Anchoring guide Crossover L
Version 2.1
Anchoring guide Crossover L
Page 2
www.creativestructures.nl
Contents
1 Introduction 3
2.1 Anchoring with anchor pins 5
2.2 Anchoring with ballast 6
2.2.1 Anchoring one Crossover L structure foot with ballast 6
2.2.2 Anchoring two Crossover L structure feet with ballast 8
2.2.3 Anchoring three Crossover L structure feet with ballast 11
2.2.4 Anchoring four Crossover L structure feet with ballast 13
2.3 Anchoring at a stage 15
Anchoring guide Crossover L
Page 3
www.creativestructures.nl
For a safe use, the Crossover L has to be anchored to the ground surface properly. This guide provides multiple
anchoring solutions with their requirements.
Note: Creative Structures BV does not bear responsibility for the installation and foundation.
Two types of anchor points are distinguished:
1. Anchor points at the structure feet (4x)
2. Anchor points at the bottom of the side panels (4 per side panel)
These additional anchor points can be used to decrease the deformation of the side panels but are not
necessary.
1. Introduction
Anchoring guide Crossover L
Page 4
www.creativestructures.nl
Anchor point positions
(Also available in digital dxf- and dwg-format)
= Anchor point structure foot
= Additional anchor point side panel. (Not necessary)
Anchoring guide Crossover L
Page 5
www.creativestructures.nl
2.1 Anchoring with anchor pins
The Crossover L can be anchored to dense cohesive less soils (such as sand) or stiff cohesive soils (such as
loam or clay) with 2 anchor pins per structure foot.
Anchor pin dimensions:
Anchoring guide Crossover L
Page 6
www.creativestructures.nl
2.2 Anchoring with ballast
The Crossover L can be anchored with ballast by using the additional ballast system. It is possible to connect
one, two, three or four structure feet at one anchor point.
2.2.1 Anchoring one Crossover L structure foot with ballast
Step 1
Slide the two ballast supports into the ballast interface and secure it with M12 screws.
Check the condition of the rubber friction strips
Replace them when damaged
!
Ballast support
CS-0522
Ballast support
CS-0522
Ballast interface
CS-0523
Screw connection
DIN 912 M12x120
Anchoring guide Crossover L
Page 7
www.creativestructures.nl
Step 2
Mount the Crossover L structure foot with M12 screws.
Step 3
Place twentyfour 50x50x4cm concrete tiles at both ballast supports and fasten them with lashings
Screw connection
DIN 933 M12x35
4x
Concrete tile
50x50x4cm
24x
Total weight: 600kg
Concrete tile
50x50x4cm
24x
Total weight: 600kg
Lashings
Total weight: 1250kg
Anchoring guide Crossover L
Page 8
www.creativestructures.nl
2.2.2 Anchoring two Crossover L structure feet with ballast
Step 1
Slide the four ballast supports into the ballast interface and secure it with M12 screws.
Ballast support
CS-0522
4x
Ballast interface
CS-0524
Screw connection
DIN 912 M12x120
8x
Check the condition of the rubber friction strips
Replace them when damaged
!
Anchoring guide Crossover L
Page 9
www.creativestructures.nl
Step 2
Mount the two Crossover L structure feet with M12 screws.
Screw connection
DIN 933 M12x35
8x
Anchoring guide Crossover L
Page 10
www.creativestructures.nl
Step 3
Place twentyfour 50x50x4cm concrete tiles at the four ballast supports and fasten them with lashings
Concrete tile
50x50x4cm
24x
Total weight: 600kg
Total weight: 2500kg
Concrete tile
50x50x4cm
24x
Total weight: 600kg
Concrete tile
50x50x4cm
24x
Total weight: 600kg
Concrete tile
50x50x4cm
24x
Total weight: 600kg Lashing
8x
