Contec F&eIT Series Manual de usuario

F&eIT Series

Isolated Analog Input Module

ADI12-8(FIT)GY

User’s Manual

CONTEC CO.,LTD.

ADI12-8(FIT)GY i

Check Your Package

Thank you for purchasing the CONTEC product.

The product consists of the items listed below.

Check, with the following list, that your package is complete. If you discover damaged

or missing items, contact your retailer.

Product Configuration List

- Module …1

- First Step Guide …1

- CD-ROM [F&eIT Series Setup Disk] *1…1

- Interface connector plugs …2

- Warranty Certificate …1

- Serial number label …1

*1 The CD-ROM contains various software and User’s Manual (this manual)

Interface connector plugsModule

CD-ROM

First step guide [F&eIT Series Setup Disk]

ADI12-8

Device

CH0

CH1

CH2

CH3

CH4

CH5

CH6

CH7

RUN STATUS

Warranty Certificate

XXXXX XXXXX XXX

Serial number label

Warr anty

Certificate

ii ADI12-8(FIT)GY

No part of this document may be copied or reproduced in any form by any means

without prior written consent of CONTEC CO., LTD.

CONTEC CO., LTD. makes no commitment to update or keep current the information

contained in this document.

The information in this document is subject to change without notice.

All relevant issues have been considered in the preparation of this document. Should

you notice an omission or any questionable item in this document, please feel free to

notify CONTEC CO., LTD.

Regardless of the foregoing statement, CONTEC assumes no responsibility for any

errors that may appear in this document nor for results obtained by the user as a resultof

using this product.

Trademarks

F&eIT is a registered trademark or trademark of CONTEC CO., LTD. Other company

and product names that are referred to in this manual are generally trademarks or

registered trade trademark.

ADI12-8(FIT)GY iii

Table of Contents

Check Your Package .......................................................... i

Trademarks.......................................................................ii

Table of Contents.............................................................iii

1. Introduction ..................................................................... 1

Features ........................................................................ 1

Functions and control method by

controller connected ..................................................... 2

Limited One-Year Warranty ........................................ 4

How to Obtain Service ................................................. 4

Liability......................................................................... 4

Handling Precautions .................................................. 5

About the Manual......................................................... 6

2. Module Nomenclature and Settings ............................... 7

Nomenclature of Module Components ............................ 7

Setting a Device ID........................................................... 8

Setup Method ............................................................... 8

LED Indicator ................................................................... 8

3. Connecting to an External Device .................................. 9

Interface Connector .......................................................... 9

How to Connect an Interface Connector ..................... 9

Signal Layout on the Interface Connector................ 10

Example of connecting a current input..................... 11

iv ADI12-8(FIT)GY

4. Using the I/O Address Map............................................13

Starting I/O Address ...................................................... 13

List of I/O Address Maps................................................ 14

Specifications Common to F&eIT Products .................. 16

Product Information................................................... 16

Overview of the Sampling Function.............................. 19

List of Commands........................................................... 30

Examples ........................................................................ 31

Software Mode............................................................ 31

Clock Mode (No Interrupts)....................................... 33

Clock Mode (with Interrupts).................................... 36

5. Using the Memory Address Map ...................................41

Module Settings Area................................................. 42

Module Information Area .......................................... 45

Basic Input Data Area ............................................... 47

Examples ........................................................................ 49

6. System Reference ...........................................................53

Block Diagram................................................................ 53

Specifications.................................................................. 54

External Dimensions...................................................... 56

Introduction

ADI12-8(FIT)GY 1

1. Introduction

Congratulations on your recent purchase of an Insulator Digital Input Module.

By converting external analog voltage signals into digital data, theADI12-8(FIT)GY

can process them inside the F&eIT series controller module < CPU-CAxx(FIT)GYGY,

CPU-SBxx(FIT)GY etc >.

The insulation between external signals and the Controller Module permits the use of

the Controller Module without compromising the communications features of the latter.

Please read this manual carefully to create application programs and configure the

system, such as setting the switches and connecting it to external devices.

Features

- The input range is common to different channels, and can be selected from four input

ranges, including unipolar and bipolar ranges.

- The ability to accommodate differential input permits the accurate measurement of

voltage values over long distances from the signal source and even under a

considerable potential difference.

- A rotary switch allows you to set device IDs to help you keep track of device

numbers.

- The system incorporates a screwless connector plug that allows you to easily attach

and detach wires without using any special tools.

