Compaq TFT1701 Manual de usuario

User’s Guide

Compaq TFT1701 Flat Panel Monitor

Document Part Number: 304323-001

August 2002

TFT1701.book Page 1 Monday, July 29, 2002 3:31 PM

Compaq, the Compaq logo are trademarks of Compaq Information

Technologies Group, L.P. in the U.S. and other countries

Microsoft, MS-DOS, Windows, Windows NT are trademarks of Microsoft

Corporation in the United States and other countries.

All other product names mentioned herein may be trademarks of their

respective companies.

Hewlett-Packard shall not be liable for technical or editorial errors or

omissions contained herein. The information in this document is provided

“as is” without warranty of any kind and is subject to change without

notice. The warranties for HP products are set forth in the express limited

warranty statements accompanying such products. Nothing herein should

be construed as constituting an additional warranty.

HP service tool software, including associated documentation, is the

property of and contains confidential technology of Hewlett-Packard

Company. Service customer is hereby licensed to use the software only for

activities directly relating to the delivery of, and only during the term of,

the applicable services delivered by HP or its authorized service provider.

Customer may not modify or reverse engineer, remove, or transfer the

software or make the software or any resultant diagnosis or system

management data available to other parties without HP’s or its authorized

service provider’s consent. Upon termination of the services, customer will,

at HP’s or its service provider’s option, destroy or return the software and

associated documentation in its possession.

ÄCAUTION: Text set off in this manner indicates that failure to follow

directions could result in damage to equipment or loss of

information.

ÅWARNING: Text set off in this manner indicates that failure to follow

directions could result in bodily harm or loss of life.

User’s Guide

TFT1701 Flat Panel Monitor

First Edition August 2002

Part Number: 304323-001

TFT1701.book Page 2 Monday, July 29, 2002 3:31 PM

User’s Guide 3

Contents

Product Features

Safety and Maintenance Guidelines

Important Safety Information. . . . . . . . . . . . . . . . . . . . . . 2–1

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Setting Up the Monitor

Removing the Monitor Base . . . . . . . . . . . . . . . . . . . . . . 3–3

Attaching a Wall-Mount Base . . . . . . . . . . . . . . . . . . . . . 3–4

Operating the Monitor

Installing Information Files . . . . . . . . . . . . . . . . . . . . . . . 4–1

Front Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . 4–2

Rear Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3

Using the On-Screen Display. . . . . . . . . . . . . . . . . . . . . . 4–4

Using the OSD Menu . . . . . . . . . . . . . . . . . . . . . . . . 4–6

Monitor Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 4–12

Energy Saver Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–13

Adjusting Screen Quality . . . . . . . . . . . . . . . . . . . . . . . . 4–13

User Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–14

Troubleshooting

Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . A–1

Using the Worldwide Web. . . . . . . . . . . . . . . . . . . . . . . . A–3

Preparing to Call Technical Support . . . . . . . . . . . . . . . . A–3

TFT1701.book Page 3 Monday, July 29, 2002 3:31 PM

4User’s Guide

Contents

Specifications

Compaq TFT1701 Flat Panel Monitor. . . . . . . . . . . . . . . B–1

Display Resolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–2

Agency Regulatory Notices

Federal Communications Commission Notice. . . . . . . . . C–1

Modifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2

Declaration of Conformity for Products

Marked with FCC Logo, United States Only . . . . . . C–2

Canadian Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–3

Avis Canadien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–3

European Union Notice . . . . . . . . . . . . . . . . . . . . . . . C–3

Japanese Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–4

Korean Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–4

EPA Energy Star Compliance . . . . . . . . . . . . . . . . . . C–4

Power Cord Set Requirements. . . . . . . . . . . . . . . . . . C–5

TCO ‘99

Why do we have environmentally labelled computers? . D–2

What does labelling involve?. . . . . . . . . . . . . . . . . . . . . . D–2

Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . D–4

Flame Retardants . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–4

Cadmium . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–5

Mercury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–5

CFCs (Freons) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–6

Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–6

TFT1701.book Page 4 Monday, July 29, 2002 3:31 PM

User’s Guide 1–1

Product Features

Your flat panel monitor has an active matrix, thin-film transistor

(TFT), liquid crystal display (LCD). The monitor features

include:

■17-inch (43.18 cm) viewable area display.

