D-Link AirPlus DWL-G730AP Manual de usuario

This product can be set up usingThis product can be set up using

This product can be set up using

anan

any curry curr

y curry curr

y currenen

enen

ent web brt web br

t web brt web br

t web browserowser

owserowser

owser, i.e, i.e

, i.e, i.e

, i.e.,.,

.,.,

Internet Explorer 6 or NetscapeInternet Explorer 6 or Netscape

Internet Explorer 6 or Netscape

Navigator 6.2.3.Navigator 6.2.3.

Navigator 6.2.3.

DWL-G730APDWL-G730AP

DWL-G730AP

D-LinkD-Link

D-Link

AirAir

Air

PlusPlus

Plus™™

™™

™GG

WirWir

Wireless Peless P

eless Peless P

eless Pockock

ockock

ocketet

etet

Router/APRouter/AP

Router/AP

5V 1.2ADC PowerAdapter

BefBef

Beforor

oror

ore Ye Y

e Ye Y

e You Beginou Begin

ou Beginou Begin

ou Begin

ChCh

Check Yeck Y

eck Yeck Y

eck Your Pour P

our Pour P

our Packack

ackack

ackagag

agag

age Cone Con

e Cone Con

e Contenten

tenten

tentsts

tsts

DWL-G730AP Wireless Pocket Router/AP

CD-ROM with Manual

Ethernet (CAT5 UTP) Cable

If any of the above items are missing, please contact your reseller.

Using a power supply

with a different voltage

ratingwilldamageand voidthe

warrantyofthis product.

Softwareandspecificationssubject to changewithoutnotice. DWL-G730AP.08162004

D-Link Travel Case

The default IP address for the DWL-G730AP is 192.168.0.30 with a Subnet Mask of

255.255.255.0.Youwill needto assignyourcomputer aStaticIPaddresswithinthesame

rangeas theDWL-G730AP’sIPaddressfor thepurpose ofconfiguring theDWL-G730AP.

USB Power Cable

Hardware OverviewHardware Overview

Hardware Overview

Mode Selection Switch:

Used to select AP,

client,orroutermode.

LAN Port

This is the connection for Ethernet cables to

yourEthernet-enableddevice.WheninRouter

mode, this port functions as a WAN port.

Receptorfor

Power Adapter

Power LED: Solid

indicates a connection

toagoodpowersource.

Top Panel

Bottom Panel

Rear Panel

LAN LED: Solid indicates an

Ethernet connection. Blinking

indicates activity on the

Ethernetnetwork.

WLAN LED: A solid light

indicates that the wireless

segment is ready. This LED

blinks during wireless data

transmission.

Reset Button:

Used to restore

defaultsettings.

Installation OverviewInstallation Overview

Installation Overview

TheDWL-G730APoffersthreedifferent operationmodes:

AP (AccessPointMode): Inthis mode,theDWL-G730AP functionsas anaccesspoint.

Client (Client Mode): When Client mode is selected, the DWL-G730AP as a wireless

client.

RT (RouterMode): TheDWL-G730AP functionsas arouter whenthismodeisselected.

AP - Access Point Mode

When the Mode Selection Switch on the bottom of the DWL-G730AP is set to AP,

the unit is in Access Point Mode. The diagram below illustrates a typical access

point configuration.

Note:D-Link®AirPlus G wireless devicesarepre-configuredtoconnecttogether,right

out of the box, using their default settings.

Installation Overview (continued)Installation Overview (continued)

Installation Overview (continued)

Client - Client Mode

When the Mode Selection Switch on the bottom of the DWL-G730AP is set to Client,

the unit is in Client Mode. The diagram below illustrates a typical client

configuration.

Note:D-Link®AirPlus G wireless devicesarepre-configuredtoconnecttogether,right

out of the box, using their default settings.

Installation Overview (continued)Installation Overview (continued)

Installation Overview (continued)

RT - Router Mode

When the Mode Selection Switch on the bottom of the DWL-G730AP is set to RT,

the unit is in Router Mode. The diagram below illustrates a typical router

configuration.

Note:D-Link®AirPlus G wireless devicesarepre-configuredtoconnecttogether,right

out of the box, using their default settings.

AP Mode - Using the Setup WizardAP Mode - Using the Setup Wizard

AP Mode - Using the Setup Wizard

Onceyouhavelogged in, the

Home screen will appear.

Click Run Wizard

Open your Web

browser and type

http://192.168.0.30

intotheURL address

box. Then press the

Enter or Return key.

The logon pop-up screen

willappear.

Type admin for the

usernameandleavethe

passwordfieldblank.

Click OK

ToconfiguretheDWL-G730APinAPMode,youwillneedtoconnectaPCdirectlyto

theDWL-G730APusingastandardEthernetcable.Youwillneedtoassignthenetwork

adapterconnectingtotheDWL-G730APanIP addressintherangeof192.168.0.x.

Click Next

Set up your new password.

You have the option to

establishapassword.

Set Your Wireless LAN

Connection.

By default the DWL-G730AP

SSID is set to ‘default’ with a

Channel setting of ‘6’.

Click Next

AP Mode - Using The Setup WizardAP Mode - Using The Setup Wizard

AP Mode - Using The Setup Wizard

(continued)(continued)

(continued)

You will see the

followingscreens.

Click Next

Encryption

TheDWL-G730APis capableof

twolevelsof wirelessencryption

64-bit and 128-bit. By default

encryptionis disabled.Youcan

change the encryption settings

for more secure wireless

communication.

Click Next

ClickRestart

AP Mode - Using The Setup WizardAP Mode - Using The Setup Wizard

AP Mode - Using The Setup Wizard

(continued)(continued)

(continued)

Click Close

TheAPSetup Wizardiscomplete!Youwillbe returned totheHome tab. Pleaseclose all

webbrowser windows.

Client Mode - Using the Setup WizardClient Mode - Using the Setup Wizard

Client Mode - Using the Setup Wizard

Onceyouhavelogged in, the

Home screen will appear.

Click Run Wizard

Open your Web

browser and type

http://192.168.0.30

intotheURL address

box. Then press the

Enter or Return key.

The logon pop-up screen

willappear.

Type admin for the

usernameandleavethe

passwordfieldblank.

Click OK

ToconfiguretheDWL-G730APinClientMode,youwillneedtoconnectaPCdirectlyto

theDWL-G730APusingastandardEthernetcable.Youwillneedtoassignthenetwork

adapterconnectingtotheDWL-G730APanIP addressintherangeof192.168.0.x.

Client Mode - Using the Setup WizardClient Mode - Using the Setup Wizard

Client Mode - Using the Setup Wizard

(continued)(continued)

(continued)

Click Next

Set up your new password.

You have the option to

establishapassword.

Set Your Wireless LAN

Connection.

Type in your network’s SSID

or click on the Site Survey

button to see the available

SSID’s. Select the Channel

settingofyournetwork.

Click Next

You will see the

followingscreens.

Click Next
