D-Link Verizon DSL-2750B Manual de usuario
WIRELESS N300 ADSL2+ MODEM ROUTER + USB
DSL-2750B
QUICK SETUP GUIDE
* PPPoE
* PPPoA
* BRIDGE MODE
* ETHERNET WAN
MANUAL INSTALLATION,
WEB INTERFACE ONLY
DSL-2750B
2
ENGLISH
1. ACCESSING THE WEB UI
To access the Web UI of the DSL-2750B, connect your computer to the DSL-2750B using the
ethernet cable provided. Then connect the power cable to the DSL-2750B. The power light will
display as solid green.
Then simply open a browser window and enter the IP address in the browser address eld:
Please jump to the below section for your Internet Connection type:
2. PPPoE (Australian Users)
3. PPPoA (New Zealand Users)
4. Bridge Mode (If you want to use this Router as a Modem only)
5. Ethernet WAN Mode (NBN / UFB Customers)
IP ADDRESS: http://192.168.1.1
USERNAME: admin
PASSWORD: admin
WEB UI
DSL-2750B 3
ENGLISH
2. SETUP PPPoE CONNECTION
Once you have successfully accessed the Web UI of the DSL-2750B you will need to go to the
following location to congure your PPPoE settings.
SETUP > WIZARD
Click on the Setup Wizard button to start the wizard, below we will go through the required settings
to setup a PPPoE connection.
Click on Next to start the Setup Wizard.
It is recommeded to setup a new password for your DSL-2750B. Please enter the current password
"admin" and then enter a new password below. Once you have entered your new passwords click on
Next.
PPP over Ethernet (Australia)
DSL-2750B
4
ENGLISH
It is recommended to congure the Time Settings to synchronise with the Internet Time Servers.
Please enable the check box and select your Time Zone, then click Next.
In this example we will be conguring the Internet connection as PPPoE which is the most common
for Australian users.
2. Cont...
PPP over Ethernet (Australia)
DSL-2750B 5
ENGLISH
Ensure the WAN Services type is set as DSL. Select Australia from the Country selection dropdown,
then select your Internet Service Provider (ISP) from the list. Once you have selected these two
entries, you will notice the majority of the elds are completed for you. Lastly enter your Username
and Passwords that have been provided by your ISP. Click on Next when you have entered your
information.
If you wish to use Wireless on your router you will now be able to congure it below. It is
recommended to change the Wireless Network Name and also use WPA2-PSK for security.
Once you have made the required changes click on Next.
2. Cont...
PPP over Ethernet (Australia)
DSL-2750B
6
ENGLISH
Please review the details to ensure they are correct. Click on Apply to make the changes effective
immediately.
You should now have an active Internet Connection.
2. Cont...
PPP over Ethernet (Australia)
DSL-2750B 7
ENGLISH
3. SETUP PPPoA CONNECTION
PPP over ATM (New Zealand)
Once you have successfully accessed the Web UI of the DSL-2750B you will need to go to the
following location to congure your PPPoA settings.
SETUP > WIZARD
Click on the Setup Wizard button to start the wizard, below we will go through the required settings
to setup a PPPoA connection.
Click on Next to start the Setup Wizard.
It is recommeded to setup a new password for your DSL-2750B. Please enter the current password
"admin" and then enter a new password below. Once you have entered your new passwords click on
Next.
DSL-2750B
8
ENGLISH
3. Cont...
PPP over ATM (New Zealand)
It is recommended to congure the Time Settings to synchronise with the Internet Time Servers.
Please enable the check box and select your Time Zone, then click Next.
In this example we will be conguring the Internet connection as PPPoA which is the most common
for New Zealand users.
DSL-2750B 9
ENGLISH
3. Cont...
PPP over ATM (New Zealand)
Ensure the WAN Services type is set as DSL. Select New Zealand from the Country selection
dropdown, then select your Internet Service Provider (ISP) from the list. Once you have selected
these two entries, you will notice the majority of the elds are completed for you. Lastly enter your
Username and Passwords that have been provided by your ISP. Click on Next when you have
entered your information.
If you wish to use Wireless on your router you will now be able to congure it below. It is
recommended to change the Wireless Network Name and also use WPA2-PSK for security.
Once you have made the required changes click on Next.
DSL-2750B
10
ENGLISH
3. Cont...
PPP over ATM (New Zealand)
Please review the details to ensure they are correct. Click on Apply to make the changes effective
immediately.
You should now have an active Internet Connection.
