Installation Guide

DEVIreg™ 530

Electronic Thermostat

DEVIreg™ 530

Installation Guide2

The English language is used for the original instructions.

Other languages are a translation of the original instructions.

(Directive 2006/42/EC)

DEVIreg™ 530

Installation Guide 3

1 Introduction

DEVIreg™ 530 is an electronic thermostat provided with a

2-pole switch and a wire sensor to measure and control the

desired oor temperature. It can be either ush-mounted

(standard) or surface-mounted (using special box).

The thermostat has a button for adjusting the temperature

setting with a scale from ( ) 1 to 6 (each step corresponds

to approximately 8°C). Furthermore, it has a LED indicator

showing standby periods (green light) and heating periods

(red light).

More information on this product can also be found at:

devireg.devi.com

Table of Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . 3

1.1 Technical Specications . . . . . . . . . . . . 4

1.2 Safety Instructions . . . . . . . . . . . . . . . . 5

2 Mounting Instructions . . . . . . . . . . . . . . . . 6

3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 12

5 Disposal Instruction . . . . . . . . . . . . . . . . . . 14

DEVIreg™ 530

Installation Guide4

1.1 Technical Specications

Operation voltage 220-240V~, 50Hz

Standby power

consumption

Max 0.25W

Relay:

Resistive load

Inductive load

Max 15A / 3450W @ 230V

cos φ= 0.3 max 1A

Sensing units NTC 15kOhm at 25°C

Sensing values:

0°C

25°C

50°C

42 kOhm

15 kOhm

6 kOhm

Hysteresis ± 0.4°C

Ambient temperature -10 to +30°C

Frost protection

temperature

5 °C -

Temperature range ( ) 5-45°C with oor

sensor only

Cable specication max 1x4mm² or 2x2,5mm²

Ball pressure temperature 75 °C

Pollution degree 2 (domestic use)

DEVIreg™ 530

Installation Guide 5

Type 1C

Storage temperature -20 to +65°C

IP class 31

Protection class Class II -

Dimensions 85 x 85 x 36 mm

Weight 90 g

The product complies with the EN/IEC Standard «Automatic

electrical controls for household and similar use»:

• EN/IEC 60730-1 (general)

• EN/IEC 60730-2-9 (thermostat)

1.2 Safety Instructions

Make sure the mains supply to the thermostat is turned o

before installation.

IMPORTANT: When the thermostat is used to control a

oor heating element in connection with a wooden oor or

similar material, always use a oor sensor and never set the

maximum oor temperature to more than 35°C.

Please also note the following:

• The installation of the thermostat must be done by an

authorized and qualied installer according to local

regulations.

DEVIreg™ 530

Installation Guide6

• The thermostat must be connected to a power supply

via an all-pole disconnection switch.

• The sensor is to be considered as live voltage. Have

this in mind if the sensor must be extended.

• Always connect the thermostat to continuous power

supply.

• Do not expose the thermostat to moisture, water,

dust, and excessive heat.

2 Mounting Instructions

Place the thermostat at a suitable height

on the wall (typically 80-170cm.).

In wet rooms, place the thermostat according

to local regulation on IP classes.

DEVIreg™ 530

Installation Guide 7

Note: A oor sensor enables a more accurate

temperature control and is recommended

in all oor heating applications

and mandatory under wooden oors to

reduce the risk of over-heating the oor.

• Place the oor sensor in a conduit in an appropriate

place where it is not exposed to sunlight or draft from

door openings.

• Equally distant and >2cm from two heating cables.

• The conduit should be ush with the oor surface -

countersink the conduit if necessary.

• Route the conduit to the connection box.

• The bending radius of the conduit must be min 50mm.

DEVIreg™ 530

Installation Guide8

Follow the steps below to mount the thermostat:

1. Open the thermostat:

devireg™550

• Press the release tab in the bottom of the

thermostat using a at object.

• Carefully detach the front cover.

• Carefully detach the frame.

DEVIreg™ 530

Installation Guide 9

2. Connect the thermostat according to the connection

diagram.

IP31

-10T30

D530

Mains

220-240V~

Max. Load

15 (1) A

Sensor

NL NTC

LOAD

-5°C

9

By connecting an external timer to the terminal

marked by a moon symbol (and by using for example

the same phase as for the mains power supply), the

thermostat can be set to reduce the temperature by

5°C during specied periods.

The screen of the heating cable must be connected

to the earth conductor of the power supply cable by

using a separate connector.

Note: Always install the oor sensor in a conduit in

the oor.

DEVIreg™ 530

Installation Guide10

3. Mount and reassemble the thermostat.

• Fasten the thermostat to a socket or an exterior

wall box by driving the screws through the holes

in each side of the thermostat.

• Install the frame and front cover in the reverse

order of disassembly.

4. Turn on the power supply.

3 Settings

How to change the minimum and maximum oor

temperatures

1. Remove the adjustment button.

2. Move the pins to the desired

positions.

3. Put the adjustment button back

in place.

devireg™550

Note: Please be aware of the following:

• The oor temperature is measured where the oor

sensor is placed.

• The temperature of the bottom of a wooden oor can

be up to 10 degrees higher than the top.
