Connects2 Connects2Vision CAM-22 Manual de usuario

Image Sensor: 1099 HD-CCD

Resolution: 976 x 496

TV Lines: 480

Horizontal Angle: 170 Degrees

Vertical Angle: 120 Degrees

Lumen: 0.1 Lux

TV System: NTSC

Video Output: 1.0V p-p 75ohm

Operating Voltage: 12V DC (Negative Ground)

Current Consumption: 120mA @ 13.8V

Waterproof Rating: IP68

Operating Temperature: -20 Degrees C to +70 Degrees C

Parking Lines: Yes

Removable Lines: Yes

Adjustable Image: Yes (Mirror/Normal

Enhanced Performance In Low Light: Yes

User Manual

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation.

Please ensure you use the correct tools to avoid damage to the vehicle or product.

Connects2 can not be held responsible for the installation of this product.

Technical Support

Connects2 want to provide a fast and suitable resolution should you encounter any

technical issues. With this in mind, when contacting Connects2, try to provide as

much Information as possible. This will speed up the process and help us to help you.

Please use our dedicated online technical support centre: support.connects2.com

Universal Camera

Surface Mount Metal Bracket

with Bevelled Squared Housing

PRODUCT FEATURES:

DISCLAIMER:

CAM-22

www.connects2.com

Connects2Vision

CONTENTS

- Camera with adjustable bracket and 1m cable to mini Male 6 pin connector

- 1m camera connection cable to mini Female 6 pin connector and RCA

Female connector

- 6m Male to Male RCA extension cable

- Instructions

INSTALLATION

1. Connect the Black wire to a suitable ground and the Red wire to a switched

+12V supply.

2. If the camera is to be used in the rear of the vehicle, the Red wire should

be connected to the reversing light circuit or an interface which provides a

reverse signal.

3. Select a suitable location for the camera and ensure that the area is free

from all cables, fuel & oil. Whenever possible, avoid locations that are subject

to road dirt & water spray.

4. Remove the protective backing from the adhesive pad and place the

camera in the required position.

5. Using the supplied video cable, connect the camera to the display screen

and ensure that the image is displayed correctly.

6. Adjustment of the camera may be required to ensure that the correct angle

of the image is achieved.

7. To swap the image from mirror to normal view, cut the small White looped

wire which is located on the camera connection cable.

8. To remove the parking line feature, cut the small Blue looped wire which is

located on the camera connection cable.

Subscribe to our YouTube Channel for installation

guides and tips... www.youtube.com/connects2
