PC-HELPER

Analog Input Board for PCI

AD12-16(PCI)E

AD12-16U(PCI)E

AD16-16(PCI)E

User’s Guide

CONTEC CO.,LTD.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E i

Check Your Package

Thank you for purchasing the CONTEC product.

The product consists of the items listed below.

Check, with the following list, that your package is complete. If you discover damaged or missing

items, contact your retailer.

Product Configuration List

- Board (One of the following) …1

[AD12-16(PCI)E, AD12-16U(PCI)E or AD16-16(PCI)E] …1

- User’s Guide (this booklet) …1

- CD-ROM [API-PAC(W32)] …1

Board CD-ROM

[API-PAC(W32)]

User’s Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ii AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E

No part of this document may be copied or reproduced in any form by any means without prior written

consent of CONTEC CO., LTD.

CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this

document. The information in this document is subject to change without notice.

All relevant issues have been considered in the preparation of this document. Should you notice an

omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.

Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may

appear in this document or for results obtained by the user as a result of using this product.

Trademarks

MS, Microsoft, Windows and Windows NT are trademarks of Microsoft Corporation. Other brand and

product names are trademarks of their respective holder.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E iii

Table of Contents

Check Your Package................................................................................................................................i

Copyright.................................................................................................................................................ii

Trademarks..............................................................................................................................................ii

Table of Contents ...................................................................................................................................iii

1. BEFORE USING THE PRODUCT 1

About the Board ......................................................................................................................................1

Features.............................................................................................................................................1

Support Software..............................................................................................................................2

Cable & Connector (Option) ........................................................................................................3

Accessories (Option).....................................................................................................................3

Customer Support....................................................................................................................................4

Web Site ...........................................................................................................................................4

Limited Three-Years Warranty...............................................................................................................4

How to Obtain Service............................................................................................................................4

Liability ...................................................................................................................................................4

Safety Precautions...................................................................................................................................5

Safety Information ...........................................................................................................................5

Handling Precautions.......................................................................................................................6

Environment.....................................................................................................................................7

Inspection .........................................................................................................................................7

Storage..............................................................................................................................................7

Disposal............................................................................................................................................7

2. SETUP 9

What is Setup?.........................................................................................................................................9

Using the Board under Windows Using the Driver Library API-PAC(W32)...............................9

Using the Board under Windows Using Software Other than the Driver Library

API-PAC(W32)................................................................................................................................9

Using the Board under an OS Other than Windows.....................................................................10

Step 1 Installing the Software...............................................................................................................11

About the driver to be used............................................................................................................11

Starting the Install Program...........................................................................................................12

Select API-AIO(WDM).................................................................................................................13

Select API-AIO(98/PC) .................................................................................................................14

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iv AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E

Step 2 Setting the Hardware..................................................................................................................16

Parts of the Board and Factory Defaults........................................................................................16

Setting the Board ID.......................................................................................................................19

Setting the interrupt signal resource ..............................................................................................19

Setting the Analog Input ................................................................................................................20

Setting the Analog Output..............................................................................................................22

Setting the Counter Control and Digital I/O Signals ....................................................................23

Plugging the Board.........................................................................................................................24

Step 3 Installing the Hardware..............................................................................................................25

Turning on the PC ..........................................................................................................................25

When Using API-AIO(WDM).......................................................................................................25

When Using API-AIO(98/PC).......................................................................................................27

Step 4 Initializing the Software.............................................................................................................30

When Using API-AIO(WDM).......................................................................................................30

When Using API-AIO(98/PC).......................................................................................................32

Step 5 Checking Operations with the Diagnosis Program...................................................................33

What is the Diagnosis Program?....................................................................................................33

Check Method.................................................................................................................................33

Using the Diagnosis Program for Use of API-AIO(WDM) .........................................................34

Using the Diagnosis Program for Use of API-AIO(98/PC)..........................................................38

Setup Troubleshooting...........................................................................................................................41

Symptoms and Actions...................................................................................................................41

If your problem cannot be resolved...............................................................................................41

3. EXTERNAL CONNECTION 43

Using the On-board Connectors............................................................................................................43

Connecting a Device to a Connector .............................................................................................43

Connector Pin Assignment.............................................................................................................45

Analog Input Signal Connection...........................................................................................................47

Single-ended Input..........................................................................................................................47

Differential Input............................................................................................................................48

Analog Output Signal Connection........................................................................................................49

