Quick Start Guide /COR IBR600 Series

+ Fully Integrated

Router/Bridge

+ Integrated 3G/4G

modem

+ Semi-ruggedized

Metal Housing

+ Certiﬁed for shock

and vibration

+ Two Ethernet Ports

(LAN/LAN or WAN/

LAN)

+ WiFi and non-WiFi

versions available

+ Built-in GPS with

NMEA Output

COR IBR600 Key Features:

COR IBR600 Series

FOR M2M & IoT NETWORKING

Go to cradlepoint.com/IBR600 to learn more.

AC Power Adapter WiFi Antennas

(on applicable models)

Modem Antennas

(on applicable models)

Mounting Bracket

WHAT’S INCLUDED:

THANK YOU FOR CHOOSING

CRADLEPOINT

Cradlepoint is the leading provider of secure

cloud-managed 3G/4G/LTE networking solutions

for the Distributed Enterprise with hundreds

or thousands of locations. Our broad family

of high-performance routers are designed for

deployment in mission-critical applications

that require 24x7 connectivity.

Always Connected. Always Protected.

DEVICE DETAILS

Model numbers:

Accessories:

+ Directional Patch &

Yagi antennas

+ Omni-directional

antennas

+ 12” Mag-mount

antenna

+ 4” Mini-mag-mount

antenna

IBR600E

IBR650E

IBR600P

IBR650P

IBR600LPE

IBR650LPE

IBR600LP2

IBR650LP2

IBR600LP3

IBR650LP3

GETTING STARTED

Setting Up the Router

+ Purchase a data plan. Insert the SIM if model

requires.

+ Plug the power supply into an electrical outlet.

+ Connect WiFi (2.4) and modem antennas (ﬁnger

tight only). Purchase and connect active GPS

antenna for -PWD models.

+ Connect the power supply to the IBR600.

+ Ensure power is switched on. O = OFF I = ON

Access the Administration Pages

To make conguration changes to your router, open

the IBR600’s GUI-based administration pages.

1. Connect to the router

via Ethernet or WiFi.

For WiFi, the default

SSID is found on the

product label on the

bottom of the router.

2. Open a browser

window and type

“cp/” or “192.168.0.1”

in the address bar and press return/enter.

Quick Start Guide /COR IBR600 Series

3. When prompted for the Administrator password,

type the default eight character password found on

the product.

4. Upon log in for the ﬁrst time, you are automatically

directed to the First Time Setup Wizard to conﬁgure

Admin Password, Time Zone, WiFi Security, APN and

WAN failure check.

FIRST TIME SETUP WIZARD

When you log in to the local administration pages for

the ﬁrst time, you will be automatically directed to the

First Time Setup Wizard, which will walk you through

basic steps to customize your Cradlepoint IBR600/650.

You have the ability to conﬁgure any of the following:

If you are currently using the router’s WiFi network,

you will need to reconnect your devices to the

network using the newly established wireless network

name and password.

+ Administrator

Password

+ Time Zone

+ WiFi Network Name*

+ Security Mode

+ Access Point Name

(APN)

+ Modem

Authentication

+ Failure Check

To return to the First Time Setup Wizard after your

initial login, select ‘System > System Control’ on the

left navigation bar and First Time Setup in the drop-

down menu.

To restore the router to its factory default settings,

press and hold the RESET button on the side of

the device for ten seconds. Reset returns the login

password to the default password and resets all

conﬁguration changes.

ACTIVATE YOUR MODEM

A Cradlepoint router requires a data subscription to a

wireless broadband data plan to connect to a wireless

network. Wireless broadband data plans are available

from wireless carriers such as AT&T, Verizon, Sprint,

T-Mobile, EE and Vodafone. Carriers oer several

dierent types of data plans and Cradlepoint works

with most (Mobile broadband, M2M, and router pricing

plans; private and public APNS; and static or dynamic

IP address). To add or transfer a line of service you will

need to provide a unique identiﬁer such as IMEI/MEID

from the Cradlepoint modem. Data plans require a SIM

that is supplied and provisioned by the wireless carrier

and inserted into the Cradlepoint router or modem.

For more information on activation see

cradlepoint.com/activation.

Quick Start Guide /COR IBR600 Series

Deploy and Manage the

Intelligent Network with

Cradlepoint Enterprise Cloud

Manager (ECM)

Cradlepoint’s network management

and application platform, Enterprise

Cloud Manager, integrates cloud

management with your Cradlepoint

devices to improve productivity,

increase reliability, reduce costs, and

enhance the intelligence of your

network and business operations.

To learn more and begin a free

30-day trial:

services@cradlepoint.com

cradlepoint.com/ecm

ACTIVE GPS: -PWD MODELS

The IBR600XX-XX-PWD now come with an active GPS

connection at 3.3V and 100mA max.

For full functionality you will need to purchase an

active GPS antenna separately. The -PWD models

include only one WiFi antenna for operation in 1x1

WiFi mode.

UPDATING FIRMWARE

Cradlepoint regularly creates new ﬁrmware packages.

You may need to update ﬁrmware to use the IBR600

with new modems and to access our latest features.

1. Log into the administration pages. You may have

changed the Administrator Password when you

used the First Time Setup Wizard.

2. Select ‘System > System Control’ on the left

navigation bar, then ‘System Software’ in the

dropdown menu.

3. Find the ‘Firmware Upgrade’ section. This displays

the current ﬁrmware version that is installed and

indicates if updated ﬁrmware is available.

4. Click ‘Automatic (Internet)’ if new ﬁrmware is

available. The IBR600 will download and install the

ﬁrmware and automatically reboot itself. A status

monitor will appear and indicate when this process

is complete. This process may take several minutes

depending on your Internet connection speed.

If your device does not have an active Internet

connection, you need to download the latest ﬁrmware

from cradlepoint.com/ﬁrmware to your desktop. Then

use the ‘Manual Firmware Upload’ option.

ROUTER COMMUNICATION /

DATA USAGE

The factory default conﬁguration of the router is set

to communicate with Cradlepoint and other resources

at regular intervals to access the latest ﬁrmware

and modem updates, clock synchronization (NTP),

and Enterprise Cloud Manager (ECM) membership.

Such communication may result in data usage and

applicable charges regardless of whether the router

uses a wired or wireless Internet connection. To avoid

such data usage and potential charges, consult the

following Knowledge Base article:

knowledgebase.cradlepoint.com/articles/Support/

Router-Communication-Data-Usage

Quick Start Guide /COR IBR600 Series
