CYP CM-388 Manual de usuario
CM-388
HDMI to CV/SV
Converter - with
HDMI Bypass
Operation Manual
1. Introduction................................................................................
2. Main Features.............................................................................
3. Package Contents.....................................................................
4. Hardware Description................................................................
4.1 Front Panel.............................................................................
4.2 Rear Panel.............................................................................
5. Connections and Installation....................................................
6. Specifications.............................................................................
TABLE OF CONTENTS
1
1
2
3
3
3
4
4
1. Introduction
The HDMI to CV/SV Converter is designed to convert digital signal from HDMI
(or DVI + Coaxial) source to analog signal of NTSC or PAL system, with L/R
stereo audio. Besides S-Video and Composite Video outputs, it also provides
one bypass HDMI output to deliver original signal, and a Coaxial output to
send S/PDIF digital audio to audio amplifier. The product provides a
convenient application that user can watch high definition movie
meanwhile record it (in standard resolutions 480i or 576i) to DVR or VCR
machine.
2. Main Features
HDMI 1.2, HDCP1.1 and DVI1.0 compliant
Converts video signal from HDMI source to NTSC or PAL signal selectable
Converts digital audio from HDMI or Coaxial source to analog stereo audio
Accepts HDTV input of wide resolutions, from 480p to 1080p@60Hz (except
1080p@24Hz) and PC from VGA@60Hz to UXGA@60Hz.
Note: Sources’ signal also need to disable 1080p@24Hz resolution in order to
avoid image corruption.
When HDMI input source end is not displaying full screen (i.e. letter
box/pillbox image) then the output display end may come out with
wrong size or position images. Hence, input source must set on full
screen first before powering on the converter and set the input source
to YCbCr by entering into DVD/PS3/BD’s OSD menu and set the HDMI
color space on YCbCr will resolve the problem.
Video and audio conversion / bypass scenarios:
1
2
* In the scenario of INPUT/OUTPUT A, the audio signal from Coaxial input will not
be used.
** DVI input or output can be applied by using HDMI to DVI adapter or cable of
similar function.
*** Analog L/R audio outputs are not available when the audio input is Coaxial,
please connect the analog audio from source to your speakers directly.
● When the signal from HDMI or DVI source is protected by HDCP (High-
bandwidth Digital Content Protection), the HDMI or DVI display needs to
support HDCP to be able to show picture.
3. Package Contents
1. HDMI to CV/SV Converter
2. 5V/2.6A DC power adaptor.
3. Operation manual.
INPUT C Video from DVI source and audio from Coaxial source
DVI -> Bypass, output original video from DVI
COAXIAL -> Output digital audio from Coaxial
CV + L/R -> Output analog video converted from DVI, L/R mute***
OUTPUT C
SV + L/R -> Output analog video converted from DVI, L/R mute***
INPUT A Both video and audio from HDMI source*
HDMI - > Bypass, output original video and audio from HDMI
OUTPUT A COAXIAL -> Output digital audio from HDMI
CV + L/R -> Output analog video / audio converted from HDMI
SV + L/R -> Output analog video / audio converted from HDMI
INPUT B
HDMI -> output original video from DVI and audio from Coaxial
COAXIAL -> Output digital audio from Coaxial
CV + L/R -> Output analog video converted from DVI, L/R mute***
OUTPUT B
SV + L/R -> Output analog video converted from DVI, L/R mute***
Video from DVI source and audio from Coaxial source**
3
COAXIAL
HDMI
COAXIAL R L VIDEO
NTSC PAL
R L S-VIDEO
DC 5V IN
HDMI
INPUT OUTPUT
2
1 3 7
4 5 6 8
1
POWER
CM-388
HDMI REPEAT WITH VIDEO OUTPUT
4. Hardware Description
The following sections describe the hardware components.
4.1 Front Panel
1 Power LED: The LED indicator will illuminate when the unit is powered on.
4.2 Rear Panel
1 Coaxial Input: Connect the digital audio input port to the Coaxial output
port of your source equipment such as DVD player or Set-Top-Box.
2 HDMI Input: Connect the HDMI input port to the HDMI output port of your
source equipment such as DVD player or Set-Top-Box.
3 Coaxial Output: Connect the digital audio output port to the input port
of your digital audio equipment such as audio amplifier.
4 HDMI Bypass Output: Connect the HDMI output port to the HDMI input
port of your display.
5 L/R Output: Connect the analog audio output port to speakers.
6 Composite Video/S-Video: Connect the Composite Video or S-Video
port to the input port of your display.
7 TV System Switcher: Select between NTSC and PAL system for output.
8 DC 5V: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
4
Input ports
Output ports
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silk Skin Color
Operating Temperature
1 x HDMI type A, 1 x Coaxial
1 x HDMI type A, 1 x Coaxial, 2 x Stereo R/L RCA jack,
1 x Composite-Video RCA jack, 1 x S-Video mini-din
5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
141(W) x 127(D) x 38(H)
510
Metal
Black
Operating from 0°C ~ 40°C
6. Specifications
5. Connection and Installation
HDMI TV
STBDVD
or
Amplifier
20071206 MPM-CM380
5
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
