DSL-504T User’s Manual

D-Link Systems, Inc.

Table of Contents

Table of Contents ...............................................................................................2

Package Contents ..............................................................................................4

Installation Overview ..........................................................................................5

Installation Requirements ..................................................................................6

Information you will need from your ADSL service provider ..............................8

Information you will need about your DSL-504T ADSL service router ...............9

Information you will need about your LAN or computer ..................................10

Introduction .....................................................................................................11

Features and Beneﬁts .......................................................................................12

Standards Compatibility & Compliance ............................................................14

Front Panel Display ..........................................................................................16

Rear Panel Connections ...................................................................................17

Hardware Installation .......................................................................................18

Power ON Router .............................................................................................19

Network Connections ....................................................................................... 20

Basic Router Conﬁguration ..............................................................................22

Access the Conﬁguration Manager ..................................................................29

Conﬁgure the Router ......................................................................................31

Using the Setup Wizard ....................................................................................33

Conﬁguring the WAN connection ..................................................................... 46

LAN IP Settings ................................................................................................55

DHCP Server Settings ......................................................................................56

DNS Server Settings ........................................................................................58

DSL-504T User’s Manual

D-Link Systems, Inc.

Advanced Settings ...........................................................................................60

Tools ................................................................................................................72

Status ...............................................................................................................79

Multiple Virtual Connections ............................................................................83

Technical Speciﬁcations ...................................................................................85

Appendix A: IP Address Setup .........................................................................87

Appendix B: IP Concepts ..................................................................................90

Appendix C: Microﬁlters & Splitters ................................................................. 93

Contacting Technical Support ..........................................................................95

Warranty ..........................................................................................................96

Registration .....................................................................................................99

Table of Contents

DSL-504T User’s Manual

D-Link Systems, Inc.

Package Contents

 D-Link DSL-504T

ADSL Ethernet Router

 One twisted-pair telephone cable used for ADSL connection

 One straight-through Ethernet cable

 Manual on CD

 Quick Installation Guide

 One AC power adapter

If any of the above items are missing, please contact your reseller.

DSL-504T User’s Manual

D-Link Systems, Inc.

Installation Overview

The procedure to install the Router can be described in general terms in the following

steps:

1. Gather information and equipment needed to install the device. Before you

begin the actual installation make sure you have all the necessary information

and equipment.

2. Install the hardware, that is, connect the cables (Ethernet and telephone) to

the device and connect the power adapter.

3. Check the IP settings on your computer and change them if necessary so the

computer can access the web-based software built into the Router.

4. Use the web-based management software to conﬁgure the device to suit the

requirements of your ADSL account.

DSL-504T User’s Manual

D-Link Systems, Inc.

Installation Requirements

In order to establish a connection to the Internet it will be necessary to provide

information to the Router that will be stored in its memory. For some users, only

their account information (Username and Password) is required. For others, various

parameters that control and deﬁne the Internet connection will be required. You can

print out the two pages below and use the tables to list this information. This way you

have a hard copy of all the information needed to setup the Router. If it is necessary to

reconﬁgure the device, all the necessary information can be easily accessed. Be sure

to keep this information safe and private.

Low Pass Filters

Since ADSL and telephone services share the same copper wiring to carry their

respective signals, a ﬁltering mechanism may be necessary to avoid mutual interference.

A low pass ﬁlter device can be installed for each telephone that shares the line with the

ADSL line. These ﬁlters are easy to install passive devices that connect to the ADSL

device and/or telephone using standard telephone cable. Ask your service provider for

more information about the use of low pass ﬁlters with your installation.

Operating Systems

The DSL-504T uses an HTML-based web interface for setup and management. The

web conﬁguration manager may be accessed using any operating system capable

of running web browser software, including Windows 98 SE, Windows ME, Windows

2000, and Windows XP.

Web Browser

Any common Web browser can be used to conﬁgure the Router using the web

conﬁguration management software. The program is designed to work best with more

recently released browsers such as Opera, Microsoft Internet Explorer® version 5.0,

Netscape Navigator® version 4.7, or later versions. The web browser must have

JavaScript enabled. JavaScript is enabled by default on many browsers. Make sure

JavaScript has not been disabled by other software (such as virus protection or web

user security packages) that may be running on your computer.

Ethernet Port (NIC Adapter)

Any computer that uses the router must be able to connect to it through the Ethernet

port on the Router. This connection is an Ethernet connection and therefore requires

that your computer be equipped with an Ethernet port as well. Most notebook computers

are now sold with an Ethernet port already installed. Likewise, most fully assembled

desktop computers come with an Ethernet NIC adapter as standard equipment. If your

computer does not have an Ethernet port, you must install an Ethernet NIC adapter

before you can use the Router. If you must install an adapter, follow the installation

instructions that come with the Ethernet NIC adapter.

DSL-504T User’s Manual

D-Link Systems, Inc.

Additional Software

It may be necessary to install software on your computer that enables the computer to

access the Internet. Additional software must be installed if you are using the device a

simple bridge. For a bridged connection, the information needed to make and maintain

the Internet connection is stored on another computer or gateway device, not in the

Router itself.

If your ADSL service is delivered through a Dynamic, PPPoE/PPPoA, Static, or Bridge

connection, the information needed to establish and maintain the Internet connection

can be stored in the Router. In this case, it is not necessary to install software on your

computer. It may however be necessary to change some settings in the device, including

account information used to identify and verify the connection.

