FireScan™

D131 READERS

QUICK REFERENCE

820001143 (Rev. D)

UPDATES AND LANGUAGE AVAILABILITY

UK/US

The latest drivers and documentation updates for this product

are available on Internet.

Log on to : www.datalogic.com

Su Internet sono disponibili le versioni aggiornate di driver e

documentazione di questo prodotto. Questo manuale è

disponibile anche nella versione italiana.

Collegarsi a : www.datalogic.com

Les versions mises à jour de drivers et documentation de ce

produit sont disponibles sur Internet. Ce manuel est aussi

disponible en version française.

Cliquez sur : www.datalogic.com

Im Internet finden Sie die aktuellsten Versionen der Treiber und

Dokumentation von diesem Produkt. Die deutschsprachige

Version dieses Handbuches ist auch verfügbar.

Adresse : www.datalogic.com

En Internet están disponibles las versiones actualizadas de los

drivers y documentación de este producto. También está

disponible la versión en español de este manual.

Dirección Internet : www.datalogic.com

USING FIRESCAN™ SERIES READERS

FireScan™ laser scanners automatically scan barcodes at a

distance. Simply aim and pull the trigger. Code scanning is

performed along the scan line emitted from the reading window.

This line must cross the entire code.

Successful scanning is obtained by tilting the scanner with

respect to the barcode to avoid direct reflections, which impair

the reading performance, see the figure above.

AIMING SYSTEM

FireScan™ laser scanners provide a programmable aiming

system. If enabled, the scan line emitted from the reading

window is preceded by a red spot, which must illuminate the

code center to get the best reading performance (see figure

above, c). Once the defined timeout is reached, the red spot

disappears and is followed by the scan line to start the code

scanning.

After configuring the scanner, read one of the following codes to

set desired aiming system timeout.

♦aiming system disabled

Ì$+BX0$-AÎ

300 ms

Ì$+BX1$-FÎ

500 ms

Ì$+BX2$-KÎ

1 sec

Ì$+BX3$-PÎ

CONNECTIONS

RS232

USB

IBM USB POS

(if required)

PEN

WEDGE

DISCONNECTING THE CABLE

READING DIAGRAM

100 200 400

200

100

-100

-200

300 500 600

Reading Zones (10° skew angle)

700 800 mm

-300

300

1.00

0.12

0.19

0.25

EAN

0.33 mm

0.38

0.50

INTERFACE SELECTION

Follow the procedure to configure the interface required by your

application:

- USB Interface

- RS232 Interface

- Wedge Interface

- Pen Interface

USB INTERFACE CONFIGURATION

The USB interface is compatible with:

Windows 98 (and later) IBM POS for Windows

Mac OS 8.0 (and later) 4690 Operating System

START-UP

As with all USB devices, upon connection, the Host performs

several checks by communicating with the FireScan™. During

this phase the green LED on the FireScan™ reader blinks and

normal operations are suspended. Two basic conditions must

be met before FireScan™ is ready to read codes, the correct

USB driver must be loaded and sufficient power must be

supplied to the reader.

For all systems, the correct USB driver for the default USB-KBD

interface is included in the Host Operating System and will

either be loaded automatically or will be suggested by the O.S.

and should therefore be selected from the dialog box (the first

time only).

If the Host supplies sufficient power to the reader, the start-up

phase ends correctly, the green LED stops blinking and the

reader emits the beep OK signal.

If the Host does not supply sufficient power to the reader, a

dialog box will appear on the Host and the reader will be

blocked (green LED continues blinking). In this case,

disconnect the USB cable at the Host (green LED stops

blinking), connect and power-up an external supply to the USB

cable then reconnect the USB cable to the Host and close the

dialog box. The reader emits the beep OK signal. You can now

read codes. At this point you can read the USB interface

configuration code according to your application. Load drivers

from the O.S. (if requested). When configuring the USB-COM

interface, the relevant files and drivers must be installed from

the USB Device Installation software, which can be downloaded

from the web page http://www.datalogic.com.

The reader is ready.

First Start-Up

Connect FireScan™

to Host

Does a dialog

box appear

warning that Bus

power is not

sufficient?

Select desired USB

interface code

(USB-KBD is default)

Disconnect reader

at Host

Connect external

power supply to

cable and power up

Reconnect reader

cable to Host and

close dialog box

YES

Read test codes.

Reader is READY

Load drivers

(if requested)

Load drivers

(

if re

uested

)

Green LED blinks

Green LED off - BEEP OK

BEEP OK

Green LED off

Successive start-ups will automatically recognize the previously

loaded drivers. If external power is used, verify that external

power is already supplied.

Successive Start-Ups

YES

Read test codes.

Reader is READY

Green LED blinks

Green LED off - BEEP OK

BEEP OK

Connect FireScan™

to Host

Disconnect reader

at Host

Connect external

power supply to

cable and power up

Reconnect reader

cable to Host and

close dialog box

Does a dialog box

appear warning

that Bus power is

not sufficient?

USB INTERFACE SELECTION

USB-KBD

Ì$+UA03$-:Î

USB-KBD-ALT-MODE

Ì$+UA04$-@Î

USB-KBD-APPLE

Ì$+UA05$-FÎ

USB-COM*

Ì$+UA02$-4Î

USB-IBM-Table Top

Ì$+UA00$-(Î

USB-IBM-Hand Held

Ì$+UA01$-.Î

* When configuring USB-COM, the relevant files and drivers

must be installed from the USB Device Installation software,

which can be downloaded from the web page

http://www.datalogic.com.