Digital I/O signals and Control signals Connection.............................................................................50

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E v

4. FUNCTIONS 51

Analog Input Function ..........................................................................................................................51

1. Setting the Conversion Conditions............................................................................................52

2. Starting/Stopping Operation......................................................................................................57

3. Monitoring the Status and Acquiring Data ...............................................................................58

4. Reset ...........................................................................................................................................61

5. Extended function......................................................................................................................61

Analog Output Function........................................................................................................................62

Digital Input Function...........................................................................................................................64

Digital Output Function ........................................................................................................................65

5. ABOUT SOFTWARE 67

When using the API-AIO(WDM).........................................................................................................68

Accessing the Help File.................................................................................................................68

Using Sample Programs.................................................................................................................69

Using Utility Programs ..................................................................................................................71

When using the API-AIO(98/PC).........................................................................................................76

Accessing the Help File.................................................................................................................76

Using Sample Programs.................................................................................................................77

Using the Utility Program..............................................................................................................79

Uninstalling the Driver Libraries..........................................................................................................81

CD-ROM Directory Structure ..............................................................................................................82

6. ABOUT HARDWARE 83

Hardware specification .........................................................................................................................83

Block Diagram.......................................................................................................................................87

Timing of Sampling Control Signals....................................................................................................88

About Calibration..................................................................................................................................89

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

vi AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1. Before Using the Product

AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E 1

1. Before Using the Product

About the Board

AD12-16(PCI)E, AD12-16U(PCI)E and AD16-16(PCI)E are PCI-compliant interface boards that

convert analog input signals to digital equivalents (performing analog-to-digital conversion).

< AD12-16(PCI)E > is the general-purpose type that can perform A-D conversion at a conversion speed

of 10µsec per channel and a resolution of 12-bit.

< AD12-16U(PCI)E > is the high-speed type that can perform A-D conversion at a conversion speed of

1µsec per channel and a resolution of 12-bit.

< AD16-16(PCI)E > is the high-precision type that can perform A-D conversion at a conversion speed

of 10µsec per channel and a resolution of 16-bit.

Using the bundled driver library [API-PAC(W32)], you can create Windows application software for

this board in your favorite programming language supporting Win32 API functions, such as Visual

Basic or Visual C/C++.

Features

Sixteen single-ended channels and eight differential channels (Analog input function)

Either board allows the single-ended or differential input mode to be selected with on-board jumpers.

The order of channels subject to signal conversion can be preset in the dedicated register. Using an

optional unit, the board can increase the maximum number of input channels (up to 32 channels) and

perform simultaneous sampling.

On-board buffer memory (Analog input function)

The board has buffer memory available as a FIFO or ring buffer to hold 256 kilobytes of data. This

enables sampling to be executed in the background independently of the processing power of the PC.

Assorted sampling control functions (Analog input function)

The board can control the starting and stopping of sampling not only with software commands but also

by detecting analog signal strength or TTL-level signals. The board offers a choice of sampling clocks

selectable to determine the sampling speed: the internal sampling clock using the on-board clock

generator and the external sampling clock using the digital signal input from an external device.

Analog output function

The board has one channel of analog output function.

Digital input/output function

The board has four digital input and four digital output pins for TTL-level signals, allowing an external

device to be monitored and controlled.

Abundant optional units

Optional units are available for enhancements.

Using optional units enhances board functions and facilitates connections.

For more details on the option, please refer to this chapter “Cable & Connector” or

“Accessories (Option)”.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1. Before Using the Product

2AD12-16(PCI)E, AD12-16U(PCI)E, AD16-16(PCI)E

Support Software

You should use CONTEC support software according to your purpose and development environment.

Driver Library API-PAC(W32) (Bundled)

API-PAC(W32) is the library software that provides the commands for CONTEC hardware products in the form of

Windows standard Win32 API functions (DLL). It makes it easy to create high-speed application software taking

advantage of the CONTEC hardware using various programming languages that support Win32 API functions, such as

Visual Basic and Visual C/C++.

It can also be used by the installed diagnosis program to check hardware operations.

CONTEC provides download services to supply the updated drivers and differential files.

For details, read Help on the bundled CD-ROM or visit the CONTEC’s Web site.

< Operating environment >

OS Windows XP, 2000, NT, Me, 98, etc..

Adaptation language Visual C/C++, Visual Basic, Delphi, Builder, etc..

