D-Link DWR-953 Manual de usuario

WIRELESS AC750 4G LTE MULTI-WAN

ROUTER

DWR-953

QUICK

INSTALLATION

GUIDE

INSTALLATIONSANLEITUNG

GUIDE D’INSTALLATION

GUÍA DE INSTALACIÓN

GUIDA DI INSTALLAZIONE

INSTALLATIEHANDLEIDING

INSTRUKCJA INSTALACJI

INSTALAČNÍ PŘÍRUČKA

TELEPÍTÉSI SEGÉDLET

INSTALLASJONSVEILEDNING

INSTALLATIONSVEJLEDNING

ASENNUSOPAS

INSTALLATIONSGUIDE

GUIA DE INSTALAÇÃO

ΟΔΗΓΟΣ ΓΡΗΓΟΡΗΣ ΕΓΚΑΤΑΣΤΑΣΗΣ

VODIČ ZA BRZU INSTALACIJU

KRATKA NAVODILA ZA UPORABO

GHID DE INSTALARE RAPIDĂ

DWR-953

ENGLISH

CONTENTS OF PACKAGING

WIRELESS AC750 4G LTE MULTI-WAN ROUTER

DWR-953

If any of these items are missing from your packaging, contact your

reseller.

12 V 1.5 A POWER ADAPTER

CAT5 ETHERNET CABLE

• A broadband Internet connection

• Computer with:

• Microsoft Windows®8/7/Vista/XP, or Mac with OS X 10.6 or higher

• PC with 1.3 GHz or above and at least 128 MB RAM

• Internet Explorer 7, Firefox 12, Safari 4, or Chrome 20 or higher version with Java installed and

enabled

SYSTEM REQUIREMENTS

DWR-953 3

ENGLISH

PRODUCT SETUP

Ensure that your DWR-953 Wireless AC750 4G LTE Multi-WAN Router is powered off before

performing the steps below.

Step 1:

Insert a standard USIM card into the SIM card slot on the back of the

router with the gold contacts facing downward.

Note: Do not attempt to insert a Nano SIM or Micro SIM into the SIM

card slot.

Step 2:

If you are connecting this router to a modem,insert one end of

an Ethernet cable into the GE WAN port on the back of the router

and the other end into your wired Internet connection device.

Note: When connected to a modem, by default, the 4G connection

will be used as a backup. The router will automatically use the 4G

Internet connection if the wired connection is not available.

Step 3:

Insert the supplied Ethernet cable into a LAN port on the back panel

of the DWR-953, and an available Ethernet port on the network

adapter in the computer you will use to congure the unit.

SIM card

Router

Modem

WELCOME TO THE D-LINK SETUP WIZARD

Router

Modem

Step 5:

To congure the DWR-953

Wireless AC750 4G LTE Multi-WAN Router:

Open a web browser window and enter 192.168.0.1 into the address

bar.

Enter admin for the username and leave the password area blank.

The home conguration page will appear. Click Internet,located in

the conguration panel, followed by Wizard to congure the DWR-953.

Step 4:

Connect the power adapter to the power input on the back panel of

your DWR-953 Wireless AC750 4G LTE Multi-WAN Router, and plug

the other end of the power adapter into a wall outlet or power strip.

The Status LED on the router will light up to indicate that power has

been supplied to the router.

DWR-953

ENGLISH

1. HOW DO I CONFIGURE MY DWR-953 ROUTER OR CHECK MY WIRELESS NETWORK NAME (SSID)

AND WIRELESS ENCRYPTION KEY?

• Connect your PC to the router using an Ethernet cable.

• Open a web browser and enter the router's IP address: http://192.168.0.1

• Log into the router using the default username admin; leave the password area blank.

• Once logged in, you can use the wizard located under Internet settings to congure the router,

or make changes manually.

Note: If you have changed the password and cannot remember it, you will need to reset the

router to factory defaults.

2. HOW DO I RESET MY DWR-953 ROUTER TO FACTORY DEFAULT SETTINGS?

• If you cannot remember your router administrator password, you may use a paperclip to press

and hold the reset button on the front of the router for about 10 seconds.

Note: Resetting the router to factory default will erase the current conguration. To recongure

your router, log in as outlined in question 1, then run the Setup Wizard.

3. HOW DO I ADD A NEW WIRELESS DEVICE OR PC IF I HAVE FORGOTTEN MY WIRELESS

NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?

• Every device that needs to connect to the router wirelessly will need use the correct Wireless

Network Name (SSID) and encryption key.

• Use the web-based user interface (as described in question 1 above) to check or choose your

wireless settings.

• Make sure you write down these settings so that you can enter them into each wirelessly-

connected PC. You will nd a dedicated area on the back of this document to note this important

information down for future use.

4. WHY AM I UNABLE TO ESTABLISH AN INTERNET CONNECTION?

• If connecting using a 4G mobile connection, make sure that you are within range of the mobile

service provider, and that the service has been correctly congured.

• If connecting using the WAN via ADSL/Cable service, make sure the modem has been enabled/

connected and is operational, and that the service is correctly congured.

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

TECHNICAL SUPPORT dlink.com/support

DWR-953 5

NOTES

Ver. 1.00(EU)_130x183 2015/12/21
