RG-S8600 Series Switch

Hardware Installation and Reference Guide V1.78

Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation

or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of

Ruijie Networks is prohibited.

, , , , , ,

, , ,

, , are registered trademarks of Ruijie Networks. Counterfeit is

strictly prohibited.

Exemption statement

This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest

information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any

responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface

Thank you for using our products. This manual will guide you through the installation of the switch.

Scope

It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it

is assumed that the users are already familiar with the related terms and concepts.

Obtaining Technical Assistance

Ruijie Networks website: http://www.ruijienetworks.com

Online customer services: http://webchat.ruijie.com.cn

Customer service center: http://www.ruijie.com.cn/service.aspx

Customer services hotline: +86-4008-111-000

BBS: http://support.ruijie.com.cn

Customer services email: s[email protected]

Related Documents

Documents

Description

Configuration Guide

Describes network protocols and related mechanisms that supported by the

product, with configuration examples.

Command Reference

Describes the related configuration commands, including command modes,

parameter descriptions, usage guides, and related examples.

Documentation Conventions

The symbols used in this document are described as below:

This symbol draws the attention of readers to some suggestions and references.

This symbol reminds readers to be alert of wrong operations that may lead to loss of data or damage to equipment.

Chapter 1 Product Overview

The RG-8600 switch is a module-based high-density multi-service IPv6 10Gbp score routing switch developed by Ruijie

Networks, providing powerful defense capability based on high performance and capacity. It can be expanded according

to users’ business needs, satisfying the design requirements for putting equal emphasis on service and performance.

The RG-S8600 switch provides dual management boards and dual power supplies for redundancy. Currently four models

are available:

The RG-S8614: designed with 14 transverse slots, supporting dual management engine modules, providing 12 slots

for service modules.

The RG-S8610: designed with 10 vertical slots, supporting dual management engine modules and providing eight

slots for service modules.

The RG-S8606: designed with six transverse slots, supporting dual management engine modules and providing four

slots for service modules.

The RG-S8606 B: designed with six transverse slots, supporting dual management engine modules and providing

four slots for service modules.

RG-S8614

The RG-8600 switch is an A-class product and may cause radio disturbance to surroundings. In this case, users are

advised to take proper measures against the disturbance.

Specifications

Model

RG-S8614

Module Slot

14 (two for management engine modules)

Module Type

M8614-CM II

M8600-24SFP/12GT

M8600-24GT/12SFP

M8600P-24GT/12SFP

M8600-02XFP

M8600-48GT/4SFP

M8600P-48GT/4SFP

M8600-04XFP

M8600-24SFP

M8600-MPLS

M8600-NMM

M8600-02XFP24SFP/12GT-E

M8600-08XFP

M8600-VSU-02XFP

M8600-FW

RG-WALL 1600-B-E

RG-WALL 1600-B-U

RG-WALL 1600 FW Module

M8600-WS

M8600-02XFP24SFP/12GT-EC

M8600-24SFP/12GT-EC

M8600-48GT/4SFP-EC

M8600P-48GT/4SFP-EC

M8600-24GT/12SFP-EC

M8600-04XFP-EC

M8600-04QXS-DA

M8600-16XS-DA

Hot Swapping

Supported

Management

Redundancy

Supported

Power Supply

RG-PA1200:90 ~ 264VAC, 47 ~ 63Hz, power: 1200W

RG-PA1200E: 90 ~ 264VAC, 47 ~ 63Hz, power: 1200W

RG-PA2000: 90 ~ 176VAC, 47 ~ 63Hz, power: 1200W

176 ~ 264VAC, 47 ~ 63Hz, power: 2000W

RG-PA1200I: 90 ~ 176VAC, 47 ~ 63Hz, power: 530W

176 ~ 264VAC, 47 ~ 63Hz, power: 1400W

RG-PA2000I: 90 ~ 176VAC, 47 ~ 63Hz, power: 1080W

176 ~ 264VAC, 47 ~ 63Hz, power: 2000W

RG-PD1200: -36 ~ -72VDC, power: 1200W

RG-PD2000: -36 ~ -72VDC, power: 2000W

PA stands for AC power; PD stands for DC power.

Power Supply

Redundancy

The power supply redundancy of the same model is supported

Fan

GB9254-2008

EMC Standards

GB4943-2011

Safety

Standards

GB4943-2011

Operating

Temperature

0 ~ 40°C

Storage

Temperature

-40 ~ 70°C

Operating

Humidity

10% ~ 90% RH (non-condensing)

Earthquake

Resistance

Able to resist the earthquake intensity 9

Weight

≤114 kg

Dimensions

(W x D x H)

436.8 mm x 508 mm x 932.2 mm, 21 RU

Product Appearance

Figure 1-1 Appearance of the RG-S8614 Switch

Note:

Modular layer: offers up to 14 module slots

Power layer: supports up to twoAC or DC power supplies

Air outlet: Located in the back of the chassis, as the air-outlet unit of the

system.

The RG-S8614 switch’s hardware system is composed of the chassis, the power system, modules, the fan tray and

the air filter.

Chassis

The RG-S8614 switch has a standard 19-inch chassis, which is 932.2mm high, 436.8mm wide and 508mm deep. It

consists of the system modular layer, the fan layer, the air filter and the power system layer.

The system modular layer is a module subrack that mechanically supports various modules of the RG-S8614.The

modular subrack is composed of module slots and back panel.

