Creda PW E4ZC Manual
Key features
• 300W, 500W and 750W output rails
• High quality white or chrome finish
• Integral controls (Controls must be positioned
outside of zones 0, 1 & 2)
• Digital electronic thermostat with range restriction
and lock facility
• Pilot wire control compatible
• IP24 rated (splashproof)
Integral control features
• Push button - On/off with neon indicator
• Rotary - Thermostat with frost protection setting
• Rotary - Variable boost - time set 15 minutes,
30 minutes,1 hour or 2 hours
Control options
Outline towel rails can be pilot wire linked
to a flash controller as part of a complete
heating system.
27
+44 (0) 1733 456789 www.creda-heating.co.uk
Outline
Thermostatic integral control towel rails
Model Reference Product Description Rating Height A Width B Depth C
OTRC300 75 772710 Outline 30 (chrome) 300W 855mm 550mm 85mm
OTRC500 75 772711 Outline 50 (chrome) 500W 1,300mm 550mm 85mm
OTRW500 75 772701 Outline 50 (white) 500W 815mm 550mm 85mm
OTRW750 75 772702 Outline 75 (white) 750W 1,225mm 550mm 85mm
PW E4ZC 75 770916 4 zone pilot wire central controller
Product Selector
Dimensions
“Outline heated towel rails
are of the popular ladder
style and, with outputs of
up to 750W, they provide
background heating as well
as warm dry towels. ”
Towel rails &
bathroom warmers
Technical Specification
• Element - cartridge type
• Control - digital electronic thermostat
with boost facility
• Protection - thermal cut-out
• Supply - 230/240V AC single phase
Proline II PL
Fast response electric ladder towel rails
Product Selector
Model Reference Description Rating Height A Width B Depth C Weight
Straight rail models
PL180SW 75 774502 Straight white 180W 610mm 453mm 80mm 4.4kg
PL220SW 75 774503 Straight white 220W 610mm 602mm 80mm 7.9kg
PL260SW 75 774504 Straight white 260W 843mm 453mm 80mm 5.5kg
PL360SW 75 774505 Straight white 360W 843mm 602mm 80mm 9.5kg
PL180SC 75 774512 Straight chrome 180W 610mm 453mm 80mm 5.4kg
PL220SC 75 774513 Straight chrome 220W 610mm 602mm 80mm 7.9kg
PL260SC 75 774514 Straight chrome 260W 843mm 453mm 80mm 5.5kg
PL360SC 75 774515 Straight chrome 360W 843mm 602mm 80mm 9.5kg
“The new Proline II range of
dry element ladder style
towel rails provide much
faster heat up than fluid
filled models and are
lighter and easier to install,
with no chance of leaks. ”
28 +44 (0) 1733 456789 www.creda-heating.co.uk
Towel rails &
bathroom warmers
Featuring a patented fast response
technology and outstanding performance.
Proline II towel rails are available in a
choice of 16 models with chrome or white
finishes and both and straight options.
Key features
• Fast response technology for a quicker warm up
than conventional towel rails
• Provides more heat from a lower output so more
energy efficient
• Even heat distribution - no cold spots
• Compact, slimline design
• Dry element technology - no leakage, no rusting
• Lightweight for faster, easier installation
• IPX4 rated (splashproof)
180W
260W
220W
360W
Four sizes each in white or chrome, straight or curved rails
29
+44 (0) 1733 456789 www.creda-heating.co.uk
Proline II PL
Fast response electric ladder towel rails
Technical Specification
Dimensions
• Element - silicone coated dry element type
• Control - cycling cutout
• Protection - Two auto re-set temperature limiters
• Supply - 230/240V AC single phase
Towel rails &
bathroom warmers
Fluid-filled
towel rail
New dry
element rails
Fast even heat distribution in minutes Control Options
RFRTK7 RF remote thermostat
and programmer kit.
Enables thermostatic and time control
using wireless signalling between the
remote wall mounted thermostat and
the receiver unit at the appliance
(Also available thermostat kit only
see page 21).