- Similar to other F&eIT series products, the system, in the module itself, incorporates

a 35-mm DIN rail mounting mechanism as a standard item. A connection to a

controller module can be effected on a lateral, stack basis in a unique configuration,

which permits a simple, smart system configuration without the need for a backplane

board.

Introduction

2 ADI12-8(FIT)GY

Functions and control method by controller connected

The ADI12-8(FIT)GY can be connected to a variety of controllers.

Micro Controller Unit : CPU-SBxx(FIT)GY

I/O Controller Module : CPU-CAxx(FIT)GY

Monitoring & Control Server Unit : SVR-MMF2(FIT)

Monitoring & Control Server Unit : SVR-MMF(FIT)GY

Isolated Analog Input Module for USB : ADI12-8(USB)GY

I/O Controller Module with USB : CPU-CA10(USB)GY

The functions and control of the ADI12-8(FIT)GYvary with the controller to which the

ADI12-8(FIT)GY is connected.

Functions available with each controller connected

CPU-SBxx(FIT)GY

CPU-CAxx(FIT)GY

SVR-MMF2(FIT)

SVR-MMF(FIT)GY

DI12-8(USB)GY

CPU-CA10(USB)GY

*1*1

Software input range setting οο οο

A/D conversion with software command οο οο

Continuous A/D conversion based on internal samplin

o*2 o*3

Interrupt function ο

Device ID setting range 0 - 7 0 - 7 0 - 7 0 - 7 1 - 3 0 - 7

*1*1

*1 For the function available, refer to the reference manual for the SVR-MMF2(FIT),

SVR-MMF(FIT)GY.

*2 Sampling timer setting: 10 to 1,073,741,824 μsec.

*3 Using the sampling timer built in the ADI12-8(USB)GY.

The setting range is from 1000 to 1,073,741,000 μsec.

Introduction

ADI12-8(FIT)GY 3

Control method by controller connected

CPU-SBxx(FIT)GY

CPU-CAxx(FIT)GY

SVR-MMF2(FIT)

SVR-MMF(FIT)GY

DI12-8(USB)GY

CPU-CA10(USB)GY

Control using the I/O address map ο

Control using the memory address map ο

FIT Protocol ο

API-CAP(W32) ο

API-SBP(W32) ο

API-USBP(WDM) οο

Control over the web οο

Control via the Windows driver *

* The API-SBP(W32) is included in the development kit

DTK-SBxx(FIT)GY; the other drivers are bundled with each controller.

Control using the I/O address map

When connected to the CPU-SBxx(FIT)GY, the ADI12-8(FIT)GY can receive I/O

instructions directly from the controller module. For details, see Chapter 4 “Using the

I/O Address Map”.

Control using the memory address map

When connected to the CPU-CAxx(FIT)GY, the ADI12-8(FIT)GY can be accessed

from the host computer over the network.

The ADI12-8(FIT)GY is assigned with its device ID in the memory managed by the

controller module. The application running on the host computer controls the module

by reading/writing the memory managed by the controller module. For details, see

Chapter 5 “Using the Memory Address Map”.

Control via the Windows driver

For the functions and settings available when using the Windows driver, refer to the

reference manual and online help for each module.

Control over the web

You can monitor collected data and manage the log over the web. You can use your

familiar browser to easily make various settings. For details, refer to the reference

manual for the SVR-MMF2(FIT), SVR-MMF(FIT)GY.

Introduction

4 ADI12-8(FIT)GY

Limited One-Year Warranty

CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in

material and workmanship for up to one year from the date of purchase by the original

purchaser.

Repair will be free of charge only when this product is returned freight prepaid with a

copy of the original invoice and a Return Merchandise Authorization to the distributor

or the CONTEC group office, from which it was purchased.

This warranty is not applicable for scratches or normal wear, but only for the electronic

circuitry and original products. The warranty is not applicable if the device has been

tampered with or damaged through abuse, mistreatment, neglect, or unreasonable use,

or if the original invoice is not included, in which case repairs will be considered

beyond the warranty policy.

How to Obtain Service

For replacement or repair, return the device freight prepaid, with a copy of the original

invoice. Please obtain a Return Merchandise Authorization Number (RMA) from the

CONTEC group office where you purchased before returning any product.

* No product will be accepted by CONTEC group without the RMA number.

Liability

The obligation of the warrantor is solely to repair or replace the product. In no event will the

warrantor be liable for any incidental or consequential damages due to such defect or

consequences that arise from inexperienced usage, misuse, or malfunction of this device.

