Daewoo DTB Series Manual de usuario

Colour Television

Instruction Manual

P/N : 48586185E215-R3

MODEL No.

DTA- 14V1 / 20V1 / 21V1

14V1T / 20V1T / 21V1T

14V3 / 20V3 / 21V3

14V3T / 20V3T / 21V3T

14U1 / 20U1 / 21U1

14U1T / 20U1T / 21U1T

14U3 / 20U3 / 21U3

14U3T / 20U3T / 21U3T

DTB- 14D2 / 20D2 / 21D2

14D2T / 20D2T / 21D2T

14D3 / 20D3 / 21D3

14D3T / 20D3T / 21D3T

14D4 / 20D4 / 21D4

14D4T / 20D4T / 21D4T

14D6T / 20D6T / 21D6T

14D7 / 20D7 / 21D7

14D7T / 20D7T / 21D7T

14D9 / 20D9 / 21D9

14D9T / 20D9T / 21D9T

21U6 / 21U6T / 21U8 / 21U8T

21T1 / 2132 / 2132T

Contents

Important safeguards 1

Before Operation 2

Connecting external equipment 3

Identification of Controls 5

Daily use 6

Menus 8

Teletext (Option) 14

Quran function 15

Specifications 16

Troubleshooting 17

Important safeguards

WATER AND MOISTURE

Never install the set in the following places : In a wet

basement, bathroom. Do not place any container with

liquid on the set.

The apparatus shall not be exposed to dripping or

splashing water and that no objects filled with liquids, such

as vases, shall be placed on the apparatus.

HEAT

Never place the set near heat sources.

Never put a naked flame, such as a candle, on the top of

TV set.

VENTILATION

Do not cover the ventilation openings in the cabinet and

never place the set in a confined space such as a

bookcase or built-in unless proper ventilation is provided.

Leave a minimum 10cm gap all around the unit.

OBJECT ENTRY

Do not insert foreign objects, such as needles and coins,

in the ventilation openings.

LIGHTNING STRIKING

You should disconnect the set from the mains and the

aerial system during thunderstorms.

CLEANING

Unplug the set from the mains during cleaning.

AFTER MOVING THE SET

If the set is moved in a different direction, the MAIN

POWER button must be switched off for at least 15

minutes in order to take out a colour strain on the screen.

Before Operation

INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT.(OPTION)

Insert the batteries (two 1.5V, type AAA or AA)

MAINS CONNECTION

Plug the mains cable into the power socket with 100V-250V, 50/60Hz AC.

AERIAL CONNECTION

When using an outdoor aerial, it is usually connected to the set by means

of 75 ohm.

SWITCHING ON AND OFF

Switching on

Switch the set on with the MAIN POWER button(ON/OFF), and then PR UP

button on the front of the set.

Or button or the PR UP button or one of the NUMBER buttons on the

remote control.

Switching off

Press button, on the remote control to return the set to its stand by

mode.

If you don't use the set for an extended period of time, turn it off with

MAIN POWER button on the set.

Battery options

TV AND A

TV AND AV

RCA JACK A

RCA JACK AV (BACK)

V (BACK)

Connecting external equipment

Use the TV/AV( ) button on the remote control or on the front of

the set to select one of the three options. Whenever the TV/AV

( ) button is pressed, the on-screen display will be changed as

shown: AV TV ( S-VHS is Russia only )

This is used to connect a VCR, a Camcorder, a S-VHS VCR, a PERI-TV decoder

or a video game console.

In most cases, the set changes automatically to AV when the VCR connected is in

display mode. If not, press the TV/AV

()

button on the remote control unit

or on the front of the set.

You must turn the external equipment off or press the TV/AV button to return to

the TV mode.

SCART (OPTION)

CAMCORDER

VIDEO GAME

LOCAL CONTROL

RCA JACK A

RCA JACK AV (FRONT)

V (FRONT)

Front

MAIN

POWER

BUTTON VIDEO AUDIO HEAD

PHONE STAND-BY

INDICATOR REMOTE

SENSOR MENU

BUTTON

VOLUME

UP/DOWN

BUTTONS

PROGRAMME

UP/DOWN

BUTTONS

TV/VIDEO

AUDIOVIDEO

Connect the AV (Audio/Video) socket with an

appropriate cable to the corresponding socket

of the external equipment. Select AV mode by

pressing the TV/AV( ) button.

