Danfoss PVREL Manual de usuario
P301 244
Installation Guide
© Danfoss A/S, 2014-03 520L0507 • Rev CB • Mar 2014 1
520L0507
520L0507
Mobile Electronics
PVREL
Standard with spring return 155U2601
Standard with spring return
and with neutral switch 155U2605
Friction hold, by turning the
knob 155U2602
Friction hold, by turning the
knob and with neutral switch 155U2606
Neutral lock and spring return 155U2603
Neutral lock and spring return
with neutral switch 155U2607
Float position lock and spring
return 155U2604
Float position lock and spring
return with neutral switch 155U2608
Bottom cover 155U2600
Bottom view
A : Socket A 6.3-0.8
155B348.12
-+
P301 225
2 520L0507 • Rev CB • Mar 2014 © Danfoss A/S, 2014-03
E
Nødstop
Emergency stop
Notschalter
Arrêt d’urgence
T
Fladstik A 6,3 - 0,8*
Tabs A 6.3 - 0.8*
Flachstecker A 6,3 - 0,8*
Languettes mâles A 6,3 - 0,8*
* (DIN 46244)
Signal (US) som funktion
af håndtagsvinkel
Signal (US) as a function
of the lever angle
Signal (US) als Funktion
des Geberwinkels
Signal (US) en fonction
de l’angle de levier
*PVREL med holdefunktion
*PVREL with hold function
*PVREL mit Haltefunktion
*PVREL avec la fonction de maintien
Flydestilling
Float position
Fliessstellung
Position flottante
