test ............................................................................................16

Technical Features ....................................................................................17

Services and Support ...............................................................................21

Datalogic Scanning Limited Factory Warranty .......................21

Warranty Coverage ..................................................................21

Warranty Claims Process .......................................................22

Warranty Exclusions ................................................................23

No Assignment ..........................................................................24

Risk of Loss ..................................................................................24

Compliance ..................................................................................................25

FCC Compliance .................................................................................25

Laser Safety ..........................................................................................25

LED Illuminator .........................................................................26

Aiming System ..........................................................................26

Power Supply ......................................................................................29

WEEE Compliance..............................................................................30

2 PowerScan™ PD8500 Family

NOTES

Quick Reference Guide 3

PowerScan™ PD8530 Family

Description

This manual includes just the commands required for the startup of the

scanner and setting of the interface. For complete configuration of the

scanner, refer to the PowerScan™ PD8530 Reference Manual or the Dat-

alogic Aladdin configuration program, both downloadable from the web-

site and available on the included CD ROM.

The PowerScan™ PD8530 Hand-Held Reader packs a lot of perfor-

mance into an attractive, rugged, hand-held device. It operates in com-

mercial and industrial environments, as well as the front office.

Omni-

directional

Operating

To read a symbol or capture an image, you simply aim

the reader and pull the trigger. Since the PowerScan™

PD8530 is a powerful omni-directional reader, the ori-

entation of the symbol is not important.

Decoding Thanks to powerful algorithms, PowerScan™ PD8530

reliably decodes all major 1D (linear) barcodes, 2D

stacked codes (such as PDF417), 2D matrix symbols

(such as DataMatrix), postal codes (such as POSTNET,

PLANET). The data stream — acquired from decoding a

symbol — is rapidly sent to the host. The reader is

immediately available to read another symbol.

Formatting

and

Concatenating

The string of a decoded code may be processed

according to either a simple or advanced data for-

matting and be concatenated to other codes (up to 4

different codes).

Imaging PowerScan™ PD8530 can also function as a camera

by capturing entire images or image portions of

labels, signatures, and other items.

Autoscanning An autoscan command causes the reader to scan

continuously and to monitor the central zone of its

reading area.

Flash Memory Flash technology allows you to upgrade the Power-

Scan™ PD8530 reader as new symbologies are sup-

ported or as improved decoding algorithms become

available.

Using the PowerScan™ PD8530 Family

4 PowerScan™ PD8530 Family

Using this Quick Reference Manual, you can start using your Power-

Scan™ PD8530 reader. For details about general configuration com-

mands, refer to the PowerScan™ PD8530 Product Reference Guide

(PRG) available on the website.

Using the PowerScan™ PD8530 Family

The PowerScan™ PD8530 normally functions by capturing and decod-

ing codes. The PowerScan™ PD8530 reader uses an intelligent aiming

system. By pulling the trigger, the aiming system indicates a field of view,

which should be positioned over the code:

Aiming System

When you pull the trigger, a red beam illuminates the code. If the aiming

system is centered and the entire symbology is within the aiming system,

you will get a good read. The field of view changes size as you move the

reader closer or farther away from the code.

Relative Size and Location of Aiming System Pattern

USA Driver

License

Parsing

The reader can be set up to select and output a sub-

set of data elements from USA Driver License PDF417

barcodes. This feature can be enabled using either

Datalogic Aladdin™ or the barcodes in the USA Driver

License Parsing Quick Reference Guide (QRG), avail-

able on the Datalogic website.

Linear barcode 2D Matrix symbol

Indicators

Quick Reference Guide 5

Successful reading is signaled by an audible tone plus a good-read green

LED.

Indicators

LED Indicators

The PowerScan™ PD8530 family uses green LED indicators to signal

the following reader functions:

Beeper

The PowerScan™ PD8530 basic software provides beeper signals for

good/wrong reading and for indicating errors. Its tone, volume and dura-

tion can be directly configured by using the codes given in the Power-

Scan™ PD8530 Product Reference Guide (PRG) available on the

website.

The application program can also manage the beeper (User Defined

Beeper) when the reader is controlled by a Host PC. It is possible to acti-

vate the beeper by sending a command from the Host to the reader via the

current communication interface.

The PowerScan™ PD8530 hand-held reader aiming system is

designed for general reading and decoding of 1D and 2D

symbols. Some variation in reading distance will occur due

to narrow bar width and other factors.

If reading codes positioned on reflective surfaces, it may be

necessary to tilt the reader with respect to the barcode and/

or set the Camera Control parameters. For configuring the

Camera Control parameters refer to the PowerScan™

PD8530 Product Reference Guide (PRG) available on the

website and the CD.