■1280 x 1024 resolution, plus full-screen support for lower

resolutions.

■Wide viewing angle to allow viewing from a sitting or

standing position, or moving side-to-side.

■Removable base for flexible mounting solutions.

■Plug and play capability if supported by your system.

■On-Screen Display (OSD) adjustments in seven different

languages: English, French, German, Italian, Russian,

Swedish and Spanish for ease of set-up and screen

optimization.

■Software and Reference Library CD that comes with your

monitor and contains an information file (INF), Image Color

Matching file (ICM) and Auto-adjustment software.

■Energy Saver feature for Energy Star compliance.

■Compliant with the following regulated specifications:

❏EPA ENERGY STAR

❏European Union CE Directives

❏Swedish MPR II 1990

❏Swedish TCO '99

TFT1701.book Page 1 Monday, July 29, 2002 3:31 PM

User’s Guide 2–1

Safety and Maintenance

Guidelines

Important Safety Information

A power cord is included with your monitor. If another cord is

used, use only a power source and connection appropriate for this

monitor. For information on the correct power cord set to use with

your monitor, refer to the “Power Cord Set Requirements” section

in Appendix C of this guide.

ÅWARNING: To reduce the risk of electric shock or damage to your

equipment, do not disable the power cord grounding feature. This

equipment is designed to be connected to a grounded (earthed)

power outlet that is easily accessible to the operator. The grounding

plug is an important safety feature.

ÅWARNING: For your safety, be sure that the power outlet you plug

the power cord into is easily accessible and located as close to the

equipment as possible. When you need to disconnect the power to

the equipment, unplug the power cord from the power outlet by

grasping the plug firmly. Never pull on the cord.

ÄCAUTION: For the protection of your monitor, as well as your

computer, connect all power cords for your computer and its

peripheral devices (such as a monitor, printer, scanner) to some

form of surge protection device such as a power strip or

Uninterruptible Power Supply (UPS). Not all power strips provide

surge protection; the power strips must be specifically labeled as

having this ability. Use a power strip whose manufacturer offers a

Damage Replacement Policy so you can replace your equipment if

surge protection fails.

TFT1701.book Page 1 Monday, July 29, 2002 3:31 PM

2–2 User’s Guide

Safety and Maintenance Guidelines

Maintenance Guidelines

To enhance the performance and extend the life of your monitor:

■Do not open your monitor cabinet or attempt to service this

product yourself. Adjust only those controls that are covered

in the operating instructions. If your monitor is not operating

properly or has been dropped or damaged, contact your HP

authorized dealer, reseller, or service provider.

■Adjust only those controls that are discussed in the operating

instructions.

■Place your monitor at least 3 inches (76 mm) away from

walls or other enclosures.

■Use only a power source and connection appropriate for this

monitor, as indicated on the label/back plate of the monitor.

■Be sure the total ampere rating of the products connected to

the outlet does not exceed the current rating of the electrical

outlet, and the total ampere rating of the products connected

to the cord does not exceed the rating of the cord. Look on the

power label to determine the ampere rating (AMPS or A) for

each device.

■Install your monitor near an outlet that you can easily reach.

Disconnect the monitor by grasping the plug firmly and

pulling it from the outlet. Never disconnect the monitor by

pulling the cord.

■Turn your monitor off when not in use. You can substantially

increase the life expectancy of your monitor by using a screen

saver program and turning off monitor when not in use.

■Unplug your monitor from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp

cloth for cleaning. If the screen requires additional cleaning,

use an antistatic screen cleaner.

ÄCAUTION: Do not use benzene, thinner, ammonia, or any other

volatile substances to clean your monitor or the screen. These

chemicals may damage the cabinet finish as well as the screen.

TFT1701.book Page 2 Monday, July 29, 2002 3:31 PM

Safety and Maintenance Guidelines

User’s Guide 2–3

■Slots and openings in the cabinet are provided for ventilation.

