D-Link DWL-P50 Manual de usuario

DWL-P50

Power Over

Ethernet Adapters

and speciﬁcations subject to change without notice.

About DWL-P50

Check Your Package Contents

DWL-P50 Power Over Ethernet Adapter

Female-to-Female Power Connector

Ethernet (CAT5 UTP/Straight Through) Cable

If any of the above items are missing, please contact your reseller.

The DWL-P50 Power Over Ethernet (POE) Adapters are designed to work with

D-Link PoE switches to deliver power over Ethernet to D-Link wireless Access

Point, IP Camera and IP phone, which didn’t support PoE. This allows you to place

those D-Link devices virtually anywhere in a building where power outlets are not

available. DWL-P50 Unit splits the data and DC power apart form D-Link PoE switch

and then supplies them to D-Link wireless Access Point, IP Camera and IP phone.

(Please refer appendix A for DWL-P50 compatibility with D-Link products )

Warning: Please follow the

instructions in this guide carefully.

Connecting these adapters

incorrectly may result in damage

to you network devices.

Connecting The DWL-P50

P+DATA IN:connect a CAT

5 RJ-45 straight- through

cable from PoE switch.

Use the Voltage Selector to set the DC output to 5V(11.5W) or 12V(12W)

depending upon your Network device’s power speciﬁcations.

Voltage Selector:used to

select DC 5V (11.5W) or

12V (12W)

LAN OUT:connect a CAT

5 RJ-45 straight- through

cable to an Ethernet

enabled device.

DC OUT:supplies 5V or

12V of power. Using the

included power cable,

connect to your Ethernet

enabled device’s power.

Use a CAT 5, 5e, or 6 UTP/STP straight-through Ethernet cable

Select voltage that your device requires before connect

power cable to power receptor. Incorrect voltage selection

may damage product.

Connecting The DWL-P50

Connect a Cat 5 Ethernet cable from the PoE port of switch (For example:

1~8 port of D-Link DES-1316) to the “P+DATA IN” of DWL-P50

Connect the provided Cat 5 Ethernet cable from DWL-P50 “LAN

OUT” to the RJ-45 LAN port of the Network Device.

Insert the Female-to-Female Power cable into “DC OUT” and the power

receptor of the Network Device. The Power LED of the Network Device

should light up.

Connecting The DWL-P50(continued)

Installation is complete! Your Network Device should have power and

data, and function normally.

Features

Speciﬁcations

. Voltage

. Output: 5VDC or 12VDC

. Power Output

. Output: 11.5W(5VDC) or 12W(12VDC)

. Ethernet

. Connector: RJ-45

. Data Rate: 10/100Mbps

. Cable: TIA/EIA - 568, Category 5

. Dimensions

. 8.09 x 5.2 x 2.8cm

. Weight

. 80grams

. Temperature

. Operating: 0°C to 40°C (32°F to 104°F)

. Storage: -40°C to 70°C (-40°F to 158°F)

. Humidity

. Operation: 10%-80% RH

. Storage: 5% ~ 90% RH

. IEEE 802.3af compatible.

. Optional output 5VDC or 12VDC.

. No Software Required and Operating System Independent.

. Work with D-Link PoE switches DES-1316 to provide Wireless AP, Internet

Camera, IP Phone or Equivalent 5VDC or 12VDC System.

Technical Support

You can ﬁnd software updates and user documentation on the

D-Link website.

Tech Support for customers within Australia:

D-Link Technical Support over the Telephone:

1300-766-868

Monday to Friday 8:00am to 8:00pm EST

Saturday 9:00am to 1:00pm EST

D-Link Technical Support over the Internet:

http://www.dlink.com.au

email:[email protected]

Tech Support for customers within New

Zealand:

D-Link Technical Support over the Telephone:

0800-900-900

Monday to Friday 8:30am to 8:30pm

Saturday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.nz

email:[email protected]

Technical Support

You can ﬁnd software updates and user documentation on the

D-Link website.

Tech Support for customers within South

Eastern Asia and Korea:

D-Link South Eastern Asia and Korea Technical Support

over the Telephone:

+65-6895-5355

Monday to Friday 9:00am to 12:30pm, 2:00pm-6:00pm

Singapore Time

D-Link Technical Support over the Internet:

email:[email protected]

Technical Support

You can ﬁnd software updates and user documentation on the

D-Link website.

Tech Support for customers within India

D-Link Technical Support over the Telephone:

+91-22-26526741

+91-22-26526696 –ext 161 to 167

Monday to Friday 9:30am to 7:00pm

D-Link Technical Support over the Internet:

http://ww.dlink.co.in

http://www.dlink.co.in/dlink/drivers/support.asp

ftp://support.dlink.co.in

email: [email protected]

Technical Support

You can ﬁnd software updates and user documentation on the

D-Link website.

D-Link provides free technical support for customers for the

duration of the warranty period on this product.

Customers can contact D-Link technical support through our web

site or by phone.

Tech Support for customers within the Russia

D-Link Technical Support over the Telephone:

(095) 744-00-99

Monday to Friday 10:00am to 6:30pm

D-Link Technical Support over the Internet:

http://www.dlink.ru

email: [email protected]

Technical Support

You can ﬁnd software updates and user documentation on the D-Link website.

Tech Support for customers within the U.A.E & North Africa:

D-Link Technical Support over the Telephone:

(971) 4-391-6480 (U.A.E)

Sunday to Wednesday 9:00am to 6:00pm GMT+4

Thursday 9:00am to 1:00pm GMT+4

D-Link Middle East & North Africa

D-Link Technical Support over the Internet:

http://support.dlink-me.com

email:[email protected]

Tech Support for customers within Israel:

D-Link Technical Support over the Telephone:

(972) 971-5701

Sunday to Thursday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.il/forum

e-mail: [email protected]

Tech Support for customers within Turkey:

D-Link Technical Support over the Telephone:

(090) 212-335-2552

Sunday to Thursday 9:00am to 6:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.tr

e-mail: [email protected]

Tech Support for customers within Egypt:

D-Link Technical Support over the Telephone:

(202) 414-4295

Sunday to Thursday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://support.dlink-me.com

e-mail: [email protected]
