Install Cisco ISE Software on the SNS 3515 and

SNS 3595 Appliances

•Cisco SNS 3500 Series Appliance Overview, page 1

•Before You Begin, page 10

•Install the Cisco SNS 3515 and Cisco SNS 3595 Hardware Appliances, page 15

•Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances, page 30

Cisco SNS 3500 Series Appliance Overview

Cisco SNS 3500 Series Appliances

The Cisco SNS 3515 or Cisco SNS 3595 appliance is designed for performance and density over a wide range

of business workloads, from web serving to distributed databases.

Cisco ISE, Release 2.0.1 is available on SNS 3515 and SNS 3595 platforms.

The SNS 3515 and SNS 3595 appliances support only Cisco ISE 2.0.1 or later releases. You cannot install

a release earlier than 2.0.1 on the SNS 3515 or SNS 3595 appliance.

Note

Support for UEFI Secure Boot

The SNS 3515 and SNS 3595 appliances support the Unified Extensible Firmware Interface (UEFI) secure

boot feature. This feature ensures that only a Cisco-signed ISE image can be installed on the SNS 3515 and

SNS 3595 appliances, and prevents installation of any unsigned operating system even with physical access

to the device. For example, generic operating systems, such as Red Hat Enterprise Linux or Microsoft Windows

cannot boot on this appliance.

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

LED Indicators on Cisco SNS 3515 and 3595 Appliances

This section describes the front- and rear-panel controls, ports, and LED indicators on the Cisco SNS 3515

and Cisco SNS 3595 appliances.

•Cisco SNS-3515 or 3595 Appliance Front Panel View, on page 3

•Cisco SNS 3515 or SNS 3595 Appliance Back Panel View, on page 6

Cisco SNS-3515 and SNS-3595 Appliances Hardware Specifications

The following table describes the hardware specifications of Cisco SNS-3515 and Cisco SNS-3595 appliances.

DiagramsHardware SpecificationsCisco Identity Services

Engine Appliance

Cisco SNS-3515 or 3595 Appliance

Front Panel View, on page 3

Cisco SNS 3515 or SNS 3595

Appliance Back Panel View, on

page 6

•Cisco UCS C220 M4

•Single socket Intel Xeon E5-2620

v3 series CPU @ 2.40GHz, 6 total

cores, 6*2 total threads

•16 GB RAM

•1 x 600-GB disk

•RAID 0

•6 GbE network interfaces

•For physical, environmental, and

power specifications, see Server

Specifications, on page 13

Cisco SNS-3515-K9

•Cisco UCS C220 M4

•Dual socket Intel Xeon E5-2640

v3 series CPU @ 2.60GHz, 8 total

cores, 8*2 total threads

64 GB RAM

4 x 600-GB disks

RAID 10

6 GbE network interfaces

For physical, environmental, and

power specifications, see Server

Specifications, on page 13.

Cisco SNS-3595-K9

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

Cisco SNS-3515 or 3595 Appliance Front Panel View

The following figure shows the components of the Cisco SNS-3515 or Cisco SNS-3595 appliance front panel

view.

Figure 1: Front Panel LEDs

Fan status LED7Drives (up to four 2.5-inch drives)1

Temperature status LED8Pull-out asset tag2

Power supply status LED9Operations panel buttons and LEDs3

Network link activity LED10Power button/power status LED4

KVM connector (used with KVM cable that

provides two USB 2.0, one VGA, and one

serial connector)

11Unit identification button/LED5

System status LED6

The following table describes the LEDs located on the front panel of the Cisco SNS-3515 or Cisco SNS-3595

appliance.

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

Front Panel LEDs

•Off—The hard drive is operating properly.

•Amber—Drive fault detected.

•Amber, blinking—The device is rebuilding.

•Amber, blinking with one-second

interval—Drive locate function activated.

Hard drive fault

•Off—There is no hard drive in the hard drive

tray (no access, no fault).

•Green—The hard drive is ready.

•Green, blinking—The hard drive is reading or

writing data.

Hard drive activity

•Off—There is no AC power to the server.

•Amber—The server is in standby power mode.

Power is supplied only to the Cisco IMC and

some motherboard functions.

•Green—The server is in main power mode.

Power is supplied to all server components.

