D-Link DWA-582 Manual de usuario

DWA-582

Quick Install Guide

Wireless AC1200

Dual Band PCI Express Adapter

• An available PCIe slot

• Windows® 8.1, 8, or 7

• An 802.11ac or 802.11n wireless network

• 20MB of free hard drive space

• CD-ROM Drive

Package Contents

System Requirements

Before installing your new D-Link wireless adapter, please verify the following:

• Remove any previous installations of wireless adapters

• Disable any built-in wireless adapters

• Verify the settings such as the wireless network name (SSID) and security

settings of the network(s) you want to connect to

• You can download the latest driver from http://support.dlink.com/DWA-582

Before You Begin

If any of the above items are missing, please contact your reseller.

DWA-582 Wireless AC1200 Dual Band PCI Express Adapter

Two Antennas

Low Prole Bracket

CD with drivers and manual

Remove Existing Installations

If you’ve installed a dierent manufacturer’s adapter or a dierent model

D-Link adapter, make sure the software is uninstalled before installing the new

software. Some utilities may cause a conict with the new software. If you plan

to use multiple adapters at dierent times, make sure the utilities are not set

to load when your computer boots up.

To remove old software, click Start > Control Panel > Uninstall Programs

WARNING: Do NOT plug the adapter into your computer before installing

the drivers. You will be prompted to plug in your adapter during the setup.

Note: If the CD Autorun function does not automatically start on your computer, go to

Start > Run. In the run box type “D:\autorun.exe” (where D: represents the drive letter

of your CD-ROM drive) and click OK.

Installation - Windows

Insert the DWA-582 Driver CD into the CD-ROM drive. When the autorun

screen appears, click Install and follow the on-screen instructions.

When the wizard instructs you to turn o your computer and install the PCIe

adapter into your computer, click Next and then Finish. Shut down your

computer and unplug the power.

Once your computer is turned o, unplug the power cord from the computer.

Open the case and insert the D-Link adapter into an available PCIe slot. Once

inserted, close the case and insert the power cable into the computer. Turn

on your computer.

Note: Before installing, write down the serial number and hardware revision (e.g.,

A1) in case you need to contact technical support.

Once your computer boots into Windows, the D-Link Installation Wizard

should continue with your installation.

After installation, use the Windows built-in wireless management utility to

connect the DWA-582 to your wireless network.

Note: For more information on how to connect to your wireless network using

your version of Windows, please refer to the User Manual on the included CD.

1. If I’ve lost my CD what can I do ?

TheCDcontainssoftwaredriversandmanualwhichcanbeobtainedfromhttp://

support.dlink.com. Windows 8.1, 8, and 7 in most cases will automatically

install the correct drivers.

2. If I’ve forgotten my wireless encryption key (password)?

The wireless encryption key is congured at the wireless access point, router,

or DSL modem/router. If you are unable to obtain your encryption key, the

only solution would be to re-congure your access point/router to use a new

encryption key. Please contact your access point/router/DSL modem/router

manufacturer.

3. Why can’t I get a wireless connection?

• Check that your DWA-582 is plugged in properly to the PCIe port or try to plug

the DWA-582 into another PCIe port if available.

• The LED on the DWA-582 should be lit, otherwise there could be a physical

fault on the PCIe port or the driver is not installed properly.

• Ensure that the wireless settings on the DWA-582 match the settings on your

access point/router. Please check and conrm your settings for.

• Wireless Network Name (SSID)

• Wireless Encryption Key/Wi-Fi Password

• Wireless Security Method (e.g., WEP, WPA2)

To check whether a wireless connection has been made, in theWindows system

tray (bottom right corner), red means no valid connections have been made.

• Check that your Internet is working ne on existing computers.

• Ensure that you have followed and completed the software installation

process, otherwise, please re-install the software.The LED on the DWA-582

should come on after software installation.

Troubleshooting

Notes

This guide is only for the rst time conguration. Refer to the user manual to

learn more, or visit http://support.dlink.com for more information. Also feel free

to contact us through our website.

Version 1.1 (US)_130x183

September 29, 2014

6DWA582Q..03G

third-party marks mentioned herein may be trademarks of their respective owners. Maximum wireless signal rate derived

from IEEE Standard 802.11ac, 902.11a, 802.11g, and 802.11n specications. Actual data throughput will vary. Network

conditions and environmental factors, including volume of network trac, building materials and construction, and

network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.

Product specications, size and shape are subject to change without notice, and actual product appearance may dier

from that depicted on the packaging. This publication may not be reproduced, in whole or in part, without prior express

written permission from D-Link Systems, Inc. Visit www.dlink.com for details.

http://support.dlink.com

USA

Technical Support