At the bottom of the chassis are two power frames. The air filter is located on the right side of the module subrack of the

chassis, facing the front of the chassis. On the back of the module subrack is the fan layer, which houses ten fans working

to suction air.

Module Slot

The RG-S8614 switch provides 14 module slots, of which two in the middle are only for the management modules. The 12

slots on the top and the bottom can accommodate a mix of various modules. Modules are inserted horizontally, with the

same height of 412 mm, and depth of 350 mm.

When all the slots are occupied, the modules in the subrack of the RG-S8614 switch are configured as follows:

Two management modules as backup for each other

12 modules are selected according to needs

The slots for the two management modules are in the middle and identified as M1 and M2 from bottom to top; the other 12

line cards are numbered 1-12 from bottom to top.







Backplane

The RG-S8614 switch’s backplane interconnects high-speed data links from switch management board to module circuit

board and various management and control signals between modules. Its functions are as follows:

Interconnects all signals between modules and provide high-speed communication channel.

Passive backplane

Supports active/standby switching between management modules

Supports automatic identification of various slots

Implements distributed power supply

Introduces monitoring signal lines of the fan and power supply

Ventilation and Heat Dissipation System

The operating temperature of the RG-S8614 switch is 0 to 40°C. The thermal design must ensure that the surface

temperature of the components does not exceed 50% to 80% of the allowed maximum temperature and satisfy the

requirement on the device’s reliability in the temperature range while ensuring the device’s reliability, safety and

maintainability. According to the thermal design of the RG-S8614 switch, fans are used to draw air for forced convection

cooling in order to ensure that the device works properly in the specified environment.

Figure 1-2 Ventilation and Heat Dissipation System of the RG-S8614 Switch

This structure is designed with air inlet on two sides, and air outlet at the back. The air flow direction is shown above.

Ten 120 x 120 x 38 fans are used to blow air outside for convection and ultimately heat dissipation. The chassis

should be mounted in a place with sufficient space for air circulation. Sufficient space (10 cm at least) must be

reserved at the air intakes and exhaust vents for ventilation.

RG-S8610

The RG-8600 series is an A-class product and may cause radio disturbance to surroundings. In this case, users are

advised to take proper measures against the disturbance.

Specifications

Model

RG-S8610

Module Slot

10 (two for management engine modules)

Module Type

M8610-CM

M8610-CM II

M8610-CM III

M8610-CM II LITE

M8600-24SFP/12GT

M8600-24GT/12SFP

M8600P-24GT/12SFP

M8600-02XFP

M8600-48GT/4SFP

M8600P-48GT/4SFP

M8600-04XFP

M8600-24SFP

M8600-MPLS

M8600-NMM

M8600-02XFP24SFP/12GT-E

M8600-08XFP

M8600-VSU-02XFP

M8600-FW

RG-WALL 1600-B-E

RG-WALL 1600-B-U

RG-WALL 1600 FW Module

M8600-WS

M8600-02XFP24SFP/12GT-EC

M8600-24SFP/12GT-EC

M8600-48GT/4SFP-EC

M8600P-48GT/4SFP-EC

M8600-24GT/12SFP-EC

M8600-04XFP-EC

M8600-04QXS-DA

M8600-16XS-DA

Hot Swapping

Supported

Management Redundancy

Supported

Power Supply

RG-PA1200: 90 ~ 264VAC, 47 ~ 63Hz, power: 1200W

RG-PA1200E: 90 ~ 264VAC, 47 ~ 63Hz, power: 1200W

RG-PA2000: 90 ~ 176VAC, 47 ~ 63Hz, power: 1200W

176 ~ 264VAC, 47 ~ 63Hz, power: 2000W

RG-PA1200I: 90 ~ 176VAC, 47 ~ 63Hz, power: 530W

176 ~ 264VAC, 47 ~ 63Hz, power: 1400W

RG-PA2000I: 90 ~ 176VAC, 47 ~ 63Hz, power: 1080W

176 ~ 264VAC, 47 ~ 63Hz, power: 2000W

RG-PD1200: -36 ~ -72VDC, power: 1200W

RG-PD2000: -36 ~ -72VDC, power: 2000W

PA stands for AC power; PD stands for DC power.

Power Supply Redundancy

The Power supply redundancy of the same model is supported

Fan

M8610-FAN (supporting hot swapping and fault alarming)

Environmental

EMC

Standards

GB9254-2008

Safety

Standards

GB4943-2011

Operating

Temperature

0 ~ 40°C

Storage

Temperature

-40 ~ 70°C

Operating

Humidity

10% ~ 90% RH (non-condensing)

Earthquake

Resistance

Able to resist the earthquake intensity 9

Weight

≤93 kg

Dimensions

(W x D x H)

436.8 mm x 448 mm x 956 mm, 21.5 RU

Product Appearance

Figure 1-3 Appearance of the RG-S8610 Switch

Note:

Air outlet layer: the air outlet layer of the whole system, discharge air to the

outside on three sides

Fan tray: slot of the fan tray, the active heat dissipation unit of the system

Modular layer: provides 10 vertical module slots, can house modules with

different functions

Wiring layer: arranges and leads out various cables in good order while

preventing the drooping cables from blocking the air inlet

Air inlet layer: inducts air into the chassis as the airway of the whole heat

dissipation unit;

Power layer: supports up to twoAC or DC power supplies