Product Selector
Model Reference Description Rating Height A Width B Depth C Weight
Curved rail models
PL180CW 75 774552 Curved white 180W 610mm 453mm 90-100mm 4.4kg
PL220CW 75 774553 Curved white 220W 610mm 602mm 90-100mm 7.9kg
PL260CW 75 774554 Curved white 260W 843mm 454mm 90-100mm 5.5kg
PL360CW 75 774555 Curved white 360W 843mm 602mm 90-100mm 9.5kg
PL180CC 75 774562 Curved chrome 180W 610mm 453mm 90-100mm 4.4kg
PL220CC 75 774563 Curved chrome 220W 610mm 602mm 90-100mm 7.9kg
PL260CC 75 774564 Curved chrome 260W 843mm 453mm 90-100mm 5.5kg
PL360CC 75 774565 Curved chrome 360W 843mm 602mm 90-100mm 9.5kg
RF Thermostat kits
RFRTK 75 770917 RF remote thermostat kit 2kW
RFRTK7 75 770920 RF thermostat and programmer 2kW
RFRI 75 770921 RF additional receiver unit only 2kW
Pilot wire interface unit
PW E16A 75 770915 Pilot wire auxiliary interface unit 3kW
PW E16A Pilot wire auxiliary interface unit
Enables heaters without electronic controls
to be central programmed, for on/off time
periods only, as part of a pilot wire linked
heating system (see page 20).
TD
Traditional style electric towel rails
Product Selector
Technical Specification
Dimensions
Permanently liquid filled for maintenance
free operation the TD towel rail range
offers chrome and white options, ideal for
drying and airing small towels in areas
such as kitchens, cloakrooms and ensuite
bathrooms. The TD towel rail can be left
switched on indefinitely with the low
wattage cartridge element providing
economical operation.
Key features
• 60W or 80W models
• Available in white or chrome finishes
• Oil filled for even heat transfer
• Mains neon indicator
• IPX4 rated (splashproof)
• Supplied with wall mounting brackets as standard
• Durable white stove enamel or chrome plated
• Can be mounted for left or right hand cable entry
Control options
RFRTK RF remote thermostat kit.
Enables thermostatic control of electric
towel rails using wireless signalling
between the remote wall mounted
thermostat and the receiver unit at
the appliance. (see page 21).
“Classically styled towel rails
that warm and dry towels.
All models offer low energy
use whilst maintaining
superior heat output.
”• Element - cartridge type
• Cycling thermostat
• Protection - thermofuse
• Supply - 230/240V AC single phase
Model Reference Product Description Rating Height A Width B Depth C
TD60W 75 774601 TD towel rail (white) 60W 616mm 533mm 93mm
TD60C 75 774611 TD towel rail (chrome) 60W 616mm 533mm 93mm
TD80W 75 774602 TD towel rail (white) 80W 851mm 533mm 93mm
TD80C 75 774612 TD towel rail (chrome) 80W 851mm 533mm 93mm
RFRTK 75 770917 RF remote thermostat kit - - - -
Towel rails &
bathroom warmers
30 +44 (0) 1733 456789 www.creda-heating.co.uk
Model Reference Product Description Rating Height A Width B Depth C
LRC3 86060 Ladder Rail (chrome) 140W 1,000mm 500mm 110mm
LRC5 86080 Ladder Rail (chrome) 175W 1,200mm 600mm 155mm
CSR50W 51 805702 Solarail 50 (white) 50W 410mm 460mm 85mm
CSR50C 51 805701 Solarail 50 (chrome) 50W 410mm 460mm 85mm
CSR100W 51 805303 Solarail 100 (white) 100W 570mm 710mm 100mm
CSR85C 51 805314 Solarail 85 (chrome) 85W 570mm 710mm 100mm
Solarail dry element towel rails
Designed for towel drying in the
bathroom, shower room or even kitchen
areas, Solarails are compact enough to fit
in the smallest of spaces.
Key features
• Dry element towel rails with a choice of 50W,
85W and 100W outputs
• Supplied with mains cable and mounting brackets
for easy installation
• Finished in white or chrome
• IPX4 rated (splashproof)
LRC electric towel rails
A range of ladder style fluid-filled towel
rails finished in chrome. All models offer
low energy usage whilst maintaining
superior heat output.
Key features
• Fluid filled for even heat distribution
• 22mm rail diameter
• Triple layer corrosion protection
• Unique styling complements a range of décor
• Maximises power distribution to optimise
energy usage
• Highly polished finish
• High impact ABS support brackets
• IP55 rated (water jets)
• Easy to install - complete with fittings
• Designed for durability
• Elements - cartridge type (LRC)
• Flexible cable type (Solarail)
• Cycling thermostat
• Protection - thermofuse
• Supply - 230/240V AC single phase
Solarail and LRC
Electric towel rails
Technical Specification
Product Selector
LRC
Solarail
Dimensions
“Solarail and LRC electric and dry element towel rails
offer a choice of large surface area to ultra compact
towel rails to satisfy all requirements. ”
50w
85w & 100w
Towel rails &
bathroom warmers
31
+44 (0) 1733 456789 www.creda-heating.co.uk
