Daewoo DCVC100 Manual de usuario

DCVC100

Window Vacuum Cleaner

USER MANUAL

GEBRUIKERSHANDLEIDING

GEBRAUCHSANWEISUNG

MODE D’EMPLOI

TECHNICAL SPECIFICATIONS

Warning!

Risk of electric shock and for potential risk of death and/or

serious irreversible injury!

Safety Warning!

It requires special attention to read and follow the instructions,

otherwise a potential hazard, injury, death or serious condition

may happen.

Class II

For equipment where protection against electric shock does

not solely rely on basic insulation, but where additional safety

precautions like double insulation or reinforced insulation are

taken, and there is no protective earthing or reliance upon

installation conditions.

CE marking

Indicates that the product sold in Europe has been assessed to

meet high safety, health, and environmental protection require-

ments.

Wheelie Bin (WEEE)

Instructions for protecting the environment (Waste Electrical &

Electronic Equipment directive)

Read the instructions for use carefully and keep them safe. If

you give this device to other people, please also pass on this

manual.

SAFETY INFORMATION:

When using any electrical appliance, basic safety precautions should always

be considered to reduce the risk of re, electrical shock, leaking batteries of

personal injury, including the followings:

• Never immerse unit or charger in water or other liquid

• Do not insert objects into the air vents.

• This appliance can be used by children aged from 14 years and above

and persons with reduced physical, sensory, or mental capabilities or

lack of experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with appliance. Cleaning

and user maintenance shall not be made by children without supervision.

• This appliance is powered by safety low voltage corresponding to the

marking on the appliance.

• Before using the appliance and after any impact, check for any sign of

wear or damage.

• Do not use the appliance if any parts is damaged or defective.

• Only use the charger supplied with the product. Do not attempt to use

any chargers from other products to charge the appliance.

• Using a charger from different product may cause re and or electrical

shocks.

• Before use, check the charger cord for signs of damage or ageing.

• Do not attempt to charge a damaged battery.

• The appliance must be disconnected from main supply when removing

the battery.

• Always unplug the appliance before cleaning and/or maintenance.

• Always unplug the charger from the main supply if it is not used for

charging.

• Keep the charger cord away from hot surfaces and sharp edges.

• Do not handle the charger with wet hands.

• Do not store or charge the unit at outdoor.

STORAGE

• Store in an upright position

• Store in a dry place

• Store out of reach of children

• Ensure the appliance is not plugged-in during storage

INTENDED USE

• Use only as instructed in this manual. The use of any accessory or opera-

tion with this appliance other than those recommended in this instruction

manual may have the risk of personal injury.

• Use this battery-operated appliance only for cleaning moist, smooth

surfaces such as windows, mirrors, or tiles.

• It is not recommended to use the appliance on surfaces that can be

easily scratched such as wood, steel, varnished and high glossy surfaces,

otherwise it will damage the rubber lips.

• Only use this appliance with conventional window cleaner (no spirit, no

foam), otherwise leakage may happen from air vents. If this happens,

stop the appliance immediately.

START UP

• Before you start, unpack the product, remove all protective cartons, and

make sure no accessories are missing and none of the package have

been damaged (Fig. 1).

• Attach the suction nozzle to the main unit until it snaps in place (Fig. 2).

• Assemble the sprayer and wipe bre and add detergent/window cleaner,

water into sprayer tank (Fig. 3, 4 and 5).

• Charge the battery of appliance for 3 hours before use (Fig. 6).

• After fully charging the appliance, the operating time of the appliance is

about 30 minutes.

INSTRUCTIONS

• Apply detergent/window cleaner on the windows surface evenly (Fig.

7-2).

• Rub and loosen the dirt on window using the wipe bre (Fig. 7-3)

• Prior to use, make sure the squeegees are clean.

• Turn the appliance on and move the appliance from top to bottom of

window (Fig. 8) and vacuum up the detergent/window cleaner.

• Hard to reach areas can be vacuumed vertically or horizontally.

• If battery level is low, the charging/power indicator starts ashing

slowly. If this happens, charge up the battery as soon as possible.

• The appliance can be switched off (Fig. 9) while the spray bottle

is in use. This will save battery power and extend operating time.

• Switch off the appliance and set it in upright position if there is a need

for an interrupt during the cleaning process.

CLEANING THE APPLIANCE

Emptying water tank

• Once the max. level (150ml mark) of the water tank is reached, dirt water

inside the water tank has to be discarded, otherwise water may get into

the suction system.

• If the appliance is being used with its handle facing down (e.g., cleaning

rooight), it is recommended to empty the water tank after cleaning each

window.

• Turn off the appliance and pull out the cover lock (Fig. 10) of the water

tank.

• Drain out the water from water from water outlet hole (Fig. 11).

• Only open the water tank when cleaning is necessary.

Cleaning water tank

• For hygienic reason, it is recommended to empty and clean the water

tank after several uses.

• Push down the release button of water tank and take it out from the main

unit (Fig. 13).

• To open the water tank, apply force to pull the top half and bottom half

of water tank apart (Fig. 14).

• Each time to open the water tank, be cautious for the inner assembled

parts.

• Remove the tube separator by pulling it out of the main unit and clean it

and the inside of water tank under running water, or with a cloth.

• Components of the window vacuum cleaner are NOT dishwasher safe!

• Connect the tube separator back to water tank bottom half unit.

• Connect the water tank top and bottom half units back in place.

• Put the water tank back to the main unit by pushing the top part into the

main unit until it snaps in place.

Cleaning main unit

• Turn off the appliance.

• The main unit as well as the squeegee can be cleaned or wiped with a

damp cloth.

• Squeegee can be detached from the main unit by releasing the lock in

the middle (Fig. 12).