Power button/LED

•Off—The unit identification function is not in

use.

•Blue—The unit identification function is

activated.

Unit identification

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

Front Panel LEDs

•Green—The server is running in normal

operating condition.

•Green, blinking—The server is performing

system initialization and memory check.

•Amber, steady—The server is in a degraded

operational state. For example:

◦Power supply redundancy is lost.

◦CPUs are mismatched.

◦At least one CPU is faulty.

◦At least one DIMM is faulty.

◦At least one drive in a RAID configuration

failed.

•Amber, blinking—The server is in a critical

fault state. For example:

◦Boot failed.

◦Fatal CPU and/or bus error is detected.

◦Server is in an over-temperature condition.

System status

•Green—All fan modules are operating properly.

•Amber, steady—One or more fan modules

breached the critical threshold.

•Amber, blinking—One or more fan modules

breached the non-recoverable threshold.

Fan status

•Green—The server is operating at normal

temperature.

•Amber, steady—One or more temperature

sensors breached the critical threshold.

•Amber, blinking—One or more temperature

sensors breached the non-recoverable threshold.

Temperature status

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

Front Panel LEDs

•Green—All power supplies are operating

normally.

•Amber, steady—One or more power supplies

are in a degraded operational state.

•Amber, blinking—One or more power supplies

are in a critical fault state.

Power supply status

•Off—The Ethernet link is idle.

•Green—One or more Ethernet LOM ports are

link-active, but there is no activity.

•Green, blinking—One or more Ethernet LOM

ports are link-active, with activity.

Network link activity

Cisco SNS 3515 or SNS 3595 Appliance Back Panel View

The following figure shows the components of the Cisco SNS-3515 and Cisco 3595 appliance back panel

view.

Figure 2: Back Panel LEDs

Serial port (RJ-45 connector)7PCIe riser 1/slot 11

Dual 1-GbE Ethernet ports (LAN1 and

LAN2)

8PCIe riser 2/slot 22

VGA video port (DB-15)9Modular LAN-on-motherboard (mLOM)

card slot

Rear unit identification button/LED10Grounding-lug hole (for DC power

supplies)

Power supplies (up to two, redundant as

1+1)

11USB 3.0 ports (two)5

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

1-GbE Ethernet dedicated management

port

The following table describes the LEDs located on the back panel of the Cisco SNS 3515 or Cisco SNS 3595

appliance.

StateLED Name

•Off—No link is present.

•Green, steady—Link is active.

•Green, blinking—Traffic is present on the active

link.

Optional mLOM 1-GbE SFP+ (there is a single status

LED)

•Off—Link speed is 10 Mbps.

•Amber—Link speed is 100 Mbps/1 Gbps.

•Green—Link speed is 10 Gbps.

Optional mLOM 1-GbE BASE-T link speed

•Off—No link is present.

•Green—Link is active.

•Green, blinking—Traffic is present on the active

link.

Optional mLOM 1-GbE BASE-T link status

•Off—Link speed is 10 Mbps.

•Amber—Link speed is 100 Mbps.

•Green—Link speed is 1 Gbps.

1-GbE Ethernet dedicated management link speed

•Off—No link is present.

•Green—Link is active.

•Green, blinking—Traffic is present on the active

link.

1-GbE Ethernet dedicated management link status

•Off—Link speed is 10 Mbps.

•Amber—Link speed is 100 Mbps.

•Green—Link speed is 1 Gbps.

1-GbE Ethernet link speed

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

StateLED Name

•Off—No link is present.

•Green—Link is active.

•Green, blinking—Traffic is present on the active

link.

1-GbE Ethernet link status

•Off—The unit identification LED is not in use.

•Blue—The unit identification LED is activated.

Rear unit identification

AC power supplies:

•Off—No AC input (12 V main power off, 12 V

standby power off).

•Green, blinking—12 V main power off; 12 V

standby power on.

•Green, solid—12 V main power on; 12 V

standby power on.

•Amber, blinking—Warning detected but 12 V

main power on.

•Amber, solid—Critical error detected; 12 V

main power off.

Power supply status

Internal Diagnostic LEDs

The server has internal fault LEDs for CPUs, DIMMs, fan modules, SD cards, the RTC battery, and the mLOM

card. These LEDs are available only when the server is in standby power mode. An LED lights amber to

indicate a faulty component.