All connections to the Internet require a unique global IP address. For bridged

connections, the global IP settings must reside in a TCP/IP enabled device on the LAN

side of the bridge, such as a PC, a server, a gateway device such as a router or similar

ﬁrewall hardware. The IP address can be assigned in a number of ways. Your network

service provider will give you instructions about any additional connection software or

NIC conﬁguration that may be required.

DSL-504T User’s Manual

D-Link Systems, Inc.

Information you will need from your ADSL service provider

Username This is the Username used to log on to your ADSL service provider’s

network. It is commonly in the form - user@isp.com. Your ADSL service

provider uses this to identify your account.

Password This is the Password used, in conjunction with the Username above, to

log on to your ADSL service provider’s network. This is used to verify

the identity of your account.

Connection

Protocol This is the method your ADSL service provider uses to send and

receive data between the Internet and your computer. Your Modem

supports the following connection protocols: Dynamic, PPPoE/PPPoA,

Static, or Bridge.

Protocol This is the method your ADSL service provider will use to verify your

Username and Password when you log on to their network. Your

Modem supports the PAP and CHAP protocols.

VPI This is the Virtual Path Identiﬁer (VPI). It is used in conjunction with the

Virtual Channel Identiﬁer (VCI) below, to identify the data path between

your ADSL service provider’s network and your computer.

VCI This is the Virtual Channel Identiﬁer (VCI). It is used in conjunction with

the VPI above to identify the data path between your ADSL service

DSL-504T User’s Manual

D-Link Systems, Inc.

Information you will need about your DSL-504T ADSL router

Username This is the Username needed access the Modem’s management

interface. When you attempt to connect to the device through a

web browser you will be prompted to enter this Username. The default

Username for the Modem is admin. This is a default setting and can

NOT be changed.

Password This is the Password you will be prompted to enter when you access

the Modem’s management interface. The default Password is admin.

This may be changed by the user.

LAN

Subnet

Mask for

the

This is the subnet mask used by the DSL-504T, and will be used

throughout your LAN. The default subnet mask is 255.255.255.0. This

can be changed later.

LAN IP

addresses

for the

DSL-504T

This is the IP address you will enter into the Address ﬁeld of your web

browser to access the Modem’s conﬁguration graphical user interface

(GUI) using a web browser. The default IP address is 192.168.1.1 and

it is referred to as the “Management IP” address in this User’s Manual.

This may be changed to suit any IP address scheme the user desires.

This address will be the base IP address used for DHCP service on

the LAN when DHCP is enabled.

DSL-504T User’s Manual

D-Link Systems, Inc.

Information you will need about your LAN or computer

Ethernet NIC If your computer has an Ethernet NIC, you can connect the

DSL-504T to this Ethernet port using an Ethernet cable. You can

also use the Ethernet port on the DSL-504T to connect to other

Ethernet devices, such as a Wireless Access Point.

DHCP Client

status Your DSL-504T ADSL Modem is conﬁgured, by default, to be

a DHCP server. This means that it can assign an IP address,

subnet mask, and a default gateway address to computers

on your LAN. The default range of IP addresses the DSL-

504T will assign are from 192.168.1.2 to 192.168.1.254. Your

computer (or computers) needs to be conﬁgured to Obtain an

IP address automatically (that is, they need to be conﬁgured as

It is recommended that your collect and record this information here, or in some other

secure place, in case you have to re-conﬁgure your ADSL connection in the future.

Once you have the above information, you are ready to setup and conﬁgure your

DSL-504T ADSL Router.

The Modem may be reset to its factory default settings by performing a

Restore settings operation within the management interface (see System

Commands). If you cannot gain access to the management interface, you

may opt to use the Reset button on the rear panel of the device).

Otros manuales para DSL-504T

Tabla de contenidos

Otros manuales de Enrutador de red de D-Link

D-Link

D-Link DES-1005 Manual de usuario

D-Link

D-Link DIR-410 Manual de usuario

D-Link

D-Link DGS-1224T - Web Smart Switch Manual de usuario

D-Link

D-Link DIR-516 Manual de usuario

D-Link

D-Link TM DES-6500 Manual de usuario

D-Link

D-Link DSL-504T Manual de usuario

D-Link

D-Link DSL-2750U Manual de usuario

D-Link

D-Link DWC-1000 Manual de usuario

D-Link

D-Link DI-824VUP+ 2.4GHz Wireless VPN Router and Print... Manual de usuario

D-Link

D-Link DWR-930M Manual de usuario

D-Link

D-Link Amplifi DIR-657 Manual de usuario

D-Link

D-Link DES-1316 - Switch Manual de usuario

D-Link

D-Link DES-1024DG Manual de usuario

D-Link

D-Link DSL-2888A Manual de usuario

D-Link

D-Link DIR-850L Manual de usuario

D-Link

D-Link DWR-921 Guía de configuración

D-Link

D-Link AC1200 Manual de usuario

D-Link

D-Link DSL-G256DG Manual de usuario

D-Link

D-Link DGS-3700 Series Manual de usuario

D-Link

D-Link SmartPro DGS-1500 Series Manual de usuario

D-Link

D-Link DIR-605L Manual de usuario

D-Link

D-Link DVG-N5402G/ACF Manual de usuario

D-Link

D-Link DSL-2750U Hoja de información del producto

D-Link

D-Link DIR-853 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
