D-Link DAP-1325 Manual de usuario
Quick Installation Guide
DAP-1325
N300 Wi-Fi Range Extender
DAP-1325 Quick Installation Guide
BEFORE YOU BEGI
Delivery Package
•Extender DAP-1325
•“Quick Installation Guide” (brochure).
If any of the ite s are issing, please contact your reseller.
The “User Manual” and “Quick Installation Guide” docu ents are available
on D-Link website (see www.dlink.ru).
Default Settings
IP address of device 192.168.0.50
Username (login) admin
Password admin
ame of wireless network (SSID) DAP-1325
etwork key (PSK password)
see WPS PIN on the
barcode label on the
back panel of the
device
2
DAP-1325 Quick Installation Guide
System Requirements and Equipment
•A router enabled to access the Internet.
•A co puter with any operating syste that supports a web browser.
•A web browser to access the web-based interface of the device:
◦Apple Safari 8 and later
◦Google Chro e 48 and later
◦Microsoft Internet Explorer 10 and later
◦Microsoft Edge 20.10240 and later
◦Mozilla Firefox 44 and later
◦Opera 35 and later.
•A NIC (Ethernet or Wi-Fi adapter) to connect to the extender.
•An 802.11b, g, or n Wi-Fi adapter to create a wireless network.
3
DAP-1325 Quick Installation Guide
CO ECTI G TO PC
PC with Ethernet Adapter
1. Connect an Ethernet cable between the Ethernet port of the extender and
the Ethernet port of your PC.
2. Plug the device into an electrical outlet or power strip.
Now you need to configure an IP address for the Ethernet adapter of your PC.
Configuring IP Address in S Windows XP
1. Click the Start button and proceed to the Control Panel > etwork
and Internet Connections > etwork Connections window.
2. In the etwork Connections window, right-click the relevant Local
Area Connection icon and select the Properties line in the enu
displayed.
4
DAP-1325 Quick Installation Guide
3. In the Local Area Connection Properties window, on the General
tab, select the Internet Protocol (TCP/IP) line. Click the Properties
button.
4. Select the Use the following IP address radio button and enter the
value 198.168.0.51 in the IP address field. The Subnet mask
field will be filled in auto atically. Click the OK button.
5. Click the ОК button in the connection properties window.
Now you can connect to the web-based interface of DAP-1325 for configuring
all needed para eters. To gain access to an external network (to the Internet),
you also need to specify the default gateway and the addresses of DNS servers.
5
DAP-1325 Quick Installation Guide
Configuring IP Address in S Windows 7
1. Click the Start button and proceed to the Control Panel window.
2. Select the etwork and Sharing Center section. (If the Control Panel
has the category view (the Category value is selected fro the View by
drop-down list in the top right corner of the window), choose the View
network status and tasks line under the etwork and Internet
section.)
3. In the enu located on the left part of the window, select the Change
adapter settings line.
4. In the opened window, right-click the relevant Local Area Connection
icon and select the Properties line in the enu displayed.
5. In the Local Area Connection Properties window, on the
etworking tab, select the Internet Protocol Version 4 (TCP/IPv4)
line. Click the Properties button.
6
DAP-1325 Quick Installation Guide
6. Select the Use the following IP address radio button and enter the
value 198.168.0.51 in the IP address field. The Subnet mask
field will be filled in auto atically. Click the OK button.
7. Click the OK button in the connection properties window.
Now you can connect to the web-based interface of DAP-1325 for configuring all
needed para eters. To gain access to an external network (to the Internet), you
also need to specify the default gateway and the addresses of DNS servers.
7
DAP-1325 Quick Installation Guide
PC with Wi-Fi Adapter
1. Plug the device into an electrical outlet or power strip.
2. Turn on your Wi-Fi adapter. As a rule, odern notebooks with built-in
wireless NICs are equipped with a button or switch that turns on/off the
wireless adapter (refer to your PC docu ents). If your PC is equipped
with a pluggable wireless NIC, install the software provided with your
Wi-Fi adapter.
Now you should configure your Wi-Fi adapter.
8
DAP-1325 Quick Installation Guide
Configuring Wi-Fi Adapter in S Windows XP
1. Click the Start button and proceed to the Control Panel > etwork
and Internet Connections > etwork Connections window.
2. In the etwork Connections window, right-click the relevant
Wireless etwork Connection icon. Make sure that your Wi-Fi
adapter is on, then select the Properties line in the enu displayed.
3. In the Wireless etwork Connection Properties window, on the
General tab, select the Internet Protocol (TCP/IP) line. Click the
Properties button.
4. Select the Use the following IP address radio button and enter the
value 198.168.0.51 in the IP address field. The Subnet mask
field will be filled in auto atically. Click the OK button.
5. Click the ОК button in the connection properties window.
9
DAP-1325 Quick Installation Guide
6. Search for available wireless networks.
7. In the opened Wireless etwork Connection window, select the
wireless network DAP-1325 and click the Connect button.
8. In the opened window, enter the network key (see WPS PIN on the
barcode label on the back panel of the device) in the etwork key and
Confirm network key fields and click the Connect button.
After that the Wireless etwork Connection Status window appears.
Now you can connect to the web-based interface of DAP-1325 for configuring
all needed para eters. To gain access to an external network (to the Internet),
you also need to specify the default gateway and the addresses of DNS servers.
!
If you perfor initial configuration of the extender via Wi-Fi
connection, note that i ediately after changing the wireless default
settings of the extender you will need to reconfigure the wireless
connection using the newly specified settings.
10
