Cypress PSoC CY8CKIT-008 Manual de usuario

PSoC® DEVELOPMENT KIT

QUICK START GUIDE

PSoC Development Board Self Test

Remove the PSoC Development Board from the kit package. Connect the AC power adapter.

After self test, read the success message on the LCD screen. Select an Architecture

• PSoC 1: Insert the “PSoC 1 Software” CD and jump to

step 5.

•PSoC3/PSoC5:Insertthe “PSoC 3 / PSoC 5

Software” CD and jump to step 6.

For PSoC 1 Development

• View the Kit User’s Guide.

• Install the PSoC 1 Software.

For PSoC 3 / PSoC 5 Development

• View the Kit User’s Guide.

• Install the PSoC 3 / PSoC 5 Software.

PSoC DEVELOPMENT KIT

QUICK START GUIDE

respective owners. Doc.#: 001-53756 Rev. *C

www.cypress.com/go/CY8CKIT-001

For the latest information about this kit, visit

PSoC Development Board

Kit Revision

To know if you are using the latest kit, look for the kit revision in the white sticker on the bottom left on the back side of the kit box. If the revision

reads CY8CKIT-001B, then congratulations, you own the latest version. You can also check the silicon marketing part number on the processor

module; the part number should be CY8C3866AXI-040. This kit is equipped with production PSoC 3 silicon.

PSoC Processor

Module Socket

LCD Contrast

P7:40-Pin GPIO

Expansion Port

P6:46-Pin GPIO

Expansion Port

P5: 40-Pin GPIO

Expansion Port

CapSense®, Switches,

and LED I/Os

P8: 40-Pin GPIO

Expansion Port

LCD Module

Adjustable Regulator

Variable Resistor

Board Reset Button

Power Source Switch

(3.3 V/5.0 V)

AC Power Adapter

9 V Power Adapter

RS-232 Interface

USB Interface

Prototyping Breadboard

Wireless 12-Pin

Module Interface

Variable Resistor/

Potentiometer

In-Circuit Emulator Interface

10-Pin JTAG/SWD/SWV

Debug and Programming Header

PSoC Devices

ISSP Programming Header

PSoC Device

10-Pin Trace Header

PSoC CY8C28 Family

Processor Module

PSoC CY8C38 Family

Processor Module PSoC CY8C55 Family

Processor Module