• Do not use solvents or polishes to clean the outside of the unit.

• The appliance contains electrical components, never immerse the

unit in water.

• Do not clean it in a dishwasher, washing machine, or under running

water.

• Store the appliance in a dry place with put the appliance in an upright

position.

BATTERY CHARGING

• Charge the battery for 3 hours before use for the rst time.

• Turn off the appliance before charging.

• Connect the charging plug of charger to the charging socket located

below the power button of apparatus.

• Plug the charger to a suitable electrical socket.

• The light indicator will be ashing in blue colour during charging.

• After charging is completed, the light indicator will remain blue.

• Unplug the charger from main socket. Do not pull the charger cord.

• Disconnect the charging plug from the apparatus.

• It takes about 3 hours to fully recharge the battery if the apparatus is

automatically stopped due to low battery power.

• If the appliance is connected to the charger while it is on, the motor will

stop immediately, and it will start charging.

• To maintain the good performance of the battery, it is recom-

mended the unit to be fully discharged and completely recharged at

least once a month.

LIGHT INDICATOR

TROUBLESHOOTING

Machine does not start

Check the light indicator

• Light is off/slow blinking: charge the apparatus.

• With a rapidly blinking signal with charged battery: inform your dealer of

after-sales service

Streaks while cleaning

• Clean the pull-off lip.

• Reverse the used pull-off lip: Pull the silicon squeegee to the side. Wet

the squeegee in the curved area with water or detergent. Slide the sili-

con squeegee back in the holder of reverse order.

• Replace the pull-off lip if necessary: If both edges are worn after turning

the silicon squeegee around, a new silicon squeegee is required. Re-

place silicon squeegee as described above.

• Adjust the dosing of cleaning solution.

Water is leaking from the air louvers

Empty the water tank (max. 150ml capacity)

INSTRUCTIONS FOR PROTECTING THE ENVIRONMENT

(WEEE, the waste electrical and electronic equipment directive)

Your product has been manufactured using high quality material and com-

ponents which can be recycled and used again. At the end of its life, this

product cannot be disposed in normal domestic waste, but must be taken

to a special collection point for recycling electrical and electronic equip-

ment. This is indicated in the user manual and in the packaging by the waste

container marked with cross symbol. Used raw materials are suitable for

recycling.

By recycling used appliance or raw materials, you are playing an important

role in protecting our environment. You can ask your local council about the

location of your nearest collection point.

Do not dispose batteries in your household waste. Dispose of batteries by

taking them to your local recycling station. Contact your local government

ofce for details.

EU DECLARATION OF CONFORMITY

We,

Elmarc B.V.

Kolenbranderstraat 28, 2984 At Ridderkerk,

The Netherlands

Declare under our sole responsibility that the product:

• Product Brand: Daewoo

• Product Model No: DCVC100

• Product Description: Window Vacuum Cleaner

• Product Rating: 3.7V , 20W, IPX4

• Charger Input: 100 - 240 V~, 50/60 Hz, 0.2A, Class II, IPX0

• Charger Output: 5V , 800mA

Following the provisions of the Directives:

• Electromagnetic Compatibility (EMC) Directive: 2014/30/EU

• Low Voltage Directive (LVD): 2014/35/EU

• Energy Related Products (ERP) Directive: 2009/125/EC

• Restriction of the use of certain Hazardous Substances in Electrical and Electronic

Equipment Directive (RoHS): 2015/863amending 2011/65/EU

And standards to which Conformity is declared:

EMC (Window Vacuum Cleaner & Charger):

• EN 55014-1:2017

• EN 55014-2:2015

• EN 61000-3-2:2014

• EN 61000-3-3:2013

LVD (Window Vacuum Cleaner):

• EN 60335-2-2:2010/A1:2013

• EN 60335-1:2012/A13:20117

• EN 62233:2008

LVD (Charger):

• EN 60335-2-29:2004+A2:2010+A11:2018

• EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A2:2019+A14:2019

• EN 62233:2008

ERP (Charger):

• EU 2019/1782

Place: The Netherlands

Date of issue: 20 April 2022

Tabla de contenidos

Idiomas:

Otros manuales de Aspiradora de Daewoo

Daewoo

Daewoo Tornado Lyte Manual de usuario

Daewoo

Daewoo Tornado Cylinder Manual de usuario

Daewoo

Daewoo RC-1780GA Manual de usuario

Daewoo

Daewoo RCG-110 Series Manual de usuario

Daewoo

Daewoo RC-L381 Manual de usuario

Daewoo

Daewoo RCC-153 Manual de usuario

Daewoo

Daewoo RC-701M Manual de usuario

Daewoo

Daewoo TORNADO F1 Manual de usuario

Daewoo

Daewoo RC-2006SV Manual de usuario

Daewoo

Daewoo RCC-11GR EU Manual de usuario

Daewoo

Daewoo HURRICANE CAT 5 Manual de usuario

Daewoo

Daewoo CYCLONE DIGI ONE Manual de usuario

Daewoo

Daewoo RC-6003F Manual de usuario

Daewoo

Daewoo RC-2200 Manual de usuario

Daewoo

Daewoo COMPACT PRO Manual de usuario

Daewoo

Daewoo Cyclone Lyte Manual de usuario

Daewoo

Daewoo RCC-9508HR Manual de usuario

Daewoo

Daewoo TORNADO PET Manual de usuario

Daewoo

Daewoo RCC-250R-1 Manual de usuario

Daewoo

Daewoo DAVC150 Manual de usuario

Daewoo

Daewoo RC-350 Manual de usuario

Daewoo

Daewoo RCC-250F Manual de usuario

Daewoo

Daewoo RCU-3006 Series Manual de usuario

Daewoo

Daewoo RC-7004F Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