Press the TV/AV( ) button to return to

the TV mode.

HEADPHONE JACK

Insert the headphone plug(3,5mm) into the

headphone socket.

The sound from the speaker will be cut off.

NOTE:

NOTE: If two apparatus are connected,

one to the front AV Jack and the other to

the rear SCART Jack, you can play only

one apparatus.

one of the them must be switched off.

or ON/OFF

Back

Identification of Controls

RCA Jack SCART (OPTION)

Aerial terminal

Aerial Terminal

REMOTE CONTROL

SLEEP RECALL

NORMAL/OK

SKIP MOVE DELETE MODE

SLEEP RECALL

MOVESKIP

DELETE MODE

NORMAL/OK

123

456

VIDEO AUDIO

POWER

NUMBER 0-9

NORMAL/OK

PR (CURSOR) UP

VOLUME UP

(CURSOR RIGHT)

PR (CURSOR) DOWN

VOLUME DOWN

(CURSOR LEFT)

MUTE

RECALL

SLEEP

MOVE

SKIP

DELETE

Not used

ON/OFF

NUMBER 0-9

INDEX

MIX

PAGE UP

SUBPAGE

PAGE DOWN

HOLD

MUTE

REVEAL

SIZE

CANCEL

Green Key

Red Key

TV/TEXT

Yellow Key

Cyan Key

two 1.5v, type AA two 1.5v, type AAA

two 1.5v, type AAA

PROGRAMME SELECTION

SOUND CONTROL

PICTURE CONTROL

Direct selection

Use remote control NUMBER 0…9 buttons.

For two digits programme numbers, press the button for

the second digit within 2.5 seconds.

Up/Down moves

Use PR UP/DOWN buttons of the remote control unit or

on the front of the set.

DAILY USE

Volume adjustment

Use VOLUME UP/DOWN buttons of the remote control

unit or on the front of the set.

Mute

Get sound off by pressing the remote control

MUTE ( ) button. Then, logo ( ) is displayed.

Sound returns by pressing the same button again.

You can choose between three picture settings, using

repeatedly remote control NORMAL/OK button :

Normal I (standard hard picture)

Normal II (standard soft picture)

Favourite (you can adjust picture setting as you

want, using Picture menu).

For other adjustments : Brightness, contrast, colour,

sharpness, see Picture menu. (page 9)

SLEEP FUNCTION

PROGRAMME ST

PROGRAMME STA

ATUS DISPLA

TUS DISPLAY

Pressing repetitively the remote control SLEEP button,

you can enter one of the following settings :

OFF > 30 min > 60 min > 90 min > 120 min > OFF

The set will be turned off after the time you set.

The remaining time before TV turn-off is displayed on

programme status.

Accessed by the Remote Control RECALL button.

Programme number

Remaining time (minutes) before

TV set turns off only when sleep

function is activated.

Channel name

01 BBC1

11 : 11

SLEEP 60

Clock

NOTE

Language selection

Child lock, Clock setting and wake time setting are

available in features menu.

MAIN MENU

HOW T

HOW TO USE SUB MENUS

O USE SUB MENUS

All menus are removed within 25 seconds if you don’t press any button.

The following is applied to all of the sub-menus.

Menus

Direct selection

Press remote control MENU button to display main

menu.

Then, you have the choice among several sub-

menus.

If you want to cancel immediately main menu,

press MENU button once more.

To select one of the sub-menus, use remote

control CURSOR buttons UP, DOWN, LEFT,

RIGHT.

To enter the selected sub-menu, press remote

control NORMAL/OK button .

Select the function you want to change using

Remote control CURSOR UP or DOWN button.

Confirm (if needed) by pressing Remote control

NORMAL/OK button .

Adjust the function using

Remote control CURSOR LEFT or RIGHT button.

Then Return to main menu pressing MENU button .


FEATURES

INSTALL
