D-Link DIR-620 Manual de usuario

Quick Installation Guide

DIR-620

Multifunction Wireless Router

Supporting WiMAX, 3G GSM/CDMA

ith Built-in S itch

DIR-620 Quick Installation Guide

BEFORE YOU BEGIN

Delivery Package

•Wireless router DIR-620

•Power adapter DC 5V/2.5A

•Ethernet able (CAT 5E)

•“Quick Installation Guide” (bro hure).

If any of the items are missing, please onta t your reseller.

The “User Manual” and “Quick Installation Guide” do uments in Russian

and English are available on D-Link website (see ftp.dlink.ru/pub/Router/DIR-

620/Des ription/RevD/).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

Default Settings

IP address o wireless router 192.168.0.1

Username (login) admin

Password admin

Name o wireless network (SSID) DIR-620

DIR-620 Quick Installation Guide

System Requirements and Equipment

•A omputer with any operating system that supports a web browser.

•A web browser to a ess the web-based interfa e of the router: Windows

Internet Explorer, Mozilla Firefox, or Opera.

•A NIC (Ethernet or Wi-Fi adapter) to onne t to the router.

•An 802.11b, g, or n Wi-Fi adapter to reate a wireless network.

•A USB modem to onne t to the Internet1.

◦A WiMAX USB modem to onne t to the Internet via a WiMAX

network.

Some WiMAX operators require subs ribers to a tivate their WiMAX

USB modems prior to using them. Please, refer to onne tion

guidelines provided by your operator when on luding the agreement

or pla ed on its website.

◦A 3G USB modem to onne t to the Internet via a 3G GSM or

CDMA network.

Your USB modem should be equipped with an a tive identifi ation

ard (SIM or R-UIM) of your operator.

For CDMA USB modems, it is required to disable the PIN ode he k

on the identifi ation ard prior to onne ting the USB modem to the

router.

1 Conta t your operator to get information on the servi e overage and fees.

DIR-620 Quick Installation Guide

Supported USB Modems

GSM modems

•Huawei E1550

•Huawei E160G

•Huawei E169G

•Huawei E171

•Huawei E220

•ZTE MF112

•ZTE MF192

•ZTE MF626

•ZTE MF627

•ZTE MF652

•ZTE MF668

•ZTE MF752

CDMA modems2

•Airplus MCD-650

•Airplus MCD-800

•AnyDATA ADU-300A

•AnyDATA ADU-310A

•WeTele om WM-D200

WiMA modem

•Samsung SWC-U200 (firmware version u200_rev1-2.7.40-CI14)

!The manufa turer does not guarantee proper operation of the router

with every modifi ation of the firmware of USB modems.

2 Performan e of CDMA USB modems is not tested for the urrent firmware version.

DIR-620 Quick Installation Guide

CONNECTING TO PC

PC wit Et ernet Adapter

1. Make sure that your PC is powered off.

2. Conne t an Ethernet able between any of LAN ports lo ated on the ba k

panel of the router and the Ethernet port of your PC.

3. To onne t via a WiMAX, 3G GSM or CDMA network: onne t your

USB modem to the USB port3 lo ated on the ba k panel of the router.

!If you need to onne t or hange a USB modem to another one when

the router is powered on, power off the router, onne t the modem to

the USB port, and power on the router.

4. Conne t the power ord to the power onne tor port on the ba k panel of

the router, then plug the power adapter into an ele tri al outlet or power

strip.

5. Turn on your PC and wait until your operating system is ompletely

loaded.

Now you should onfigure your PC to obtain an IP address automati ally (as

DHCP lient).

3 It is re ommended to use a USB extension able to onne t a USB modem to the

router.

DIR-620 Quick Installation Guide

Obtaining IP Address Automatically

in OS Windows XP

1. Cli k the Start button and pro eed to the Control Panel > Network

and Internet Connections > Network Connections window.

2. In the Network Connections window, right- li k the relevant Local

Area Connection i on and sele t the Properties line in the menu

displayed.

3. In the Local Area Connection Properties window, on the General

tab, sele t the Internet Protocol (TCP/IP) line. Cli k the Properties

button.

DIR-620 Quick Installation Guide

4. Sele t the Obtain an IP address automatically and Obtain DNS

server address automatically radio buttons. Cli k the OK button.

5. Cli k the ОК button in the onne tion properties window.

Now your omputer is onfigured to obtain an IP address automati ally.

DIR-620 Quick Installation Guide

Obtaining IP Address Automatically

in OS Windows 7

1. Cli k the Start button and pro eed to the Control Panel window.

2. Sele t the Network and Sharing Center se tion. (If the Control Panel

has the ategory view (the Category value is sele ted from the View by

drop-down list in the top right orner of the window), hoose the View

network status and tasks line under the Network and Internet

se tion.)

3. In the menu lo ated on the left part of the window, sele t the Change

adapter settings line.

4. In the opened window, right- li k the relevant Local Area Connection

i on and sele t the Properties line in the menu displayed.

5. In the Local Area Connection Properties window, on the

Networking tab, sele t the Internet Protocol Version 4 (TCP/IPv4)

line. Cli k the Properties button.

DIR-620 Quick Installation Guide

6. Sele t the Obtain an IP address automatically and Obtain DNS

server address automatically radio buttons. Cli k the OK button.

7. Cli k the OK button in the onne tion properties window.

Now your omputer is onfigured to obtain an IP address automati ally.

DIR-620 Quick Installation Guide

PC wit Wi-Fi Adapter

1. To onne t via a WiMAX, 3G GSM or CDMA network: onne t your

USB modem to the USB port4 lo ated on the ba k panel of the router.

!If you need to onne t or hange a USB modem to another one when

the router is powered on, power off the router, onne t the modem to

the USB port, and power on the router.

2. Conne t the power ord to the power onne tor port on the ba k panel of

the router, then plug the power adapter into an ele tri al outlet or power

strip.

3. Turn on your PC and wait until your operating system is ompletely

loaded.

4. Turn on your Wi-Fi adapter. As a rule, modern notebooks with built-in

wireless NICs are equipped with a button or swit h that turns on/off the

wireless adapter (refer to your PC do uments). If your PC is equipped

with a pluggable wireless NIC, install the software provided with your

Wi-Fi adapter.

Now you should onfigure your Wi-Fi adapter.

4 It is re ommended to use a USB extension able to onne t a USB modem to the

router.
