D-Link EXO AC2000 Manual de usuario

AC2000 Wi-Fi Range Extender

Quick Install Guide

DAP-1820

2DAP-1820 Install Guide

Package Contents

DAP-1820 AC2000 Wi-Fi Range Extender

Quick Install Card

Quick Install Guide

If any of the above items are missing, please contact your reseller.

• Make sure the area that you want to plug the extender into has a

strong connection to your router. Use a wireless laptop, tablet, or

mobile phone in that area to test the connection to verify.

• If your wireless router or access point does not support WPS, follow

the steps under Congure the DAP-1820 Using D-Link Wi-Fi Setup to

connect to the DAP-1820 and run the Setup Wizard. If you are not

sure how to enable WPS on your wireless router, please refer to your

router’s user manual.

Before You Begin

DAP-1820 Install Guide 3

Product Overview

LED Color Status Description

Status LED

Red Solid The device is powering on.

Amber Blinking The device is ready but not connected to a router.

Green

Solid Indicates that the DAP-1820 is securely connected

to your wireless router or access point.

Blinking The WPS button has been pushed and the device is

processing a connection.

Signal Strength Indicators

Very Weak (Amber)

Weak (1 x Green)

Good (2 x Green)

Strong (3 x Green)

Signal

Strength

Indicators

Status

LED

WPS

Button

Ethernet

Port

Reset

Button

4DAP-1820 Install Guide

Method One: Connect to Your

Router Using WPS

1Find an available outlet near your wireless router.

Plug in the DAP-1820 and wait until the Status

LED is blinking amber.

2Press the WPS (Wi-Fi Protected Setup) button

on your wireless router.

Within one minute, press the WPS button on

the DAP-1820. The Status LED will start to blink.

WPS

DAP-1320

There are two easy ways to set up your DAP-1820.

It is recommened that you use Method One if your router has a WPS

button. If your router does not support WPS or you are not sure, see

Method Two, Congure the DAP-1820 Using D-Link Wi-Fi Setup, on page 6.

DAP-1820 Install Guide 5

4When the Status LED turns solid green, this indicates that the DAP-1820 is

securely connected to your wireless router or access point. You can now unplug

and move the DAP-1820 to a location between your wireless router and the

area that you need wireless coverage.

If after moving your DAP-1820, the signal strength

indicators are showing one single amber bar or if the

DAP-1820 is not connecting (Status LED is no longer

green), move the DAP-1820 to a wall outlet closer to

your wireless router or access point.

Note: WPS may not be enabled on all Routers or Modems. If

the Status LED on your Range Extender does not turn solid

green after running WPS setup, try again. If it still does not

turn solid green, see Congure the DAP-1820 Using D-Link

Wi-Fi Setup, on page 6.

Your setup is complete!

6DAP-1820 Install Guide

Method Two: Congure the

DAP-1820 Using D-Link Wi-Fi Setup

1Scan the code below or search “D-Link Wi-Fi” (App Store or Google Play) to

download the D-Link Wi-Fi App to your iPhone, iPad, or Android device.

Once your app is installed, tap on the D-Link Wi-Fi icon from your mobile

device. Please follow the on-screen instructions to complete the setup.

When asked to scan the setup QR Code, scan the QR Code located on

the Quick Install Card.

SmartConnect: By default, SmartConnect is enabled on this Range Extender.

SmartConnect will automatically steer your device to the optimal wireless

band according to current network trac. When enabled, you will only see

one wireless network from your Range Extender.

iOS Android D-Link Wi-Fi App

Your setup is complete!

Quick Install Card

DAP-1820 Install Guide 7

Troubleshooting

Why is my DAP-1820 not connecting or dropping signal from my router?

1. Verify that the DAP-1820 is within range of your wireless router. Try plugging it into

a location closer to the router and verify the Status LED is solid green.

Note: When repeating a wireless signal from a router or access point, devices

connected to the repeater will not get the same speed/throughput as when

connected directly to the router.

How do I change the wireless settings on the DAP-1820?

1. Open a web browser (e.g., Internet Explorer, Firefox, Chrome, or Safari) and go to

http://dlinkap.local./

2. At the login screen, enter your password and click Log in.

3. Go to Settings > Extender.

4. Enter a new Wi-Fi Network Name (SSID) and modify the security (Wi-Fi password)

settings as needed.

5. Click Save.

Note: If you have changed the Wi-Fi Network name, the device you are currently using to connect to the

DAP-1820 will drop. You will need to open your wireless utility and connect to the DAP-1820 using the

new network name and password.

8DAP-1820 Install Guide

Where should I place my DAP-1820 when using it as a range extender?

A Range Extender only works as well as the signal it is extending.

Therefore, proper placement of your DAP-1820 is important in

achieving desired results.

For best performance, place your DAP-1820 in between your

router and your dead zone, making sure it is placed in a location

where theWi-Fi signal is still strong. Use the Smart Signal Indicator

to help nd a location with a strong signal. The more bars lit on

the signal indicator, the stronger the Wi-Fi signal is.

Poor

location

Ideal

location

Poor

location

Ideal

location

DAP-1820 Install Guide 9

What if I forgot my DAP-1820 password?

1. If you forgot your password or want to reset the DAP-1820

back to the factory default settings, press and hold the

reset button on the bottom of the extender using a paper

clip and release after a minimum of 10 seconds. The Status

light will turn red.

Note: This process will erase all your settings.

2. You may repeat the WPS process on page 4. Follow the

steps under Connect to Your Router Using WPS.

Reset

Button

What if WPS setup is not working?

WPS may not be enabled on all Routers or Modems. If the

Status LED on your Range Extender does not turn solid

green after running WPS setup, try again. If it still does not

turn solid green, see Congure the DAP-1820 Using D-Link

Wi-Fi Setup, on page 6.

10 DAP-1820 Install Guide

GPL Code Statement

This D-Link product includes software code developed by third parties, including

software code subject to the GNU General Public License (“GPL”) or GNU Lesser

General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL,

and information on obtaining access to the GPL code and LGPL code used in this

product, are available to you at:

http://tsd.dlink.com.tw/GPL

The GPL code and LGPL code used in this product is distributed WITHOUT ANY

WARRANTY and is subject to the copyrights of one or more authors. For details,

see the GPL code and the LGPL code for this product and the terms of the GPL and

LGPL.

Written Oer for GPL and LGPL Source Code

Where such specic license terms entitle you to the source code of such software,

D-Link will provide upon written request via email and/or traditional paper mail the

applicable GPL and LGPLsource code les via CD-ROM for a nominal cost to cover

shipping and media charges as allowed under the GPL and LGPL.

Please direct all inquiries to:

Email:

GPLC[email protected]

Snail Mail:

Attn: GPLSOURCE REQUEST

D-Link Systems, Inc.

17595 Mt. Herrmann Street

Fountain Valley, CA 92708

GNU GENERAL PUBLIC LICENSE

Version 3, 29 June 2007

View the full GPL Code Statement at http://www.gnu.org/licenses/gpl.html
