The Crestron® MC4 and MC4-I 4-Series media room controllers provide

secure, high-performance, cost-effective control processors and

interfaces. Their small form factor and versatile mounting options make

them ideal for applications such as single-room systems, small to

medium-sized homes and offices, and MDUs (multidwelling units). The

controlsystem includes a built-in infiNET EX® and ER wireless gateway

for acquiring wireless devices as well as numerous control ports for

controlling wired devices.

NOTE:TheMC4 and MC4-I are functionally similar. For simplicity

within this guide, the term "control system"is used to refer to both

the MC4 and MC4-Iunless otherwise noted.

In the Box

1 MC4 or MC4-I, 4-Series Media Room Controller

Additional Items

1 Rack Ear, Left (2053897)

1 Rack Ear, Right (2053896)

4 Nut, 10-32 (2004889)

1 Antenna, Dual Band, 2.4/5.8 GHz (2052945)

1 Cable, CAT5e, 5 ft (1.52 m) (2022311)

2 Connector, 3-Pin (2003575)

4 Connector, 4-Pin (2003576)

Install the Device

The control system may be mounted into a rack or onto a flat surface.

Rack Mounting

The control system occupies 1U of rack space when using the provided

rack ears.

1. Attach the rack ears to the device:

a. Insert the two threaded posts on the left rack ear up and into the

front opening in the left mounting flange of the control system.

Repeat this step for the right rack ear.

b. Attach the four provided nuts to the threaded posts to secure the

rack ears to the control system.

MC4/MC4-I Quick Start

Refer to the following image for rack ear placement. 2. Secure the control system to the rack rails using four rack mounting

screws (not provided).

Surface Mounting

Use four mounting screws(not provided)to mount the control system to

a flat surface such as a wall or under a table. The control system can also

be mounted behind a flat panel display or similar equipment.

MC4/MC4-I Quick Start

Connect the Device

Make all necessary connections to the control system as shown below.

Front Panel Connections

Rear Panel Connections

MC4/MC4-I Quick Start

Observe the following when connecting the control system:

lThe control system is powered over PoE (Power over Ethernet)via a

Crestron PoEinjector (PWE-4803RU) or a Crestron PoEswitch

(CEN-SW-POE-5 or CEN-SWPOE-16). All PoEequipment is sold

separately.

lThe included cables may not be extended.

lMount the included antenna per the guidelines described in Mount the

Antenna.

lConnect the chassis ground lug to a known earth ground circuit (such

as building steel) to ensure that the control system is grounded

properly.

lApply power after all connections have been made.

Mount the Antenna

The included antenna should be placed in a location that maximizes signal

strength and limits impedance. Refer to the Best Practices for Installation

and Setup of Crestron RFProducts (Doc. 6689) at

www.crestron.com/manuals.

If installing the control system in a rack enclosure, the antenna should be

mounted outside of the enclosure using the Crestron ANT-EXT-10 (sold

separately). For more information, refer to the ANT-EXT-10 Installation

Guide (Doc. 7047) at www.crestron.com/manuals.

Configure the Device

The control system may be configured using the provided web

configuration interface. The interface can be accessed using the control

system IP address or the Crestron XiOCloud™ service.

Configuration via IP Address

To access the web configuration interface using the control system

IPaddress:

NOTE:The control system ships with DHCPenabled. A DHCPserver is

required to access the web configuration interface via the device

IPaddress.

1. Connect the control system to the network.

2. Use the Device Discovery tool in Crestron Toolbox™ software to

discover the control system and its IP address on the network.

3. Enter the control system IPaddress into a web browser.

MC4/MC4-I Quick Start

Configuration via Crestron XiOCloud

The Crestron XiO Cloud service allows supported Crestron devices across

an enterprise to be managed and configured from one central and secure

location in the cloud. Supported devices are configured to connect to the

service. Use of the service requires a registered Crestron XiO Cloud

account.

