Physical Appearance2

Speciﬁcations

3

Hardware Connection

1

Network protocol

PoE Protocol

Industry Standard

Network Medium

Model

Power

Ethernet

Switching Capacity

Throughput

Packet Buffer

MAC Address

Jumbo Frame

Transfer Mode

MTBF

Working Temperature

Storage Temperature

GS1008PT

Power Socket

Ethernet Device

(switch, router, etc.) Wireless AP Smart VoIP

IP Camera

Powered Device (PD)

Internet

Front board

Ethernet PoE Port

Input: AC 100-240V, 50/60Hz

8 *10/100/1000M PoE Port

16Gbps

11.9Mpps

1.5Mb

2K

9216bytes

Store and forward

100000 hour

0~40°C

-40~85°C

Router

IEEE802.3 (10Base-T) / IEEE802.3u (100Base-TX)

IEEE802.3ab(1000Base-TX) / IEEE802.3x (Flow control)

IEEE802.3af （15.4W）IEEE802.3at （30W）

IEEE802.3bt （60W）

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD),EN61000-4-4 (EFT),EN61000-4-5 (Surge)

Shock: IEC 60068-2-27 / Free Fall: IEC 60068-2-32

Vibration: IEC 60068-2-6

10Base-T : Cat3、4、5 or above UTP(≤100m)

100Base-TX : Cat5 or above UTP(≤100m)

1000Base-TX : Cat5 or above UTP(≤100m)

8 10/100/1000Mbps PoE Ports

120 Watts total PoE budget

60 Watts maximum for port #1~#2 (802.3bt/at/af)

30 Watts maximum for port #3~#8 (802.3at/af)

VLAN mode support for port #1~#6

Extend mode support for port #3~#6

Quick Installation Guide

Model: GS1008PT

EU declaration of conformity

Cudy hereby declares that the device is in compliance with the essential requirements and other

relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The

original EU declaration of conformity may be found at http://www.cudy.com/

810600091

Email: support@cudy.com

www.cudy.com

LED and Interface Explanation

5

PWR

Mode

Link ACT

Power LED

Mode LED

Link LED

ON

OFF

ON

OFF

Flashing

ON

OFF

Flashing

Power on

Power off

Port Isolation

Standard switching

Link extension

Link connected

Link disconnected

Link data transmitted

DIP Explanation

4

VLAN

(1-6 Ports)

Default

Extend

(3-6 Ports)

Port Isolation

Standard Switch

Link Extension

Downlink designated ports are isolated

from each other, only transmit data with

the uplink port.

All ports communicate freely

The speciﬁed port speed drops to 10Mbps/s,

max PoE transmission is 250 meters.