Others Each piece of library software requires 50 megabytes of free hard disk space.

Linux version of analog I/O driver API-AIO(LNX) (Supplied: Stored on the API-PAC(W32)

CD-ROM)

This driver is used to control CONTEC analog I/O boards (PC Cards) from within Linux.

You can control CONTEC I/O boards easily using the shared library used by gcc and Kylix, the device driver (module)

for each kernel version, and the board (PC Card) configuration program (config).

CONTEC provides download services to supply the updated drivers and differential files.

For details, read Help on the bundled CD-ROM or visit the CONTEC’s Web site.

< Operating environment >

OS RedHatLinux, TurboLinux, etc..

(For details on supported distributions, refer to Help available after installation.)

Adaptation language gcc, Kylix, etc..

Others Requires 3 megabytes of free hard disk space.

Base package of ActiveX components for measurement system development

ACX-PAC(W32)BP (Option)

This is a set of useful Windows development tools for measurement systems and consists of a software component

library with ready-to-use samples which you can combine for easy programming.

The package contains components for controlling CONTEC I/O boards (PC Cards). Features include interface

control for analog I/O, digital I/O, GPIB communications, and counter inputs, as well as X-Y plotting and file storage

support.

Check the CONTEC’s Web site for more information on this soft.

Advanced package of ActiveX components for measurement system development

ACX-PAC(W32)AP (Option)

Complements the ACX-PAC(W32)BP functions with additional components including graphics (plotting, switches,

and lamps, etc.) and mathematical and analysis tools.

Check the CONTEC’s Web site for more information on this soft.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Otros manuales para PCI-bus Analog Input Multi-Function Board...

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de E/S de Contec

Contec

Contec PIO-32/32B(PCI)V Manual de usuario

Contec

Contec PIO-16 Manual de usuario

Contec

Contec AO-1604CI2-PCI Manual de usuario

Contec

Contec COM-4CX-USB Manual de usuario

Contec

Contec PIO-16H Manual de usuario

Contec

Contec DIO-128SLX-USB Manual de usuario

Contec

Contec AI-1664LAX-USB Manual de usuario

Contec

Contec CONPROSYS Series Guía del usuario

Contec

Contec AI-1604CI2-PCI Manual de usuario

Contec

Contec CONPROSYS nano CPSN-DI-16BCL Manual de usuario

Contec

Contec AIO-163202FX-USB Manual de usuario

Contec

Contec DIO-96D2-LPCI Manual de usuario

Contec

Contec F&eIT Series Manual de usuario

Contec

Contec DIO-3232L-PE Manual de usuario

Contec

Contec PIO-32/32RL(PCI)H Manual de usuario

Contec

Contec DAI12-4(USB)GY Manual de usuario

Contec

Contec DI-128L-PE Manual de usuario

Contec

Contec N Series Manual de usuario

Contec

Contec PIO-16/16B(PCI)H Manual de usuario

Contec

Contec RRY-16C(PCI)H Manual de usuario

Contec

Contec F&eIT Series Manual de usuario

Contec

Contec DI-32T2-PCI Manual de usuario

Contec

Contec ADI16-4(USB) Manual de usuario

Contec

Contec AO-1604L-LPE Manual de usuario

Manuales populares de Sistema de E/S de otras marcas

WAGO

WAGO 750-344 Manual de usuario

Teknim

Teknim TWM-1887 Manual de instrucciones

Intelligent Appliance

Intelligent Appliance IA-2662-E Manual de usuario

BERGHOF

BERGHOF ECC DIO 16/16 Manual de instrucciones

Advantech

Advantech PCM-27J3AU Manual de instalación y operación

Festo

Festo CP-E08-M12-CL Manual de usuario

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manual de usuario

Hitachi

Hitachi HX-RIO3 Series Manual de usuario

NUUO

NUUO SCB-A08 Manual de usuario

M-system

M-system R3Y-RS8 Manual de usuario

jablotron

jablotron JB-110N Manual de usuario

Omron

Omron SYSMAC C200H Manual de usuario

DOLD

DOLD SAFEMASTER M Manual de usuario

ABB

ABB OPT-MF-001 Manual de usuario

Omron

Omron SYSMAC C2000H Manual de usuario

Helmholz

Helmholz TB20 Manual de usuario

ICP DAS USA

ICP DAS USA tM-AD2 Manual de usuario

Automationdirect.com

Automationdirect.com DL305 Manual de usuario