STATUS BEHAVIOR

Power ON

At power-on, the LEDs blink briefly, then

light up for 2 seconds to signal the power

supply is present.

Normal Function

The LED lights up after a good decoding

and will switch off only at the next trigger

press.

Setup

6 PowerScan™ PD8530 Family

Good Read Spot

A green good-read spot will be projected in the field of view when the

reading is successful.

Setup

1. Make connections between PowerScan™ PD8530 and the Host

PC using the correct interface cable.

2. Read the correct Interface Selection code.

Your reader is now ready to read codes using the default settings.

Connections

Quick Reference Guide 7

Connections

Connecting the Cable

A. Rubber gasket

B. Plastic boot

C. Cable spacer

D. Cover

E. Strain relief

1. Slip the cover over the cable.

2. Push the plastic boot into the rubber

gasket. Take care that the tab on the

plastic boot is aligned with the notch

in the rubber gasket.

3. Push the plastic boot and gasket into

the handle. Ensure that the “Front”

marking on the plastic boot is facing

out, with the arrow pointing towards

the front of the scanner.

4. Insert the cable into the socket of the

plastic boot.

5. Insert the cable spacer into the cable

wire and slide it towards the handle.

6. Push the cover along the cable towards

the reader, and hook it over the yellow

“tooth”.

7. Insert the strain relief into the cover

and tighten the screw to fix the whole

assembly to the reader handle.

Connections

8 PowerScan™ PD8530 Family

RS232

Wedge

USB

The USB interface is compatible with:

IBM USB

Windows 98 (and later) IBM POS for Windows

Mac OS 8.0 (and later) 4690 Operating System

Otros manuales para PowerScan PD8530

Tabla de contenidos

Otros manuales de Lector de código de barras de Datalogic

Datalogic

Datalogic Gryphon M 00 Series Manual de usuario

Datalogic

Datalogic POWERSCAN SR Manual de usuario

Datalogic

Datalogic Gryphon I GFS4400 Manual de usuario

Datalogic

Datalogic QuickScan I QD21 1 Series Manual de instalación y operación

Datalogic

Datalogic QuickScan i QD2100 Manual de usuario

Datalogic

Datalogic Reader Matrix-1000 Manual de usuario

Datalogic

Datalogic DS6500 Series Manual de usuario

Datalogic

Datalogic Gryphon D100 Manual de usuario

Datalogic

Datalogic Magellan 2200VS/2300HS Manual de instalación y operación

Datalogic

Datalogic DS8110 Manual de usuario

Datalogic

Datalogic QuickScan Lite QW2100 Manual de usuario

Datalogic

Datalogic Gryphon I GD4132 Manual de usuario

Datalogic

Datalogic Magellan 3300HSi Manual de usuario

Datalogic

Datalogic Gryphon I GD4132 Manual de instalación y operación

Datalogic

Datalogic MAGELLAN 3200VSI Manual de usuario

Datalogic

Datalogic Gryphon D412Plus Manual de instalación y operación

Datalogic

Datalogic Magellan 8500Xt Guía de referencia

Datalogic

Datalogic DS6400 Manual de usuario

Datalogic

Datalogic Magellan 800i Manual de usuario

Datalogic

Datalogic Touch 90 pro Manual de usuario

Datalogic

Datalogic QuickScan Lite QW2100 Manual de usuario

Datalogic

Datalogic PowerScan BT8300 Family Manual de usuario

Datalogic

Datalogic QuickScan QD24 series Manual de instalación y operación

Datalogic

Datalogic FireScan D131 Manual de usuario

Manuales populares de Lector de código de barras de otras marcas

POSMicro

POSMicro Datalogic PowerScan D7100 Manual de usuario

Marson

Marson MT780 Guía de configuración rápida

NCR

NCR RealPOS Manual de usuario

Motorola

Motorola SE3300 Guía de configuración rápida

Element

Element P130BT Manual de usuario

Motorola

Motorola Symbol LS3008 Manual de instalación y operación

Meec tools

Meec tools OBD-II / VAG Manual de usuario

SICK

SICK CLP 100 Manual de usuario

Royal Tag SA

Royal Tag SA I-Read Manual de usuario

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manual de usuario

Meteor

Meteor 8310 Manual de usuario

Denso

Denso BHT-500B Manual de usuario

Motorola

Motorola MP6000 Instrucciones de montaje

Newland

Newland NLS-HR15-BT Manual de usuario

ARTDEV

ARTDEV AS-1310 Manual de usuario

Aopos

Aopos AS290 Manual de usuario

ENS

ENS 367-5455 Manual de usuario

Atid

Atid AT188N Plus Manual de usuario
