Crux VRFAD-81C Manual de usuario
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
R
INTERFACING SOLUTIONS
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0224201 of 11
- Adds front and back up camera inputs plus an extra video input1.
- Uses the steering wheel control buons or radio buons to toggle between the inputs.
- Picture-in-picture mode combining aer-market rear-view and front camera picture(s) with factory parking sensor
graphics.
- Interacve parking guide lines with calibraon funcon.
- Simultaneous use of picture-in-picture factory parking sensor graphics and interacve lane lines
- Built-in on-screen display and setup.
- 2 trigger outputs (+12V max. 1A), separately adjustable switching events (CAN, ACC, camera, reverse gear)
PRODUCT FEATURES:
PARTS INCLUDED:
VRFAD-81C Module VRFAD-81C Harness Video Harness
LVDS1 Cable (to vehicle) LVDS 2 Cable (to radio)
1. Factory Audio Aux Input is required if video input will be used for AV sources.
2. The VRFAD-81C connects at the mulmedia player located in the glove box.
NOTES:
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
2 of 11
INSTALLATION DIAGRAM:
R
INTERFACING SOLUTIONS
DIP SWITCH SETTINGS:
VEHICLE MONITOR SIZE DIP 1 DIP 2 DIP 3
Audi A3 (8V) 7” ON OFF OFF
Audi A4 (8W) 8.3” ON ON ON
Audi Q7 (4M) 8.3” ON OFF ON
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
Rear Camera
(not included)
Front Camera
(not included)
LVDS 1 Cable
LVDS 2 Cable
4-pin HSD
Female LVDS Vehicle Harness
+12V Power Output 1 (Pink)
Connect to camera power
Female Quadlock
Vehicle Harness
Multimedia player
inside the glove box
AV Sources*
Front Cam Video In
+12V Power Output 2 (Green)
Connect to AV Source Power
AV Sources
Vehicle AUX Input
*NOTE: Vehicle must have Auxiliary Audio Input for the AV source.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
3 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
INSTALLATION INSTRUCTIONS:
1. Installaon is done behind the media
player in the glove compartment.
2. Remove the dashboard side panel. 3. Remove the screw that holds the
glove compartment.
4. Remove the other screws holding
the glove compartment.
5. Pull down the glove compartment to
show the media player.
6. Remove the media player to gain
access to the connectors on the back.
7. Unplug the Gray connector from the
Quadlock connector.
8. Plug in the Gray connector to the
mate on the VRFAD-81C harness.
9. Locate the Pink OR Gray LVDS
connector and unplug it.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
4 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
10. Plug the Pink or Gray LVDS cable to
the LVDS 1 cable. Plug the other end of
the LVDS 1 cable to the module LVDS
OUT.
11. Plug one end of the LVDS 2 cable
to the Pink or Gray LVDS port on the
media player. Plug the other end of the
LVDS 2 cable to the module LVDS IN.
12. Tap the Red and Black wires of
the VRFAD-81C harness to power &
ground:
Red to RED/YELLOW
Black to BROWN
14. Install the cameras that will be
used in the install. Run the camera
cables towards the radio. The RCAs and
camera power wires will be connected
to the VRFAD-81C harness.
Video Inputs Power Wire
Reverse Camera Pink
Front Camera Pink
Video Input Green
13. Tape the connecons well to avoid
short circuits.
15. Connect the camera power wires to
the PINK power output 1 wire.
18. Test the cameras. Put gear in
reverse and check for rear camera
image on screen. Put gear in Drive
and the front camera should turn on.
Test AV source if image shows on the
screen.
Once the cameras and AV source
validaon is complete, mount the
VRFAD-81C module, reinstall the media
player and glove compartment.
16. Plug in connectors to the VRFAD-
81C module.