These openings must not be blocked or covered. Never push

objects of any kind into cabinet slots or other openings.

■Do not drop your monitor or place it on an unstable surface.

■Do not allow anything to rest on the power cord. Do not walk

on the cord.

■Keep your monitor in a well-ventilated area, away from

excessive light, heat or moisture. Keep your monitor away

from high-capacity transformers, electric motors, and other

devices with strong magnetic fields.

TFT1701.book Page 3 Monday, July 29, 2002 3:31 PM

User’s Guide 3–1

Setting Up the Monitor

Before setting up the monitor, ensure that power is turned off to

the monitor, computer system, and other attached devices, then

follow these steps:

1. Place the monitor in a convenient, well ventilated location

near your computer.

2. Connect the power cord 1for your monitor to the power port

on the rear of the monitor. Plug the power cord for the

monitor into a nearby electrical outlet.

3. Connect the monitor signal cable 2to the 15-pin, D-sub

connector on the back of your monitor.

4. Connect the other end of the signal cable 3to your

computer’s video port, video board, video card or

graphics card.

TFT1701.book Page 1 Monday, July 29, 2002 3:31 PM

3–2 User’s Guide

Setting Up the Monitor

5. Connect the computer’s power cable to an electrical outlet.

6. Turn on your computer and monitor. If your monitor displays

an image, installation is complete.

ÅWARNING: To reduce the risk of electric shock or damage to your

equipment:

■Do not disable the power cord grounding plug. The grounding

plug is an important safety feature.

■Plug the power cord into a grounded (earthed) electrical outlet

that is easily accessible at all times.

■Disconnect power from the monitor by unplugging the power

cord from the electrical outlet.

■Do not place anything on power cords or cables. Arrange them

so that no one may accidentally step on or trip over them. Do

not pull on a cord or cable. When unplugging from the electrical

outlet, grasp the cord by the plug.

✎After you turn on the monitor and computer equipment, refer to

“Installing Information Files” in chapter 4 to install the software

contained on the CD that is included with your monitor. Use the

on-screen instructions to adjust the picture quality of your

monitor.

Always activate a screen saver program or turn off the monitor

when it is not in use for a prolonged period of time. All LCD

monitors that display the same static image on screen for a

prolonged period of time may exhibit screen image retention.

Note that image retention is not a permanent condition and will

fade over a period of time. Image retention is a condition that may

occur on all LCD screens.

TFT1701.book Page 2 Monday, July 29, 2002 3:31 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Compaq

Compaq

Compaq 8000 - Elite Convertible Minitower PC Manual de usuario

Compaq

Compaq P1220 Manual de usuario

Compaq

Compaq CRT Monitor s7500 Manual de usuario

Compaq

Compaq 1825 Manual de usuario

Compaq

Compaq P 110 Manual de usuario

Compaq

Compaq S900 Instrucciones de uso

Compaq

Compaq TFT 1501 Manual de usuario

Compaq

Compaq CPQ-C1786FNSL Manual de usuario

Compaq

Compaq TFT5010 Manual de usuario

Compaq

Compaq Compaq P1610 Manual de usuario

Compaq

Compaq 378901-008 - FP 700 - 15" LCD Monitor Instrucciones de instalación

Compaq

Compaq 151FS - QVision - 15" CRT Display Manual de usuario

Compaq

Compaq 8000 - Elite Convertible Minitower PC Manual de usuario

Compaq

Compaq TFT1720 Manual de usuario

Compaq

Compaq V1100 Manual de usuario

Compaq

Compaq MV-920 Manual de usuario

Compaq

Compaq TFT5030 Manual de usuario

Compaq

Compaq MV 740 Manual de usuario

Compaq

Compaq 307713-001 - V 75 - 17" CRT Display Manual de usuario

Compaq

Compaq 7020 Manual de usuario

Compaq

Compaq QVision Graphics System Manual de usuario

Compaq

Compaq Compaq S710 Manual de usuario

Compaq

Compaq V70 Manual de usuario

Compaq

Compaq MV 540 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
