D-Link DWL-3150 Manual de usuario

Wireless G USB 2.0 Adapter

Wireless Internet Camera

with 3G Mobile Video

2D-Link DWL-3150 Install Guide

• CD-ROM Drive.

• Computers with Windows®, Macintosh®, or Linux-based operating

systems.

• Installed Ethernet Adapter Internet Explorer version 6.0 or Netscape

Navigator™version 7.0 and above.

Minimum System Requirements

Package Contents

If any of the above items are missing, please contact your reseller.

Manual, Install Guide,

software, and warranty

on CD

CAT5 Ethernet Cable

D-Link DWL-3150

802.11g Wireless Bridge

5VDC 2A Power Adapter

Using a power adapter with a different

voltage rating will damage and void

the warranty of this product.

3 D-Link DWL-3150 Install Guide

Installation Considerations

D-Link wireless devices allow you access your network using a wireless connection

from virtually anywhere within the operating range of your wireless network. Keep

in mind, however, that the number, thickness and location of walls, ceilings, or

other objects that the wireless signals must pass through, may limit the range.

Typical ranges vary depending on the types of materials and background RF (radio

frequency) noise in your home or business. The key to maximizing wireless range

is to follow these basic guidelines:

1. Keep the number of walls and ceilings between the D-Link access point

and other network devices to a minimum - each wall or ceiling can reduce

your adapter’s range from 3-90 feet (1-30 meters.) Position your devices

so that the number of walls or ceilings is minimized.

2. Be aware of the direct line between network devices. A wall that is 1.5

feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet (1

meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick!

Position devices so that the signal will travel straight through a wall or

ceiling (instead of at an angle) for better reception.

3. Building Materials make a difference. A solid metal door or aluminum

studs may have a negative effect on range. Try to position access points,

wireless routers, and computers so that the signal passes through drywall

or open doorways. Materials and objects such as glass, steel, metal, walls

with insulation, water (ﬁsh tanks), mirrors, ﬁle cabinets, brick, and concrete

will degrade your wireless signal.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical

devices or appliances that generate RF noise.

5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as

ceiling fans, lights, and home security systems), your wireless connection

may degrade dramatically or drop completely. Make sure your 2.4GHz

phone base is as far away from your wireless devices as possible. The

base transmits a signal even if the phone in not in use.

4D-Link DWL-3150 Install Guide

Connect Power SupplyConnect Ethernet Cable

Insert the supplied Ethernet cable to the DWL-3150 and connect the

other end to your computer or network.

5 D-Link DWL-3150 Install Guide

Connect Power Supply

Insert the supplied power supply to the DWL-3150 and plug the other

end into an outlet or power strip. The unit will power on.

6D-Link DWL-3150 Install Guide

Connect a standard Ethernet cable from the DWL-3150 to an Ethernet

port on the computer that will be used to conﬁgure the DWL-3150.

You must assign your computer a static IP address within the same

range as the IP address of the DWL-3150. The DWL-3150’s default

IP address is 192.168.0.30 with a Subnet Mask of 255.255.255.0.

If your network is using another network (I.E. 192.168.1.xxx), then

conﬁgure only 1 computer using the steps below.

Step 1

Windows®XP - Click on Start > Control Panel > Network

Connections.

Windows®2000 - From the desktop, right-click My Network Places

> Properties.

Step 2

Right-click on the Local Area Connection which represents your

D-Link network adapter and select Properties.

Step 3

Highlight Internet Protocol (TCP/IP) and click Properties.

Step 4

Click Use the following IP address and enter an IP address of

192.168.0.10 and a subnet mask of 255.255.255.0. Do not enter a

gateway or DNS server address.

Step 5

Click OK twice to save your settings.

You will now be able to connect to the DWL-3150 to conﬁgure it. Once

conﬁgured, you may change your computer’s IP settings back.

Using the Setup Wizard

7 D-Link DWL-3150 Install Guide

Using the Setup Wizard

Open your Web browser

and type http://192.168.0.30 into

the URL address box.Then press

the Enter or Return key.

Click OK.

The logon pop-up screen will appear.

Type admin for the username and

leave the password ﬁeld blank.

Once you have logged in, the main page will appear.

8D-Link DWL-3150 Install Guide

Technical Support

D-Link’s website contains the latest user documentation and

software updates for D-Link products.

U.S. and Canadian customers can contact D-Link Technical

Support through our website or by phone.

United States

Telephone

(877) 453-5465

World Wide Web

http://support.dlink.com

Canada

Telephone

(800) 361-5265

World Wide Web

http://support.dlink.com

Version 1.0

March 1, 2007

trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property

of their respective owners. Maximum wireless signal rate based on IEEE Standard 802.11g speciﬁcations. Actual data throughput

will vary. Network conditions and environmental factors, including volume of network trafﬁc, building materials and construction,

and network overhead lower actual data throughput rate. Product speciﬁcations, size and shape are subject to change without

notice, and actual product appearance may differ from that depicted on the packaging. Visit www.dlink.com for more details.