Introduction

ADI12-8(FIT)GY 5

Handling Precautions

Take the following precautions when handling this module.

-Do not modify the module. CONTEC will bear no responsibility for any problems, etc.,

resulting from modifying this module.

-Do not use or store the equipment in a hot or cold place, or in a place that is subject to

severe temperature changes. (Operating temperature range: 0 - 50°C)

-Do not use or store the equipment in a place subject to direct sunlight or near a heating

device, such as a stove.

-Do not use or store the equipment in a dusty or humid place. (Operating humidity

range: 10 - 90%RH, No condensation)

-As this product contains precision electronic components, do not use or store in

environments subject to shock or vibration.

-Do not use or store the product near equipment generating a strong magnetic field or

radio waves.

-If you notice any strange odor or overheating, please unplug the power cord

immediately.

-In the event of an abnormal condition or malfunction, please consult the dealer from

whom the equipment was purchased.

-To avoid electric shock, please do not touch the system with a wet hand.

-Do not open the module casing. CONTEC will disclaim any responsibility for

equipment whose casing has been opened.

-To prevent damage, please do not subject the module to impact or bend it.

-To prevent contact malfunction, please do not touch the metallic pins on the external

module connector.

-The module contains switches that need to be properly set. Before using the module,

please check its switch settings.

-To avoid malfunction, please do not change the module switch settings in an

unauthorized manner.

-"Do not operate the device module when the power for the Controller Module is on.

To avoid malfunction, please be sure to turn off the power for the Controller

Module".

-If you use this product in a noisy environment, attach ferrite cores to the IO cable to

stabilize the operation.

Otros manuales para F&eIT Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de E/S de Contec

Contec

Contec PIO-32DM Manual de usuario

Contec

Contec ADA16-8/2(LPCI)L Manual de usuario

Contec

Contec ADI12-8(USB)GY Manual de usuario

Contec

Contec CONPROSYS nano CPSN-COM-1PD Manual de usuario

Contec

Contec F&eIT Series Manual de usuario

Contec

Contec AIO-160802GY-USB Manual de usuario

Contec

Contec DIO-48DX-USB Manual de usuario

Contec

Contec CPS-MC341-DS2-111 Manual de usuario

Contec

Contec PIO-64 Manual de usuario

Contec

Contec PIO-32H(PCI)H Manual de usuario

Contec

Contec PIO-16H Manual de usuario

Contec

Contec PIO-16/16L(PCI)H Manual de usuario

Contec

Contec DAI16-4(USB) Manual de usuario

Contec

Contec PIO-16/16B(PCI)H Manual de usuario

Contec

Contec DAI12-4(USB)GY Manual de usuario

Contec

Contec CONPROSYS nano CPSN-DI-16BCL Manual de usuario

Contec

Contec AI-1204Z-PCI Manual de usuario

Contec

Contec AO-1604CI3-PCI Manual de usuario

Contec

Contec PIO-32/32F(PCI)H Manual de usuario

Contec

Contec CONPROSYS CPS-MM-LC Manual de usuario

Contec

Contec N Series Manual de usuario

Contec

Contec AD12-64(PCI) Manual de usuario

Contec

Contec AI-1664LAX-USB Manual de usuario

Contec

Contec DIO-1616TB-PE Manual de usuario

Manuales populares de Sistema de E/S de otras marcas

WAGO

WAGO 750-344 Manual de usuario

Teknim

Teknim TWM-1887 Manual de instrucciones

Intelligent Appliance

Intelligent Appliance IA-2662-E Manual de usuario

BERGHOF

BERGHOF ECC DIO 16/16 Manual de instrucciones

Advantech

Advantech PCM-27J3AU Manual de instalación y operación

Festo

Festo CP-E08-M12-CL Manual de usuario

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manual de usuario

Hitachi

Hitachi HX-RIO3 Series Manual de usuario

NUUO

NUUO SCB-A08 Manual de usuario

M-system

M-system R3Y-RS8 Manual de usuario

jablotron

jablotron JB-110N Manual de usuario

Omron

Omron SYSMAC C200H Manual de usuario

DOLD

DOLD SAFEMASTER M Manual de usuario

ABB

ABB OPT-MF-001 Manual de usuario

Omron

Omron SYSMAC C2000H Manual de usuario

Helmholz

Helmholz TB20 Manual de usuario

ICP DAS USA

ICP DAS USA tM-AD2 Manual de usuario

Automationdirect.com

Automationdirect.com DL305 Manual de usuario