NOTE: The device may be disconnected from the service by navigating

to the Cloud Services tab in Crestron Toolbox software (Functions >

Device Info >Cloud Services). For details, refer to the Crestron

Toolbox help file.

To access the web configuration interface using the Crestron XiOCloud

service:

1. Connect the control system to the network.

2. Record the MAC address and serial number that are labeled on the top

of the control system. The MACaddress and serial number are

required to add the device to the service.

3. Do either of the following

lFor existing accounts, access the Crestron XiO Cloud service at

https://portal.crestron.io.

lFor new accounts, register for a Crestron XiO Cloud account at

www.crestron.com/xio-cloud-registration.

4. Claim the device to the service as described in the Crestron XiO Cloud

User Guide (Doc. 8214) at www.crestron.com/manuals.

5. Select the device from the cloud interface to view its settings.

Create an Admin Account

The first time the web configuration interface is accessed, a dialog box is

displayed asking the user to create an admin account. A similar message

is displayed when connecting to the device in Crestron Toolbox software if

an admin account has not already been created.

To create an admin account:

1. Enter a username and password for the admin account in the

appropriate text fields.

CAUTION:Do not lose the username and password for the admin

account, as the device must be reset to factory settings to regain

access.

2. Click OK. A dialog box is displayed stating that enabling authentication

will restart the web session.

3. Click Yes to confirm and restart. The username and password created

in step 1 must be entered to regain access to the web configuration

interface.

NOTE:The username and password must also be entered when

connecting to CrestronToolbox or XPanel.

MC4/MC4-I Quick Start

Set the Time Zone

The time zone must be set on the control system to ensure that the

correct time settings are pushed to controlled devices.

To set the time zone:

1. Access the web configuration interface using either the device

IPaddress or the Crestron XiOCloud service.

2. Navigate to Settings >System Setup.

3. Select the time zone where the control system is used from the Time

Zone drop-down menu.

4. Click Save Changes on the top right of the screen.

Assign the RFChannel

Set the RF channel of the control system prior to operation. The control

system can operate on channels 11 through 26. Crestron recommends

using RF channel 15 or 20. The default RF channel is 15.

For optimum performance when installing the control system in a

Wi-Fi®network environment, do not set the RF channel within a Wi-Fi

channel band. Refer to the information below when choosing the RF

channel in a Wi-Fi environment:

lGateway channels 11 through 14 are within the Wi-Fi channel 1band.

lGateway channel 15 is adjacent to Wi-Fi channels 1 and 6.

lGateway channels 16 through 19 are within the Wi-Fi channel 6band.

lGateway channel 20 is adjacent to Wi-Fi channels 6 and 11.

lGateway channels 21 through 24 are within the Wi-Fi channel 11band.

lGateway channel 25 is adjacent to Wi-Fi channel 11.

lGateway channel 26 is neither within nor adjacent to any Wi-Fiband.

NOTE: Crestron RF devices are divided into two categories: infiNETEX

network devices and Crestron Extended Range (ER) devices.

infiNETEX devices automatically set their RF channel assignment to

match the gateway’s channel, whereas ER devices must have their RF

channel manually assigned to match the gateway’s channel.

Use Crestron Toolbox to set the control system RFchannel. From the

EasyConfig tool, navigate to Functions >infiNETEXGateway. Refer to

the Crestron Toolbox help file for more information.

MC4/MC4-I Quick Start

Acquire Devices to the Control

System

Crestron infiNET EX and ER devices can communicate with the control

system after they have been acquired by the control system internal

gateway. A device can be acquired to only one gateway. Acquire mode is

activated from Crestron Toolbox or by pressing the ACQUIREbutton on

the control system front panel.

For optimum performance when installing the control system in a Wi-Fi

network environment, do not set the RF channel within a Wi-Fi channel

band. Refer to the information below when choosing the RF channel in a

Wi-Fi environment:

NOTES:

lUse Crestron Toolbox to set the RF channel before starting the

acquiring process. Refer to Assign the RFChannel.

lAcquire mode can be activated approximately 15 seconds after

power is applied to the control system.

lThe control system must be put in Acquire mode before an infiNET

EX device is put into Acquire mode.