17. Test the communicaon. Turn on
the ignion and check if LEDs are on.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
5 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
OSD Menu
Use the following buons to enter the VRFAD-81C OSD Menu:
AUDI
OSD SETTINGS:
Use the PINK wire to power the Front and
Rear cameras. Set the OSD as follows:
Opon 1 = CAM
Seng the Front Camera
(Use the PINK (Output 1) wire to power the Front camera)
SETTING THE CAMERAS:
OSD Menu Menu Item Seng Descripon
Input FVC
OFF Front camera deacvated
ON Switches to front camera if parking process is enabled
and reverse gear is released
Opon 1 Park Logic
Intelligent For vehicles with front-PDC. Enabled while parking
process and up to 12 mph
RGearOnly Enabled while parking process
(not suitable for front camera operaon)
RGearSpeed Enabled while parking process and up to
e.g. 7 mph (speed adjustable)
RGearTime Enabled while parking process and up to 20 seconds
Opon 2 R/F Cam ON XX Speed seng for deacvang of the camera image
Opon 2 PDC Graphic
OFF OEM PDC display of the vehicle deacvated
Horizontal Vehicles with horizontal OEM PDC display
Vercal Vehicles with vercal OEM PDC display
Note: You can deacvate the camera image by a long press (2 sec.) of the rotaon knob.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
6 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
Seng the Rear Aermarket Camera
(Use the PINK (12V Output 1) wire to power the Rear camera)
In the OSD Menu, set “Opon 1” > menu item “Power
Out 2” to “CAM”
If the aermarket back up camera does not automacally
switch on aer pung the gear to reverse, you can use
the analog seng instead. Connect the white wire from
the VRFAD-81C harness to the analog reverse gear signal
(+12V) wire. Set “Opon 2” > “Cam Trigger” to Analog.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
7 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
OSD Menu Menu Item Seng Descripon
Input RVC
OFF Rear View camera deacvated
ON Switches to rear-view camera if reverse gear is engaged
or PDC is acvate
Opon 1 Park Logic
Intelligent
For vehicles with PDC. Enabled while parking process
and up to 12 mph (not suitable for front camera
operaon for vehicles without front PDC)
RGearOnly Enabled while parking process
(not suitable for front camera operaon)
RGearSpeed Enabled while parking process and up to
e.g. 7 mph (speed adjustable)
RGearTime Enabled while parking process and up to 20 seconds
Opon 1 RVC Lines ON Interacve lane lines acvated
Opon 2 R/F Cam Till XX Speed seng for deacvang of the camera image
Opon 2 PDC Graphic
OFF OEM PDC display of the vehicle deacvated
Horizontal Vehicles with horizontal OEM PDC display
Vercal Vehicles with vercal OEM PDC display
Opon 2 Cam Trigger CAN Rear gear and blinker signal detecon over CAN Bus
Analog Rear gear signal detecon over analog +12V signals
Note: You can deacvate the camera image by a long press (2 sec.) of the rotaon knob.
OSD Menu Menu Item Seng Descripon
Input RVC OEM
If a factory rear-view camera is present. The interface
turns o, if reverse gear is enabled and it displays
factory rear-view camera
Opon 1 Park Logic
Intelligent For vehicles with front-PDC. Enabled while parking
process and up to 12 mph.
RGearSpeed Enabled while parking process and up to
e.g. 7 mph (speed adjustable)
RGearTime Enabled while parking process and up to 20 seconds
Opon 2 R/F Cam Till XX Speed seng for deacvang of the camera image
AV Input
You can use the Video Input to plug in an external video source. Please note that the vehicle needs to
have a factory AUX Input for audio to be heard through the factory sound system.
Use the GREEN wire (12V OUTPUT 2) of the VRFAD-81C
harness to power the external video source (max. 1A) of
the AV source.
Go to the OSD menu and set “Opon 1”, menu item “Power
Out 2” to “AVS” or “ACC”.
OSD Menu Menu Item Seng Descripon
Input Right VC/AV OFF No camera / AV source connected
RC01 AV source connected to the Video input RCA
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
8 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
In the vehicle’s Media menu, acvate AUX Input (only necessary for AV source operaon) to get sound
through the vehicle’s audio system. Press the “MEDIA” buon for 3 to 5 seconds to go to AV mode.
A short press of the ”MEDIA” buon (or addionally on touchscreen the swipe gesture) will toggle
through the video sources. Each short press will toggle to the next enabled input. If all inputs are
enabled the order is:
Rear CAM > Front CAM > Video Input > … Inputs which are not enabled are skipped.
