D-Link DMG-112A Manual de usuario

Wireless N300 Range Extender

DMG -112A

QUICK

INSTALLATION

GUIDE

КРАТКОЕ РУКОВОДСТВО ПО УСТАНОВКЕ

GUÍA DE INSTALACIÓN RÁPIDA

GUIA DE INSTALAÇÃO RÁPIDA

快速安裝指南

PETUNJUK PEMASANGAN CEPAT

DMG -112A

ENGLISH

РУССКИЙ

ESPAÑOL

Computer USB output of the 5V/500mA is not up to the requirements of power

equipment 5V/1A, unable to make the equipment normal use, if forced to use can

damage the equipment.

Питание на выходе USB-порта компьютера 5 В/500 мА не соответствует

требованиям к питанию устройства 5 В/1 А и является непригодным для

нормальной эксплуатации повторителя. Принудительное использование может

привести к повреждению устройства.

La salida USB del computador de 5V/500mA no corresponde a los requisitos de

energía de 5V/1A del equipo, esta salida es incapaz de hacer que el equipo funcione

normalmente, si lo usa, puede dañar el equipo .

DMG -112A 3

PORTUGUÊS

中文

BAHASA INDONESIA

A saída USB do computador de 5V/500mA não corresponde aos requisitos de energia de

5V/1A do produto, sendo assim esta saída é incapaz de fazer com que o equipamento

funcione adequadamente; se utilizar forçadamente, isto poderá danicar o produto.

若您的電腦的 USB 埠口無法提供所需的 5V/1A 電力，DMG-112A 將無法正常運作。在此

情況下強制使用 DMG-112A 將可以造成設備損壞。

Output daya dari USB komputer adalah 5V/500mA tidak mencukupi kebutuhan daya

perangkat 5V/1A, sehingga perangkat tidak dapat berfungsi secara normal. Bila

dipaksakan dapat merusak perangkat.

DMG -112A

ENGLISH

CONTENTS OF PACKAGING

WIRELESS N300 RANGE EXTENDER

DMG-112A

If this item is missing from your package, please contact

your reseller.

DMG-112A

DMG -112A 5

ENGLISH

INTRODUCTION

The DMG-112A extends the wireless coverage of an existing AP (access point) or wireless

router, allowing you to reach more parts of your home with wireless coverage. It can intuitively

communicate with your router to ensure your wireless devices receive the best internet

connection at all times throughout your home network.

Extend the wireless coverage of another AP or wireless router.

Smartphone

Internet Modem

Computer

Router DMG-112A

Tablet

DMG-112A

DMG -112A

ENGLISH

PRODUCT SETUP

SETUP

SELECT YOUR METHOD

There are two methods available for setting up the DMG-112A. These are: using the D-Link

One-Touch app (recommended) or Wi-Fi Protected Setup (WPS).

SET UP DMG-112A WITH THE D-LINK ONE-TOUCH APP

The DMG-112A can be congured using your smartphone. Search for the "D-Link One-Touch"

in the Apple App Store or Google Play, and download the app.

Plug the DMG-112A into a 5V/1A USB power adaptor, then plug

the USB power adaptor into a power outlet and wait until the

blue power LED is on.

NOTE: To ensure that the DMG-112A receives adequate power,

please only use a 5V/1A USB power adaptor and not other USB

ports such as a desktop USB port for power.

DMG -112A 7

ENGLISH

Launch the "D-Link One-Touch" app on your device and select

the D-Link 112A device listed under the "Ready for Setup"

section. Follow the application's prompts to complete the setup.

Once you have completed the installation, the application will

save a Wireless Prole Card on your device, displaying the

DMG-112A’s updated information for future reference.

NOTE: Please remember to store your Wireless Prole Card in a

safe place on your device.

PRODUCT SETUP

SETUP

DMG -112A

ENGLISH

PRODUCT SETUP

SETUP

SET UP DMG-112A USING Wi-Fi PROTECTED SETUP (WPS)

NOTE: To connect to a wireless router or AP and extend the Wi-Fi network in your home,

please make sure the source router or AP features a WPS Push Button.

Push the WPS button on the source wireless router or AP, and then push the WPS button on

the DMG-112A. The middle white LED on the DMG-112A will start to ash.

Please allow up to two minutes for the conguration process to nish. Once conguration

between the DMG-112A and the router is complete, the white LEDs will light up to indicate

the strength of the signal between the DMG-112A and the router it is connected to. The

DMG-112A is now connected successfully and ready to share the extended Wi-Fi network

with your PCs and mobile devices. If the white LED does not turn on, you will need to repeat

the WPS setup process.

The SSID will be the same as the router that you are extending from.

DMG -112A 9

ENGLISH

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

1. HOW DO I RESET MY DMG-112A WIRELESS N 300M REPEATER TO FACTORY DEFAULT

SETTINGS?

- Ensure the product is powered on.

- Press and hold the WPS button for 6 seconds or longer until the bottom white LED begins to

ash.

Note: Resetting the product to the factory default will erase the current conguration

settings. The default Wi-Fi network name (SSID) is dlink-112A-z with no password required.

2. HOW DO I CONNECT A PC OR OTHER DEVICE TO THE DMG-112A IF I HAVE FORGOTTEN MY WI-

FI NETWORK NAME (SSID) OR WI-FI PASSWORD?

- If you haven't changed the extended Wi-Fi network's settings, you can use the default Wi-Fi

network name (SSID) dlink-112A-z with no password required.

- If you did change the network name (SSID) or Wi-Fi password and you deleted the Wi-Fi

Prole Card saved on your device, you must reset the device as described in Question 1

above.

DMG -112A

ENGLISH

TECHNICAL SUPPORT

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.

com.au

E-mail: support@dlink.

com.au

India:

Tel: +91-832-2856000

Toll Free 1800-233-0000

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand,

Indonesia, Malaysia,

Philippines, Vietnam:

Singapore - www.dlink.

com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.

com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to

6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South

Africa only)

Monday to Friday 8:30am to

9:00pm South Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

D-Link Middle East - Dubai,

U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai,

U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 /

8809069