To acquire an infiNET EX or ER device to the control system:

1. Press ACQUIRE on the control system to enter Acquire mode. The

Acquire LED lights to indicate that the unit is ready to acquire.

NOTE:Acquire mode deactivates after one hour by default. This

timeout period can be modified in Crestron Toolbox.

2. Place the infiNET EX or ER device within range of the gateway (50 ft),

and put it into Acquire mode as described in its documentation. The

device is acquired within two minutes of putting it into Acquire mode.

3. Repeat step 2 for each device that must be acquired.

4. Press ACQUIRE on the control system to leave Acquire mode.

Visit the Product Page

Scan the QR code to visit the product page.

MC4:

www.crestron.com/model/6510432

MC4-I:

www.crestron.com/model/6511326

MC4/MC4-I Quick Start

Additional Information

Original Instructions

The U.S. English version of this document is the original instructions.

All other languages are a translation of the original instructions.

Crestron product development software is licensed to Crestron dealers and Crestron

Service Providers (CSPs) under a limited nonexclusive, nontransferable Software

Development Tools License Agreement. Crestron product operating system software is

licensed to Crestron dealers, CSPs, and end-users under a separate End-User License

Agreement. Both of these Agreements can be found on the Crestron website at

www.crestron.com/legal/software_license_agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed at

www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, visit

www.crestron.com/opensource.

Crestron, the Crestron logo, Cresnet, Crestron Toolbox, Crestron XiOCloud, and

infiNETEX are either trademarks or registered trademarks of Crestron Electronics, Inc.

in the United States and/or other countries. The microSDlogo is either a trademark or

a registered trademark of SD-3C, LLC in the United States and/or other countries.

Wi-Fi is either a trademark or registered trademark of Wi-Fi Alliance in the United

States and/or other countries. Other trademarks, registered trademarks, and trade

names may be used in this document to refer to either the entities claiming the marks

and names or their products. Crestron disclaims any proprietary interest in the marks

and names of others. Crestron is not responsible for errors in typography or

photography.

Doc ID 8489A

(2054144)

01/03/20

MC4/MC4-I Quick Start

Otros manuales para 4 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Controladores de Crestron

Crestron

Crestron CLS-EXP-DIMFLV Manual de usuario

Crestron

Crestron ZUMMESH-JBOX-DALI Manual de usuario

Crestron

Crestron C3COM-3 Manual de usuario

Crestron

Crestron CH-HREL8-D6 Manual de usuario

Crestron

Crestron CLC-1LEDPWM-RGBW-EX Manual de usuario

Crestron

Crestron onCue BPC-8 Manual del propietario

Crestron

Crestron 3 Series Manual de usuario

Crestron

Crestron TSW-1050-FMKT Manual de usuario

Crestron

Crestron onCue BPC-8 Dibujo dimensional

Crestron

Crestron CNXFZ Manual de usuario

Crestron

Crestron CP4-R Manual de usuario

Crestron

Crestron DigitalMedia DM-RMC-100-1 Cómo utilizar

Crestron

Crestron C2N-SDC Cómo utilizar

Crestron

Crestron MC2E Manual de usuario

Crestron

Crestron infiNET EX CLC-FANDELVEX-W Manual de usuario

Crestron

Crestron PC-350V-12 Manual de usuario

Crestron

Crestron QM-RMC Manual de usuario

Crestron

Crestron DigitalMedia Room Controller DM-RMC-100 Cómo utilizar

Crestron

Crestron 4K DigitalMedia 3-Series Manual de usuario

Crestron

Crestron MPC-M5 Dibujo dimensional

Crestron

Crestron ST-VC Manual de usuario

Crestron

Crestron CGDMX-512BI Cómo utilizar

Crestron

Crestron infiNET HTT-B10X Manual de usuario

Crestron

Crestron IPAC Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
