LED STATUS

QUICK INSTALLATION GUIDE

DWR-910 LTE DONGLE ROUTER

ENGLISH

A GLANCE AT DWR-910 LTE DONGLE ROUTER

INSERT SIM AND MICRO SD CARDS

CONNECT THE USB

Push the SIM/Micro SD card into the card slots with the gold contact points facing

upwards.

NOTE! Please insert the SIM/Micro SD card according to the orientation of the

SIM/Micro SD card icon on the device.

The USB on the dongle can be rotated 90° or 180° according to your needs.

1. Rotate the USB to the desired angle.

2. Connect the USB plug on the dongle to the USB input port on your computer.

Ensure the plug is connected rmly.

NOTE! Rotate the antennas 90° for best signal reception.

WEB UI ACCESS

APN SETTINGS

The Web UI allows you to congure advanced settings. To access the Web UI:

1. Connect the DWR-910 LTE Dongle Router to your computer.

2. Enter “192.168.0.1” or “http://dlink.DWR-910” as the URL in your Web

browser to access the Web UI; the Web UI login screen will then appear.

ESTABLISH A NETWORK CONNECTION

The device supports USB Connection and Wi-Fi Connection methods to

access the Internet.

Modem Mode (USB Connection)

Plugging the dongle into your computer’s USB port will allow you to access the

Internet or the Web UI. The device will automatically install driver on rst time

usage.

1. Log in to Web UI.

2. Click the Setup Wizard icon on the main page of the Web UI. The default

APN Prole setting for DWR-910 is set to Auto. The device will match the

APN Prole with your SIM card automatically.

However, if APN Prole cannot be matched, you can enter the related

information manually. For detailed information please refer to your service

provider.

SIM Card Slot

Micro SD Card Slot

MicroSD

LED Indicators

Wi-Fi/ 4G/Signal

Antenna

USB

Antenna

TMTM

WPSButton

Micro SD

MicroSD

180

TMTM

Wi-Fi LTE Signal

Solid Idle Red No data connection

Green Connected with 3G

Purple Connected with 2G

Blue Connected with LTE

Orange Roaming in another

operator’s network

Blinking Number

of clients

currently

connected

to the device

Data traffic Blink once Signal weak

Blink twice Signal fair

Blink three

times

Signal

strong

Router Mode (Wi-Fi connection)

Wi-Fi

1. Search for the Wi-Fi signal broadcast by the device on other client devices

such as a computer, mobile phone, tablet PC, or game console.

2. Establish a connection by selecting the device’s network name (SSID) and

password. The default SSIDs are:

SSID1: dlink_DWR-910_xxxx (Password: 10 digits), user can nd the

default SSID and Wi-Fi key on the label of this device.

SSID2: dlink_DWR-910.1 (This is a hidden SSID. Security method: WPA2;

password: 1234567890).

3. The default settings will allow the device to automatically connect to the

Internet.

Note! If you encounter a WAN connection failure, please login to the Web UI

and congure the APN manually.