To exit AV mode, press the “MEDIA” buon for 3 to 5 seconds or by a short press of “RADIO/NAV/TEL/
PHONE/CAR” buon.
AV Sources
Vehicle AUX Input
Congurable Trigger Outputs
You can congure the both +12V trigger outputs separately in the OSD menu. The PINK wire (12V
OUTPUT 1) is Power Out 1 and the GREEN wire (12V OUTPUT 2) is Power Out 2.
OSD Menu Menu Item Seng Descripon
Opon
Power Out 1
(PINK)
CAM +12V when the interface is on (red LED on)
ACC +12V when ignion is on
Cam +12V when camera input is acvated
(manually or automacally)
Power Out 2
(GREEN)
RGear +12V when reverse gear is engaged
AVS +12V when camera / video input was manually acvated
OFF Trigger output deacvated
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
9 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
Tip: We recommend for all camera to use power out seng “Cam” and for AV source the power out
seng of “AVS” or “ACC”.
Interacve Lane Lines
The VRFAD-81C includes an Interacve Lane Lines funcon that is added to the aermarket rear view
camera. Use the OSD menu to acvate this feature.
OSD Menu Menu Item Seng Descripon
Opon RVC Lines OFF Interacve lane lines deacvated
ON Interacve lane lines acvated
Car Type AUDI A3 / AUDI A4 / AUDI Q7 Vehicle Type Selecon
Interacve Lane Lines Sengs
The height and width of the interacve lane lines can be set in
the OSD menu. For this seng you must rst acvate the rear
view camera level and push the “MENU“ buon for 2 seconds
to acvate the sengs menu. With the rotaon knob you can
select the menu point “Line Height” to change the height of the
interacve lane lines and with menu point “Line Width” the width
of the lines. Click “Exit” to leave the sengs menu.
Picture Sengs
The camera picture can be set in the OSD menu. For this seng
you must rst acvate the camera level and push the “MENU“
buon for 2 seconds to acvate the sengs menu. With the
rotaon knob you can select and change the “Brightness”,
“Contrast”, “Saturaon”, Hue” and “Sharpness”. Click “Exit” to
leave the sengs menu.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.022420
10 of 11
R
INTERFACING SOLUTIONS
VRFAD-81C
Front and Rear View Integration Interface
for AUDI Vehicles with MMI/MIB/MIB2 Systems
OSD Sengs
You can change the basic conguraons of the interface in the OSD (on screen display).
OSD Menu Menu Item Seng Descripon
OSD
POS. X 0-xxx Horizontal posion of the OSD
POS. Y 0-xxx Vercal posion of the OSD
Size Small Small OSD menu window
Large Large OSD menu windows
Osd TimeOut 2-20 Time seng for automac OSD shuto
Info Version X.XX.XX Displays the current SW-version
Opon 1 Factory Reset Reset to factory default sengs
Note: The picture sengs will be retained for every camera input separately.
Tabla de contenidos
Otros manuales de Accesorios para automóviles de Crux
Crux
Crux RVCAD-81M Manual de uso y cuidado
Crux
Crux SOOGM-16V Manual de usuario
Crux
Crux TDR-RVM32 Manual de usuario
Crux
Crux SWRGM-49 Manual de usuario
Crux
Crux Sightline RVCVW-73B Manual de usuario
Crux
Crux Sightline VIMFD-95 Manual de usuario
Crux
Crux RVCCH-75 Manual de usuario
Crux
Crux ACPBM-77X Manual de usuario
Crux
Crux Sightline VIMCF-93C Manual de usuario
Crux
Crux RVCAD-81T Manual de usuario
Crux
Crux AVICH-03 + VCIP5 Manual de usuario
Crux
Crux Sightline MRVBM-77Q Manual de usuario
Crux
Crux BEECR-35 Manual de usuario
Crux
Crux Sightline RVCAD-81B Manual de instrucciones
Crux
Crux RVCCH-75E Manual de usuario
Crux
Crux BEECR-35P Manual de usuario
Crux
Crux VIMMB-85S Manual de usuario
Crux
Crux RVCCH-75W Manual de usuario
Crux
Crux BEECR-35D Manual de usuario
Crux
Crux RVCCH-75F Manual de usuario
