D-Link DCS-8600LHA1 Manual de usuario

FCC: DCS-8600LH

IC: DCS-8600LHA1

User Manual

Full HD Outdoor Wi-Fi Camera

Hardware: A1

Manual Version: 1.00

08/29/2018

iD-Link DCS-8600LH User Manual

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any

person or organization of such revisions or changes. Information in this document may become obsolete as our services and

websites develop and change. Please refer to the www.mydlink.com website for the most current information.

Manual Overview

Revision Date Description

1.00 July 24, 2018 Initial release

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.

All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.

Manual Revisions

iiD-Link DCS-8600LH User Manual

Table of Contents

Product Overview..............................................................1

Package Contents......................................................................... 1

Introduction ................................................................................... 2

System Requirements.................................................................2

Hardware Overview..................................................................... 3

Front .......................................................................................... 3

Side ............................................................................................4

Bottom......................................................................................5

Back............................................................................................6

Power Adapter....................................................................... 7

Safety ................................................................................................8

Before you Begin...........................................................................8

Wireless Installation Considerations...................................... 9

Getting Started................................................................10

Mounting the Camera...............................................................10

Mounting the Power Supply ..................................................12

Setting up the Canera Through mydlink App..................14

Using the mydlink App....................................................16

Controlling Your Device ...........................................................16

Troubleshooting..............................................................21

Regulatory Information ..................................................24

1D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Product Overview

Package Contents

Note: Using a power supply with a dierent voltage rating than the one included with your produce will cause damage and void the warranty

for this product.

If any of the above items are missing, please contact your reseller.

DCS-8600LH

Full HD Outdoor Wi-Fi Camera

Power adapter

Quick Installation Guide

2D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Introduction

The D-Link DCS-8600LH Full HD Outdoor Wi-Fi Camera boasts a wide-angle lens that easily captures your entire room, wall-to-wall, in high-quality

1080p. You will know what is happening day or night with built in night vision, motion and sound detection sending notications to the mydlink™

app. The rotatable head makes discrete installations easy even on ceilings.

Network Requirements • Activated SIM card with cellular data or Wi-Fi

App-based Conguration

Utility Requirements

Smartphone with the following:

• iOS or Android-based operating system

OS Requirements:

• iOS 9.0 or higher1

• Android 4.3 or higher1

1 For iPhone, iPad, or Android, smartphones or tablets (please refer

to the mobile app's store page to check whether your device is

compatible)

System Requirements

3D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Hardware Overview

Front

1Microphone Records audio of the surrounding area.

2 Status LED

Solid Green: Camera has successfully bounded to a Wi-Fi network. Setup is complete.

Flashing Green: Live view active.

Solid Red: Powered on.

Flashing Red: Upgrading rmware. Recovery mode.

Solid Orange: Bluetooth activated.

Flashing Orange: Bluetooth pairing.

3 Camera Lens Records video of the surrounding area. An IR LED encircles it.

4 Light Sensor The IR-Cut Removable sensor monitors lighting conditions and switches between

color and infrared accordingly.

Camera Lens

Microphone

Light Sensor

Status LED

4D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Side

1Speaker Provides audio playback for the two-way audio feature.

2Power Cord Supplies power to the camera.

Speaker 1

Power Cord

5D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Bottom

1Reset Button Holding this recessed button down for at least 10 seconds resets the camera to factory default settings.

2microSD Card Slot Where a microSD card can be inserted.

3Mounting Thread 1/4x20 UNF mounting thread

Reset Button

microSD Card Slot

Mounting Thread 3

6D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Back

1Snap Mount

Indentation Where the snap mount is attached.

Snap Mount Indentation

7D-Link DCS-8600LH User Manual

Section 1 - Product Overview

Power Adapter