Power must be connected to the server for these LEDs to be operate.Note

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

The following figure shows the locations of these internal LEDs in Cisco SNS-3515 or Cisco SNS-3595

appliance.

Figure 3: Cisco SNS-3515 or 3595 Internal Diagnostic LED Locations

The following table describes the callouts in the above figure.

SD card fault LEDs (one next to each bay)4Fan module fault LEDs (one next to each fan

connector on the motherboard)

RTC battery fault LED5CPU fault LEDs (one in front of each CPU)2

mLOM card fault LED (on motherboard next

to mLOM socket)

6DIMM fault LEDs (one in front of each

DIMM socket on the motherboard)

The following table describes the internal diagnostic LEDs located inside the Cisco SNS-3515 or Cisco

SNS-3595 appliance.

StateLED Name

•Off—Component is functioning normally.

•Amber—Component has failed.

Internal diagnostic LEDs (all)

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Cisco SNS 3500 Series Appliances

Regulatory Compliance

For regulatory compliance and safety information, see Regulatory Compliance and Safety Information for

Cisco SNS-3415 and Cisco SNS-3495 Appliances.

Before You Begin

This section provides information on how you can prepare your site for safely installing the Cisco SNS-3515

or Cisco SNS-3595 appliance.

Safety Guidelines

Before you install, operate, or service a Cisco SNS-3515 or Cisco SNS-3595 appliance, review the

Regulatory Compliance and Safety Information for Cisco SNS-3515 and Cisco SNS-3595 Appliances for

important safety information.

Note

Warning: IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work

on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard

practices for preventing accidents. Use the statement number provided at the end of each warning to locate

its translation in the translated safety warnings that accompanied this device.

Statement 1071

Warning: To prevent the system from overheating, do not operate it in an area that exceeds the maximum

recommended ambient temperature of: 40° C (104° F).

Statement 1047

Warning: The plug-socket combination must be accessible at all times, because it serves as the main

disconnecting device.

Statement 1019

This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the

protective device is rated not greater than: 250 V, 15 A.

Statement 1005

Installation of the equipment must comply with local and national electrical codes.

Statement 1074

When you are installing a server, use the following guidelines

•Plan your site configuration and prepare the site before installing the server. See the Cisco UCS Site

Preparation Guide for the recommended site planning tasks.

•Ensure that there is adequate space around the server to allow for servicing the server and for adequate

airflow. The airflow in this server is from front to back.

Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1

Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances

Before You Begin

Otros manuales para SNS-3515 series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Servidor de Cisco

Cisco

Cisco UCS C Series Manual de usuario

Cisco

Cisco UCS B440-M1 Manual de usuario

Cisco

Cisco UCS X9508 Manual de usuario

Cisco

Cisco UCS C240 M4 Instrucciones de instalación y mantenimiento

Cisco

Cisco C880 M5 Manual de usuario

Cisco

Cisco APIC M4 Instrucciones de instalación y mantenimiento

Cisco

Cisco SCE2020-4XGBE-SM Manual de usuario

Cisco

Cisco c240 Instrucciones de instalación y mantenimiento

Cisco

Cisco UCS C260 Instrucciones de instalación y mantenimiento

Cisco

Cisco UCS C460 M2 Manual de usuario

Cisco

Cisco UCS C Series Instrucciones de montaje

Cisco

Cisco UCS B22 M3 Manual de usuario

Cisco

Cisco TelePresence Manual de servicio

Cisco

Cisco ONS 15600 Manual de usuario

Cisco

Cisco Expressway CE1200 Manual de usuario

Cisco

Cisco UCS C480 M5 Instrucciones de montaje

Cisco

Cisco UCS C Series Manual

Cisco

Cisco TelePresence MSE 8710 Manual de usuario

Cisco

Cisco UCS B420 M3 Manual de usuario

Cisco

Cisco UCS C24 Instrucciones de instalación y mantenimiento

Cisco

Cisco TelePresence Server 7010 Hoja de especificaciones

Cisco

Cisco C880 Series Instrucciones de montaje

Cisco

Cisco PDS2000 Manual de usuario

Cisco

Cisco AS5300 - Universal Access Server Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
