CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
1
CSL CS468-2INT EPC Class 1 Gen 2 RFID
Fixed Reader
User’s Manual
Version 1.0.3
CSL: The One-Stop-Shop for RFID Solutions
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
2
1 Content
1
CONTENT.......................................................................................................................................................2
2
FCC STATEMENT .........................................................................................................................................3
3
INTRODUCTION............................................................................................................................................4
3.1
P
RODUCT
P
ACKAGE
.................................................................................................................................4
3.1.1
Basic Package Content.......................................................................................................................4
3.1.2
Product Specifications........................................................................................................................5
4
INSTALLATION ............................................................................................................................................7
4.1
D
EVICES
..................................................................................................................................................7
4.1.1
Reader ................................................................................................................................................7
4.2
O
PERATING
S
ETUP
...................................................................................................................................9
5
REGULATORY INFORMATION..............................................................................................................11
5.1
F
EDERAL
C
OMMUNICATIONS
C
OMMISSION
I
NTERFERENCE
S
TATEMENT
................................................11
APPENDIX A. RFID BASICS ..............................................................................................................................15
APPENDIX B. OPERATION PROFILES...........................................................................................................16
APPENDIX C. RF CHANNELS ...........................................................................................................................17
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
3
2 FCC Statement
FCC NOTICE: To comply with FCC part 15 rules in the United States, the system
must be
professionally installed to ensure compliance with the Part 15 certification. It is the
responsibility
of the operator and professional installer to ensure that only certified systems are
deployed in the
United States. The use of the system in any other combination is expressly
forbidden.
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
4
3 Introduction
3.1 Product Package
3.1.1 Basic Package Content
The reader package contains:
•Fixed reader with 16 RF ports
•USB cable
•GPIO cable
•12V switching power supply
•Extended mounting stud and nuts
•Plastic caps for connectors and cables
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
5
3.1.2 Product Specifications
Fig 3-1 CS468-2INT Reader
Features:
•
ISO 18000-6C and EPCglobal Class 1 Gen 2 UHF RFID protocol compliant including
dense reader mode
•
Ultra long read range – peak at 9 meters for UPM Dogbone RFID tag
•
Ultra high read rate – peak at 300 tags per second
•
Sophisticated data handling for efficient management of large streams of tag data.
•
Highly configurable buffering and tag filtering modes to eliminate the redundant tag data
so as to reduce LAN traffic and server loading
•
400 kbps tag-to-reader data rate profile
•
Robust performance in dense-reader environments
•
Excellent in transmit and receive mode – generates a different combination of unique
reader-to-tag command rate, tag-to-reader backscatter rate, modulation format, and
backscatter type
•
Configurable parameters offer maximum throughput and optimal performance
•
Supports all Gen 2 commands, including write, lock and kill
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
6
Specifications:
Physical Characteristics: Reader:
Length: 27 cm; Width: 16 cm; Height: 2.4 cm; Weight: 700g
Switch:
Length: 16cm; Width: 13.5; Height: 2cm; Weight:415g
Environment: Operating Temp: -20
0
C to 50
0
C
Storage Temp: -40
0
C to 85
0
C
Humidity: 5% to 95% non-condensing
Power: 12 Volt supplie
d via an AC/DC adaptor or IEEE 802.3af
compliant Power Over Ethernet enabled power source
RFID Frequency Ranges: 902~928MHz ISM band
Interfaces LAN TCP/IP
( Configurable to use fixed IP address or DHCP )
Maximum Tag Read Rate: 300 tag/sec.
Maximum Speed of Tag: 660 ft/min
Accessories: •USB cable
•GPIO cable
•12V switching power supply
•Extended mounting stud and nuts
•Plastic caps for connectors and cables
Order Code: CS468-2INT
Restrictions on Use: Approvals, features and parameters may vary depending o
n
country legislation and may change without notice
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
7
4 Installation
4.1 Devices
4.1.1 Reader
The CSL CS468-2INT fixed RFID Reader is an EPCglobal Class 1 Gen 2 reader product.
Figure 4-1 CS468-2INT Reader Top View
Figure 4-2 CS468-2INT Reader Side View
USB
GPIO
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
8
Figure 4-3 CS468-2INT Reader Side View
12VDC
Ethernet
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
9
4.2 Operating Setup
CS468-2INT has two power up modes: POE mode and 12V adaptor mode.
Figure 4-4 POE mode Setup
The reader is connected to POE enabled power source’s output port via the cable provided in
the package.
PC
CS468-2INT
Ethernet Cable 1
CS771S-2
Antenna or
Test
Equipment
with 50R
Input port
RF Cable
PoE Adaptor or Ethernet Switch with
PoE output port
AC100~240V
RF Output: SMA RP Jack
Ethernet Cable 2
PoE Output
CSL CS468-2INT EPC CLASS 1 GEN 2 RFID FIXED READER USER'S MANUAL, VERSION 1.0.3
Copyright © Convergence Systems Limited, All Rights Reserved
10
Figure 4-5 12V power adaptor mode Setup
The reader is directly connected to a host computer via the cable provided in the package.
PC
CS468-2INT
Ethernet Cable
CS771S-2
Antenna or
Test
Equipment
with 50R
Input port
RF Cable
AC/DC Adaptor
DC12V
AC100~240V
RF Output: SMA RP Jack
