GO-SW-5G & GO-SW-8G

• Five/Eight 10/100/1000Mbps Ports

• Up to 1 Gbps of Dedicated Bandwidth per Port and up to

2Gbps Bandwidth in Full-Duplex mode

• Compatible with All Popular Operating Systems

• Plug & Play Installation

• Conserves energy with D-Link Green Technology

• Supports MAC address learning

Product Highlights Think Green

The GO-SW-5G/8G 5-Port and 8-Port Unmanaged Gigabit Switch is part of D-Link’s new

series of SOHO devices that make use of D-Link’s Green Technology, providing energy

savings, reduced heat, and a longer product life without sacricing performance

or functionality. An energy-ecient power adapter (EnergyStar Level V qualied),

minimized use of harmful substances (RoHS compliant), and recyclable packaging

make this switch truly environmentally friendly.

Conserves Energy

The GO-SW-5G/GO-SW-8G 5/8-Port Unmanaged Gigabit Switch helps you conserve

energy automatically. The switch saves substantial amounts of power by cutting power

usage for unused ports or ports connected to computers that have been shut down.

• Economical yet innovative fanless design runs

cool and quiet

• Gigabit ports allow you to connect all your

devices for fast file transfers and smooth

media streaming

• Reduced energy consumption without sacrificing

performance EEE compliance

5/8 Port Unmanaged Gigabit Switch

GO-SW-5G & GO-SW-8G 5/8 Port Unmanaged Gigabit Switch

Environmentally Friendly

The GO-SW-5G/GO-SW-8G 5/8-port Gigabit Unmanaged Switch was designed

with the environment in mind, and is compliant with Energy Star Level V, as well

as with the stringent CEC and MEPS regulations that require the use of energy

ecient power adapters. The switch is also built to follow RoHS standards to

minimize use of hazardous materials, and uses recyclable packaging that helps

reduce waste, complying with the WEEE directive.

Gigabit Connection for Home and SOHO

The GO-SW-5G/GO-SW-8G oers an economical way for SOHO and small to

medium businesses (SMB) to benet from the increased bandwidth of Gigabit

Ethernet. It provides ve/eight Gigabit ports for easy expansion of your network

and a quick way to upgrade your network to Gigabit connectivity.

Package Contents

• 5/8 port Gigabit Desktop Switch (GO-SW-5G/GO-SW-8G)

• Power Adapter

• Quick Install Guide

Minimum System Requirements

• Devices Supporting 802.3 Ethernet, 802.u Faster Ethernet, or

802.3ab Gigabit Ethernet

• Cat5 or better Ethernet Cable

• Network Interface Card for each computer

Features

• Built-in D-Link Green Technology

• Inexpensive Gigabit solution for Home/SOHO

• Five/Eight 10/100/1000 Mbps Gigabit ports

• 10/16 Gbps switching fabric

• Auto MDI/MDIX crossover for all ports

• Secure store-and-forward switching scheme

• Full/half-duplex for Ethernet/Fast Ethernet speeds

• IEEE 802.3x Flow Control

• Supports 9,216 Byte Jumbo Frames

• RoHS compliant

• Plug-and-play installation

GO-SW-5G & GO-SW-8G 5/8 Port Unmanaged Gigabit Switch

Technical Specications

GO-SW-5G GO-SW-8G

Switching Fabric • 10Gbps • 16Gbps

Standards • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)

• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair

copper)

• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-

pair copper)

• ANSI/IEEE 802.3 NWay auto-negotiation

• IEEE 802.3x Flow Control

• IEEE 802.3az Energy-Efficient Ethernet (EEE)

Protocol • CSMA/CD

Data Transfer Rates • Ethernet:

- 10 Mbps (half duplex), 20 Mbps (full duplex)

• Fast Ethernet:

- 100 Mbps (half duplex), 200 Mbps (full duplex)

• Gigabit Ethernet:

-2000 Mbps (full duplex)

Topology • Star

Network Cables • 10BASE-T:

- UTP CAT 3, 4, 5/5e (100 m max.)

- EIA/TIA-586 100-ohm STP (100 m max.)

• 100BASE-TX, 1000BASE-T:

- UTP CAT 5/5e (100 m max.)

- EIA/TIA-568 100-ohm STP (100 m max.)

Media Interface Exchange • Auto MDI/MDIX adjustment for all ports

LED Indicators • Per port: Link/Activity/Speed • Per device: Power

Transmission Method • Store-and-forward

MAC Address Table • 2K • 8K

MAC Address Learning • Automatic update

Packet Filtering/Forwarding Rates • Ethernet: 14,880 pps per port

• Fast Ethernet: 148,800 pps per port

• Gigabit Ethernet: 1,488,000 pps per port

RAM Buffer • 128KB per device

Jumbo Frames • 9,216 Bytes

General Specications

DC Input • External 5 V/1 A Level “V” Power Adapter

Power Consumption • DC input: 1.67 watts

• AC input: 2.7 watts

• DC input: 3.06 watts

• AC input: 3.9 watts

MTBF • 815,700 hours • 412,433 hours

Operating Temperature • 32 to 104 ˚F (0 to 40 ˚C)

Storage Temperature • 14 to 158 ˚F (-10 to 70 ˚C)

Operating Humidity • 10% to 90% RH non-condensing

All references to speed and range are for comparison purposes only. Product specications, size, and shape are subject to change without notice, and actual product appearance may dier from that depicted herein.

©2010-2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, the D-Link RoHS logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other

countries. Other trademarks or registered trademarks are the property of their respective owners.

Updated 05/18/12

For more information

Storage Humidity • 5% to 90% RH non-condensing

Dimensions • 3.8 x 3.1 x 1.1 inches (97 x 79 x 28 mm) • 5.0 x 2.7 x 1.0 inches (128 x 68.5 x 25.4 mm)

Weight • 3.688 ounces (105 grams) • 6.88 ounces (195 grams)

Certifications • FCC Class B

• ICES-003 Class B

• CE Class B

• C-Tick Class B

• VCCI Class B

• cUL/UL

• CCC

• Anatel

• LVD

Warranty

Warranty • 3-Year Limited1

Order Information

Part Number Description

GO-SW-5G 5-Port Unmanaged Gigabit Switch

GO-SW-8G 8-Port Unmanaged Gigabit Switch

13 Year Limited Warranty available only in the USA and Canada. All references to speed are for comparison purposes only. Product specications, size and shape are subject to change without notice, and actual product appearance may dier from

that depicted herein.

GO-SW-5G/GO-SW-8G 5/8-Port Gigabit Switch

GO-SW-5G GO-SW-8G
