D-Link DIR-825M Manual de usuario

DIR-825M

AC1200 MU-MIMO Wi-Fi Gigabit Router

BEFORE YOU BEGIN

Delivery Package

Default Settings

• Router DIR-825M

• Power adapter DC 12V/1A

• Ethernet cable

• “Quick Installation Guide” (brochure).

If any of the items are missing, please contact your reseller.

The “User Manual” and “Quick Installation Guide” documents are available

on D-Link website.

IP address of router: 192.168.0.1

Username (login): admin

Password: (as printed on the device label)

dlink-825M-2.4G-xxxx

dlink-825M-5G-xxxx

Wireless Password: (as printed on the device label)

Using a power supply with a diﬀerent voltage rating than the one included

will cause damage and void the warranty for this product.

Name of wireless

network (SSID):

The router DIR-825M with default settings cannot connect to the

Internet.To get started, please set your own password for access to the

web-based interface and change the WLAN name (SSID); then, if

needed, conﬁgure other settings recommended by your ISP.

SYSTEM REQUIREMENTS AND EQUIPMENT

SAFETY RULES AND CONDITIONS

• A computer with any operating system that supports a web browser.

• A web browser to access the web-based interface of the router: Apple Safari 8

and later, Google Chrome 48 and later, Microsoft Internet Explorer 10 and later,

Microsoft Edge 20.10240 and later, Mozilla Firefox 44 and later, Opera 35 and

later.

• A NIC (Ethernet or Wi-Fi adapter) to connect to the router.

• An 802.11a, b, g, n, or ac Wi-Fi adapter to connect to a wireless network.

Please carefully read this section before inﬆallation and connection of the device.

Make sure that the power adapter and cables are not damaged. The device should

be used only as intended in accordance with the documents.

The device is intended for use in dry, clean, duﬆ-free, and well ventilated areas with

normal humidity away from ﬆrong heat sources. Do not use the device outdoors or

in the areas with high humidity. Do not place foreign objects on the device. Do not

obﬆruct the ventilation openings of the device. The environmental temperature near

the device and the temperature inside the device's cover should be within the range

from 0 °С to +40 °С.

Only use the power adapter supplied with the device. Do not plug in the adapter, if

its case or cable are damaged. Plug the adapter only into working electrical outlets

with parameters indicated on the adapter.

Do not open the cover of the device! Unplug the device before duﬆing and cleaning.

Use a damp cloth to clean the device. Do not use liquid/aerosol cleaners or magnet-

ic/ﬆatic cleaning devices. Prevent moiﬆure getting into the device or the

poweradapter.

1. Connect the power cord to the power connector port on the back panel of the

router, then plug the power adapter into an electrical outlet or power strip.

2. Connect the router to your PC.

3. Start a web browser. In the address bar of the web browser, enter the

IPaddress of the router (by default, 192.168.0.1). Press the Enter key.

After the ﬁrs t access to the web-based interface you are forwarded to the s tart

page of the Setup Wizard.

4. Click the Next button.

5. Select a Mode (Router, Bridge/AP or WISP)

6. Click the Next button in order to conﬁgure the device with the Setup

Wizard or the Cancel button to conﬁgure all needed setting manually.

When the web-based interface is accessed the next time and after, the login page

opens. Enter the username (admin) in the Username ﬁeld and the password you

speciﬁed in the Password ﬁeld, then click the LOGIN button.

Use the menu in the top part of the page to conﬁgure the router.

To exit the web-based interface, select the Logout menu section.

CONNECTION AND CONFIGURATION

• PC with Ethernet adapter: Connect an Ethernet cable between an available

Ethernet port of the router and the Ethernet port of your PC. Turn on the router by

pressing the POWER button on its back panel. Make sure that the Ethernet

adapter of your PC is conﬁgured to obtain an IP address automatically.

• PC with Wi-Fi adapter: Turn on the router by pressing the POWER button on its

back panel. Make sure that the Wi-Fi adapter of your PC is on and conﬁgured to

obtain an IP address automatically. Connect to the network

(for operating in the 2.4GHz band) or dlink-825M-5G-xxxx (for operating in the

5GHz band). Use wireless password from the device label.

dlink-825M-2.4G-xxxx

Ques tion 1. How do I reset the router to the factory

default settings?

You can restore the factory default settings via the hardware RESET button

located on the back side of the router.

1. Use a small paperclip to activate the button; insert it into the hole (with the

device turned on), push, and hold for 10 seconds.

2. Release the button and wait until the router is rebooted (about a minute

or two).

Then access the web-based interface (see the Default Settings section of the

present document) and conﬁgure all needed settings.

Ques tion 2. What can I do if my router is not working

correctly?

Below are some steps applicable to the most common issues.

1. Check the LEDs on the top panel of the router. The following LEDs should be

solid or blinking blue : POWER, INTERNET, LAN (corresponding to the LAN

ports of the router to which devices from the router's local area network are

connected), 2.4GHz WLAN and 5GHz WLAN (if the 2.4GHz or 5GHz wireless

network correspondingly is ON and in use).

2. Make sure that all cables are connected properly.

3. Power oﬀ the router for 20 seconds, then power it on again.

Ques tion 3. Why am I unable to connect to the Internet?

Contact your ISP to make sure that the relevant service is available and that you

use correct connection settings.

TROUBLESHOOTING

TECHNICAL SUPPORT

You can ﬁnd software updates and user documentation

on the D-Link website.

Tech Support for cus tomers in:

D-Link Middle East - Dubai, U.A.E.

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

Technical Support Call Center: +20 2258 66777

General Inquiries: [email protected]

Tech Support : [email protected]

Kingdom of Saudi Arabia

Technical Support: +966 1121 70009

General Inquiries: [email protected]

Tech Support: [email protected]

Pakistan

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

Phone oﬃce: +212 700 13 14 15

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait

Email: [email protected]

South Africa

Technical Support: +27-08600-35465, 012 741 2000

Tech Support: [email protected]

Latin America

la.dlink.com/la/soporte

2020/11/2 F1500022
